Plantronics Savi Go WO101/B Manuale utente
Savi™Go WO101/B Optimized for
Microsoft Office Communicator 2007®
Professional Wireless Headset System
User Guide
Plantronics Savi Go WO101/B Optimized for Microsoft Office Communicator 2007 User Guide
Welcome
Congratulations on purchasing your new Plantronics product. This guide contains instructions for
setting up and using your Savi Go professional wireless headset system.
Contents
Plantronics Savi Go WO101/B Optimized for Microsoft Office Communicator 2007 User Guide
1 Package Contents and Features
1.1 USB Adapter............................................................ 4
1.2 Headset ................................................................... 4
2 Set Up ........................................................................ 6
2.1 Connecting USB Adaptor to PC .............................. 6
2.2 Connecting Power Supply to
Charger Base ................................................................. 6
2.3 Fitting Headset ........................................................ 7
2.4 Docking and Charging Headset............................... 7
3 Test Call ......................................................................8
3.1 Making a Test Call Using Microsoft
Office Communicator..................................................... 8
4 Using Your Headset System with
Microsoft Office Communicator ..................................9
Powering Headset On/Off.............................................. 9
Placing, Answering and Ending Calls with
Microsoft Office Communicator .................................... 9
Muting a Headset Call ................................................. 10
USB Adapter Indicator Light........................................ 10
Headset Indicator Lights and Tones ............................ 10
Out of Range Warning ................................................. 11
Low Battery Warning ................................................... 11
Checking Battery Level................................................ 11
Turning Headset Indicator Blue Flash On/Off .............. 11
Mute Warning .............................................................. 11
Pairing Headset to USB Adapter ................................. 11
5 Using Your Headset with Your Bluetooth
Mobile Phone.............................................................12
Pairing Your Headset to Your Bluetooth
Mobile Phone............................................................... 12
Placing, Answering and Ending Calls
with Your Headset and Bluetooth Mobile Phone......... 12
Troubleshooting and Common Questions....................13
Plantronics Savi Go WH100/B Optimized for Microsoft Office Communicator 2007 User Guide 4
1.2 Savi Go (check model number) Headset
1.1 Savi Go USB Adapter and Charger
USB Adapter
USB Extension
Cable
Base Power Supply
1Package Contents and Features
Charger Base
Headband
Headset with Pre-Installed Earloop
Extra Ear Tab
Foam Ear Cushions
Plantronics Savi Go WH100/B Optimized for Microsoft Office Communicator 2007 User Guide 5
Savi Go USB Adapter Features
Savi Go (check model number) Headset Features
Pairing Button
Indicator Light
Earloop Indicator Light
Microphone
Call Control Button (also controls volume
and mute functions)
Ear Tab
Plantronics Savi Go WH100/B Optimized for Microsoft Office Communicator 2007 User Guide 6
2.2 Connecting Power Supply to Charger
Base
1Connect the base power supply into the power jack on
the charger base.
2Connect the power supply to the outlet. The power
indicator light will be solid green.
2Set Up
2.1 Connecting USB Adapter to PC
1Insert the USB adapter into USB Port on PC. The indicator
light on the base will be solid red to indicate the USB adapter
is powered on.
NOTE If the USB port is hard to access, use the provided USB
extension cable.
IMPORTANT NOTE For best performance it is recommended
that Windows is updated with Service Pack levels listed below:
Microsoft Windows®XP-Service Pack 3 (SP3) or later
Microsoft Windows Vista®-Service Pack 1 (SP1) or later
Plantronics Savi Go WH100/B Optimized for Microsoft Office Communicator 2007 User Guide 7
2.4 Docking and Charging Headset
1Gently push the headset into the charge cradle.
The indicator light on the headset will be solid red to indicate
that the headset battery is charging
2Charge for at least 20 minutes prior to the first use.
A full charge takes 3 hours.
CHARGING TIME
20 min .....................
Minimum charge
before first use
3 hours ...................
Full charge
2.3 Fitting Headset
The headset comes with a pre-installed earloop and ear tab. An
optional headband is also provided.
