LEARN

M100™Bluetooth®Headset

TAKE A GOOD LOOK

CALL BUTTON

• Takeacallorendit (1 tap)

• Redial(2 taps)

• Initiatephone’svoice-dialing

(2-seccond press until tone heard)

• Reconnectlostconnection (1 tap)

• Activatepairingafterinitialsetup

(press until LED ﬂashes red/blue)

• Activatemultipoint (press while

powering on)

• Transferacallto/fromheadset

(1-second press while on a call)

POWER SWITCH

• On (slide to reveal black)

• Off (slide to reveal red)

MICRO USB CHARGING PORT

• WithACcharger:

30 minutes (2 hours talk time)

90 minutes (full charge)

• Bestperformancewhenfullycharged

VOLUME/MUTE BUTTON

• Min-Lo-Med-Hi-Max

(1 tap per level change)

• Mute:on/off (1-second press)

LED

• Charging (solid red)

• Fullycharged (solid blue)

• Lowbattery (2 red ﬂashes, 2 tones)

• Criticallylow (3 red ﬂashes, 3 tones)

• Multipoint (on=2 blue ﬂashes,

and off=1 blue ﬂash)

Besafe!Pleasereadthesafetyguide

beforeusingyournewheadset.

CONNECT TO YOUR PHONE

“Pairing” connects your

headset to your phone.

“Multipoint” lets you use this

headset with two phones.

(Activate this feature before

pairing your second phone.)

1. READY

Activate the Bluetooth feature on

your phone, then use the phone’s

settings to add/search/discover

new Bluetooth devices.

iPhone: Settings > General >

Bluetooth>On

(starts the search for devices)

BlackBerrysmartphone®: Settings/

options > Bluetooth: On >

Search for devices

VIDEO TUTORIAL IN USA:

www.plantronics.com/pairing

2. SET

FirstTime:

With headset turned off, activate

Bluetooth pairing mode by sliding

Power switch on. The LED ﬂashes

red/blue to indicate pairing mode.

ActivateMultipoint:

While pressing the Call button, turn

on the headset and keep pressing

the Call button until LED ﬂashes

blue twice. (Repeat to deactivate.)

PairingNewPhone/

ReconnectingOriginal:

Turn on the headset then press

and hold the Call button until the

LED ﬂashes red/blue.

3. CONNECT

Select “1xxPlantronics” from the

list of Bluetooth devices shown on

your phone.

If phone asks for a passcode, enter

four zeros (0000). You may see

**** on screen.

Some phones also ask to conﬁrm

headset connection after pairing.

Headset LED will stop ﬂashing red/

blue once your phone and headset

are successfully paired/connected.

FIND YOUR GROOVE

The loop of the gel eartip tucks into the back curve of your

ear for a stable ﬁt.

Try on the headset. The eartip is positioned to suit most

people, but you may want to rotate it to best ﬁt your left or

right ear.

The gel eartip and speaker click into matching grooves so

the eartip doesn’t move out of place during use.

The loop on the gel eartip should point away from the

headset. (Do not rotate the eartip too far.)

ForLeftEar

ForRightEar

MIX AND MATCH FOR BEST FIT

If the gel eartip feels loose or tight in your

ear, then change it. To replace the medium gel

eartip for small or large, pull the loop of the gel

eartip to remove it. (Don’t pull on the speaker

base and stem.)

Using your thumb, tuck the bottom of the

eartip over the speaker and pull the loop of

the eartip over the speaker. (Don’t push the

speaker through the gel eartip.)

If you aren’t familiar with this style of gel

eartip, clip on the earloop to the stem for

extra stability.

VIDEO TUTORIAL:

www.plantronics.com/M100t

MORE ABOUT MULTIPOINT

Plantronics M100 supports multipoint

technology, which allows you to use one

headset with two different Bluetooth

mobile phones.

To pair your headset to a second phone,

see “Connect to Your Phone.”

How to Initiate a Call

When multipoint is on, the headset

controls initiates or redials a call from

the phone that last made an outgoing

call.

To use the second paired phone in-

stead, make the call using the controls

on that phone. The second phone acti-

vates its link with the headset.

NOTE: The headset cannot place a cur-

rent call on hold while answering a call

from the second phone.

How to Answer a Call While Talking on

the Other Paired Phone

To answer a second call on the other

phone, the current call must be termi-

nated or transferred back to the ﬁrst

phone. To transfer the call, see “Take a

Good Look.”

