LEARN

Savor™M1100™

Bluetooth®Headset

TAKE A GOOD LOOK

CALL BUTTON

• Takeacallorendit (1 tap)

• Redial(2 taps)

• Reconnectlostconnection(1 tap)

• Activatepairingafterinitialsetup

(press until LED ﬂashes blue/red)

• Transferacallto/fromheadset

(1-second press during call)

POWER SWITCH

• On (slide to reveal black)

• Off (slide to reveal red)

VOICE RECOGNITION BUTTON

• VoiceRecognition(VR)commands

(Tap VR button, say a command

within 10 seconds. See Voice Com-

mands for commands list.)

• Initiatephone’svoice-dialing

(2-taps then tone heard)

MICRO USB CHARGING PORT

• WithACcharger:

20 minutes (1 hour talk time)

Less than 2 hours (full charge)

• Bestperformancewhenfullycharged

VOLUME/MUTE BUTTON

• Volumeup/down (1 tap per level

change)

• Mute:on/off (1-second press)

LED

• Charging (Solid red. No light when

fully charged)

• Lowbattery (2 red ﬂashes, 2 tones

and voice alert)

• Criticallylow (3 red ﬂashes, 3 tones

and voice alert)

Besafe!Please read the safety guide

before using your new headset.

CONNECT TO YOUR PHONE

“Pairing” connects your

headset to your phone.

“Multipoint” technology

lets you use this headset

with two phones.

1. READY

Activate the Bluetooth feature on

your phone, then use the phone’s

settings to add/search/discover

new Bluetooth devices.

iPhone:

Settings > General >

Bluetooth > On

(starts the search for devices)

BlackBerry®smartphone:

Settings/options >

Bluetooth: On >

Search for devices

VIDEO TUTORIAL IN USA:

www.plantronics.com/pairing

2. SET

FirstTime:

With headset turned off, activate

Bluetooth pairing mode by sliding

Power switch on. The LED ﬂashes

blue/red to indicate pairing mode.

PairingNewPhone/

ReconnectingOriginal:

Turn on the headset then press

and hold the Call button until the

LED ﬂashes blue/red.

3. CONNECT

Select “PLT_M1100” from the list of

Bluetooth devices shown on your

phone.

If phone asks for a passcode, enter

four zeros (0000). You may see

**** on screen.

Some phones also ask to conﬁrm

headset connection after pairing.

Headset LED will stop ﬂashing

blue/red once your phone and

headset are successfully paired/

connected.

PLT_M1100

FIND YOUR GROOVE

The loop of the gel eartip tucks into the back curve of

your ear for a stable ﬁt.

Try on the headset. The eartip is positioned to suit most

people, but you may want to rotate it to best ﬁt your left

or right ear.

The gel eartip and speaker click into matching grooves

so the eartip doesn’t move out of place during use.

The loop on the gel eartip should point away from the

headset. (Do not rotate the eartip too far.)

For Right Ear

For Left Ear

MIX AND MATCH FOR BEST FIT

If the gel eartip feels loose or tight in

your ear, then change it. To replace the

medium gel eartip for small or large,

pull the loop of the gel eartip to remove

it. (Don’t pull on the speaker base and

stem.)

Using your thumb, tuck the bottom of

the eartip over the speaker and pull

the loop of the eartip over the speaker.

(Don’t push the speaker through the gel

eartip.)

For best voice pickup, always check that

the headset points towards the corner

of your mouth.

VIDEO TUTORIAL:

www.plantronics.com/M1100t

Optionalearloopshown

MORE ABOUT MULTIPOINT

Plantronics M1100 supports multipoint

technology, which allows you to use one

headset with two different Bluetooth

mobile phones.

To pair your headset to a second phone,

see “Connect to Your Phone.”

How to Initiate a Call

When multipoint is in use, the headset

controls, initiates or redials a call from

the phone that last made an outgoing

call.

To use the second paired phone in-

stead, make the call using the controls

on that phone. The second phone acti-

vates its link with the headset.

NOTE: The headset cannot place a cur-

rent call on hold while answering a call

from the second phone.

How to Answer a Call While Talking

on the Other Paired Phone

To answer a second call on the

other phone, the current call must

be terminated or transferred back

to the ﬁrst phone. To transfer the

call, see “Take a Good Look.”

If you choose not to answer, the

second call will go to voice mail.

