PLANON PRINTSTIK 900 SERIES
QUICK START GUIDE
DataStream
Before You Begin
Take a moment before you get started to
familiarize yourself with your new PRINTSTIK
printer.
PowerButton
PaperFeedButton
PrintingStatus
BatteryLife
Install PC Software
NOTE: Initially Charge the
PRINTSTIK for 3 hours. Plug your
PRINTSTIK into the wall outlet (AC) using the
wall charger included in your box. You can
also charge the PRINTSTIK by connecting it
to your home PC (or Laptop) via the USB
cable provided in your box, charge for 4
hours
Our Software works with Windows XP, Vista
& BlackBerry.
1
A. PRINTSTIK Driver:
Insert the PRINTSTIK installation CD. Select
the “PRINTSTIKInstall.exe” file. The window
below should open. Click “Next to proceed.
Follow installation instructions and choose
finish when process is complete.
Click“Next”
B. USB Driver:
Select the SetupApp.exe file from the
PRINTSTIK Installation CD. Click “next” to
begin installation.
Click“Next”
Follow setup wizard through instructions.
Once you arrive to this window, select the
“Install” option and click “next” to proceed.
Once completed click “finish”.
Click“Next”
C. Bluetooth Pairing:
Before attempting to pair your device, make
sure your PC or Laptop is pre-installed with
Bluetooth environment.
Search and locate the printer in “My
Bluetooth Places”, you will find your printer
with the address:
“PRINTSTIK 00XXXX” (2 zero’s followed by 4
alphanumeric characters)
Now proceed with pairing the PRINTSTIK.
Select the serial port icon, double click it and
now you will be required to enter a security
code; you can use the 4-digit code “0000”.
For detailed instructions please refer to the
User Manual.
D. Printing:
Choose PRINTSTIK printer from your list of
printers, select your file and print!
Install Blackberry Software
1. Verify your Blackberry Operating
System is 4.5 or higher*. Download
the driver files from the Planon
website link shown below. Extract the
download (the driver files) to a
location on your computer.
http://www.planon.com/drivers.php
2. Download BlackBerry Desktop
Manager (version 4.7 or higher) and
install on your computer. Copy the
following link to download this
program:
http://na.blackberry.com/eng/services/desktop/
3. Use the BlackBerry USB data cable to
connect your Smartphone Device and
computer.
*NOTE: If you do not have Blackberry
OS 4.5 or higher, check your
Blackberry Desktop Manager for
available updates. If not, then contact
your carrier.
4. Open the Blackberry Desktop
Manager on your PC.
2
5. The following screen will appear, if
this is your first time loading the
PRINSTIK drivers onto your
Blackberry, click on icon Application
Loader”
Choose“ApplicationLoader”
6. Follow the “Application Loader”
instructions until you reach the
screen below. Click “Add” to
continue.
Click “Browse”