1To install the headband, gently unsnap the pre-installed
earloop from the headset.
2Snap the headband into the headset. The headband can
be adjusted to fit.
3For either wearing option rotate the headset until the
microphone is pointed toward your mouth.
4The headset can be converted for wearing on the left or
right ear with both earloop and headband.
Indicator Light
Power Indicator Light
Headset
Snap
Earloop
Headband
Ear Tab
5The ear tab has been designed to maximize stability of
the headset. It can be rotated on the headset to optimize
its fit and comfort in the ear. If desired, the ear tab can
be removed by pulling tab from the headset.
Plantronics Savi Go WH100/B Optimized for Microsoft Office Communicator 2007 User Guide 8
3.1 Making a Test Call Using
Microsoft Office Communicator
1 Ensure Microsoft Office Communicator is running on
your PC.
2 Set the headset and microphone volume to a
comfortable level using the Microsoft Office
Communicator “Set up Audio and Video” page*.
3 Place a test call using Microsoft Office Communicator.
4 Adjust the receive and listen volume to comfortable
levels using the volume control in the “Conversation
Window”*.
5 You can also fine tune the listening volume on the
headset by pushing the call control button up to
increase the volume and pushing down to decrease the
volume.
NOTE Do not press the call control button in when adjusting the
volume otherwise the call can be ended accidentally.
6. To end the test call, press the call control button on the
headset
3Test Call
* Consult Microsoft Office Communicator Help for more
information.
Plantronics Savi Go WH100/B Optimized for Microsoft Office Communicator 2007 User Guide 9
For your safety, do not use headset at high volumes for
extended periods of time. Doing so can cause hearing
loss. Always listen at moderate levels. For more information on
headsets and hearing visit: www.plantronics.com/healthandsafety.
Powering Headset On/Off
The headset will be ready to use once it has been charged in
the charger base as described in Section 2.5. Docking and
Charging the Headset
To conserve power you may optionally power the headset off, by
pressing and holding the call control button for six seconds. The
headset indicator light will be lit red for four seconds to confirm
that the headset is powered off. Note once powered off you will
not be able to use the headset.
To power the headset back on press and hold the call control
button for four seconds when the headset indicator will light blue
for two seconds, then flash red a number of times to indicate the
remaining battery charge (see Checking the Battery Level).
4Using Your Headset System with
Microsoft Office Communicator
Call Control Button
Indicator Light
Placing, Answering, and Ending Calls with Microsoft Office Communicator
To place a call Dial number using Microsoft Office Communicator*
To answer a call on the headset Short press call control button on headset
To answer a call when already on an
active call on your mobile phone
Short press the call control button once to end the mobile phone call then press again to answer
your Microsoft Office Communicator call
To end a call on the headset Short press call control button on headset
*Consult Microsoft Office Communicator Help for more information on how to place a call.
NOTE You can also answer calls directly from Microsoft Office Communicator by clicking on the Call Alert that appears on your PC screen.
In this case the call will be directed to the default speakerphone which may not be your headset. Consult Microsoft Office Communicator
Help for more information.
Plantronics Savi Go WH100/B Optimized for Microsoft Office Communicator 2007 User Guide 10
Muting a Headset Call
To mute a call, press and hold the call control button down (in the
volume down position) for two seconds. You will hear a low/high
tone pair indicating the mute is activated.
To unmute a call, push and hold the call control button down (in
the volume down position) for two seconds. You will hear a high/
low tone pair indicating the mute is deactivated.
USB Adapter Indicator Light
USB Adapter Status Indicator Light
Headset in talk mode Solid blue
Base and headset pairing Flashes red and blue
Headset Indicator Lights and Tones
Headset Status Headset Indicator Light
Headset charging Solid red
Headset fully charged Off
Headset battery low Flashes double red
Headset ready Slow blue flash (every 10 sec.)
Incoming call Flashes purple
Active call Fast blue flash (every 2 sec.)
Volume Down Button