If you choose not to answer, the sec-

ond call will go to voice mail.

Answeringanincomingcallfrom

thesecondphone,whilealreadyon

anothercall:

1. Before answering the second call,

end the ﬁrst call by tapping the Call

button.

2. Answer the second call by tapping

the Call button again.

TIP To avoid issues with Multipoint,

use the Call button on the headset

rather than your phone controls.

LISTEN TO THE VOICE

WHAT YOU’LL HEAR WHEN YOU’LL HEAR IT

PowerOn After sliding the Power switch to “on” position

PowerOff After sliding the Power switch to “off” position

TalkTime:(5hrs,4hrs,

3hrs,2hrs,1hr)

After sliding the Power switch to “on” position

BatteryLow When you have approximately 30 minutes left before

the battery must be recharged

RechargeHeadset When you have approximately 15 minutes left before

the battery must be recharged

Phone1Connected After sliding the Power switch to “on” position or recon-

necting a dropped Bluetooth connection

Phone2Connected After pairing a second phone using multipoint feature

Pairing While the headset and phone are trying to pair/connect

PairingSuccessful After the headset and phone are successfully paired/

connected

PairingIncomplete,

RestartHeadset

After the headset and phone tried to pair but failed

VolumeMaximum When the highest volume level is reached after tapping

Volume button

MuteOn After pressing Volume button for 1 second during a call

MuteOff When on mute, after pressing Volume button

for 1 second

LostConnection When the phone loses the Bluetooth connection with

the headset

MultipointOn After activating the feature by pressing Call button

while sliding the Power switch to “on” position

MultipointOff After deactivating the feature by pressing Call button

while sliding the Power switch to “off” position

This headset whispers various status

alerts when you power on/off, run low

on talk time, or lose/reconnect the

Bluetooth connection to your phone.

TIPS

Pair/Connect Just Once

Pairing is a one-time process unless

your phone loses the connection or

you want to pair a new phone.

Watch for Flashing Red LED

This headset will visually warn you

when your battery is low and needs to

be recharged.

Continue a Call Without the Headset

If you need to continue a call without

using your headset, just press the Call

button for 1 second and the call trans-

fers back to your phone. You will hear

a tone to conﬁrm the transfer.

Stay Near Your Phone:

Bluetooth has a working “range” of

up to 33 feet between the phone and

headset before audio degrades and

the connection is lost.

Know How to Reconnect:

Your headset tries to reconnect a lost

connection. If it can’t, then tap the Call

button once or manually reconnect via

the phone’s Bluetooth device menu.

Reset if You Cannot Reconnect

If your headset was working but now

won’t connect, remember that newer

phones are like small computers, so

they may become corrupt over time

and you may need to reset them every

so often.

Simply turn your phone off and re-

move the battery for a few seconds,

then replace the battery and turn it

back on again. If this does not resolve

the issue, delete the pairing informa-

tion for your M100 headset and pair it

with your phone again.

Sound Your Best:

For best voice pickup, always check

that the headset points towards the

corner of your mouth.

SPECIFICATIONS

TalkTime Up to 6 hours

StandbyTime Up to 10 Days

OperatingDistance(Range) Up to 33 feet (10 meters), Class II

HeadsetWeight 9 grams

HeadsetDimensions 55 x 18.5 x 8.1 mm

ChargeConnector Micro USB charging

BatteryType Rechargeable non-replaceable lithium ion polymer

ChargeTime(Maximum) 90 minutes for full

PowerRequirements 5V DC – 180mA

BluetoothVersion 2.1 speciﬁcations with EDR

BluetoothProles Hands-Free (HFP) Proﬁle 1.5 and Headset (HSP) Proﬁle 1.1

OperatingTemperature 32°F - 104°F (0 - 40°C)

StorageTemperature 32°F - 104°F (0 - 40°C)

ChargingTemperature 32°F - 104°F (0 - 40°C)

NEED MORE HELP?

24-hour support in USA:

1-866-363-BLUE (2583)

FAQs:

www.plantronics.com/M100faq

1-year limited warranty details:

www.plantronics.com/warranty

Bluetooth SIG, Inc. and any use by Plantronics is under license. All other trademarks

are the property of their respective owners.

Patents US 5,712,453; Patents Pending AM84466-01 (08/10)

Z109

N10687