Answeringanincomingcallfrom

thesecondphone,whilealready

onanothercall:

1. Before answering the second

call, end the ﬁrst call by tapping

the Call button.

2. Answer the second call by tapping

the Call button again.

TIP To avoid issues with multipoint,

use the Call button on the headset

rather than your phone controls.

LISTEN TO THE VOICE

WHAT YOU’LL HEAR WHEN YOU’LL HEAR IT

PowerOn After sliding the Power switch to “on” position

PowerOff After sliding the Power switch to “off” position

TalkTime:(4hrs,3hrs,

2hrs,Lessthan2hours)

After sliding the Power switch to “on” position

BatteryLow When you have approximately 30 minutes left before

the battery must be recharged

RechargeHeadset When you have approximately 15 minutes left before

the battery must be recharged

Phone1Connected After sliding the Power switch to “on” position or recon-

necting a dropped Bluetooth connection

Phone2Connected After pairing a second phone using multipoint feature

Pairing While the headset and phone are trying to pair/connect

PairingSuccessful After the headset and phone are successfully paired/

connected

PairingIncomplete,

RestartHeadset

After the headset and phone tried to pair but failed

VolumeMaximum When the highest volume level is reached after tapping

Volume button

MuteOn After pressing Volume button for 1 second during a call

MuteOff When on mute, after pressing Volume button

for 1 second

LostConnection When the phone loses the Bluetooth connection with

the headset

Cancelled After saying “cancel” to stop a voice command

This headset whispers various status

alerts when you power on/off, run low

on talk time, or lose/reconnect the

Bluetooth connection to your phone.

VOICE COMMANDS

You can give your headset a

command, and it will whisper

the answer or do what you say.

If your command is not recognized

by the headset, you may hear a help-

ful prompt like “Always remember the

“What Can I Say?” command for

a list of active commands”.

Know How to Control the Headset:

First tap the VR Button then say:

 • WhatCanISay?

 • PairMode

 • AmIConnected?

 • CheckBattery

 • Redial

 • Cancel

 • CallInformation(USAonly;dials

 Bing411™)

 • CallVocalyst™(USAonly)

 • Answer(noneedtotapVRrst)

 • Ignore(noneedtotapVRrst)

TIPS

Pair/Connect Just Once:

Pairing is a one-time process unless

your phone loses the connection or

you want to pair a new phone.

Know How to Reconnect:

Your headset tries to reconnect a lost

connection. If it can’t, then tap the Call

button once or manually reconnect via

the phone’s Bluetooth device menu.

Continue a Call Without the Headset:

If you need to continue a call without

using your headset, just press the Call

button for 1 second and the call trans-

fers back to your phone. You will hear

a tone to conﬁrm the transfer.

Listen To Music But Don’t Miss a Call:

This headset supports Bluetooth A2DP

audio streaming to let you hear mu-

sic, internet radio, podcasts and even

turn-by-turn directions from your

A2DP-enabled phone. Use your phone

to start the music or audio and it will

automatically transfer to your headset.

If your phone rings, your streaming

audio will mute to allow you to answer

or ignore the incoming call then auto-

matically resume playback. Audio will

also pause when you use the headset

voice commands but will only resume

playing if you did not make an outgo-

ing call.

Stay Near Your Phone:

Bluetooth has a working “range” of

up to 33 feet between the phone and

headset before audio degrades and

the connection is lost.

Sound Your Best:

For best voice pickup, always check

that the headset points towards the

corner of your mouth.

SPECIFICATIONS

TalkTime Up to 4 hours

StandbyTime Up to 7 Days

OperatingDistance(Range) Up to 33 feet (10 meters), Class II

HeadsetWeight 9 grams

HeadsetDimensions 55 x 16 x 12 mm

ChargeConnector Micro USB charging

BatteryType Rechargeable non-replaceable lithium ion polymer

ChargeTime(Maximum) Less than 2 hours

PowerRequirements 5V DC – 180 mA

BluetoothVersion 2.1 speciﬁcations with EDR and eSCO

BluetoothProles Advanced Audio Distribution (A2DP), Hands-Free (HFP)

Proﬁle 1.5, Headset (HSP) Proﬁle 1.1 and Secure Simple

Pairing (SSP)

Operating,Storageand

ChargingTemperature

32°F - 104°F (0°C - 40°C)
