Plantronics .Audio 655 Manuale utente

Calisto™Pro Series

Home Phone with Multi-function

Bluetooth®Headset

User Guide

Ignore Answer

Incoming Call

John Smith

123-456-7890

Page 2

Please refer to the Safety Instructions on page 53 for important product

safety information prior to installation or use of this product.

With the Calisto Pro Series product, you get maximum ﬂexibility for

handling all of your calls:

Answer landline and VoIP calls using either the handset, the built-in

speakerphone, or the wireless headset.

Use the headset with other devices enabled with Bluetooth®

technology, such as your Bluetooth mobile phone.

This User Guide provides comprehensive information on how to use

your Calisto Pro Series and all of its features.

Tip: For a quick reference to common features, see the QuickTips card,

located under the base of your Calisto Pro Series. When you see this symbol

next to a topic in this User Guide, it means that you can ﬁnd a quick

reference for this topic on the QuickTips card.

•

Page i

Contents

Components ..........................................2

Setup................................................4

Hookingupthebase..................................4

Completedsystem ...................................4

Installing the handset battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Chargingthehandset.................................5

Chargingtheheadset .................................5

Wearing the headset and handset. . . . . . . . . . . . . . . . . . . . . . . . 6

Replacing the handset battery. . . . . . . . . . . . . . . . . . . . . . . . . . . 7

PoweringtheHeadsetOnandOff..........................8

Poweringyourheadseton..............................8

Poweringyourheadsetoff..............................8

Using Your Headset with Your Handset . . . . . . . . . . . . . . . . . . . . . . 9

Placingcalls ........................................9

Receivingcalls ......................................9

Adjustingcallvolume.................................10

Switching calls between handset, headset, and speakerphone 10

Endingcalls........................................11

Locating the headset from the handset . . . . . . . . . . . . . . . . . . . 11

Using Your Calisto Headset with Your Mobile Phone . . . . . . . . . . . 12

Pairing your Calisto headset with your mobile phone . . . . . . . . 12

Placingcalls .......................................13

Receiving calls using your headset . . . . . . . . . . . . . . . . . . . . . . 14

Adjusting call volume using your headset . . . . . . . . . . . . . . . . . 14

Ending calls using your headset . . . . . . . . . . . . . . . . . . . . . . . . 14

Additional mobile phone/headset features . . . . . . . . . . . . . . . . 15

UsingthePhonebook...................................16

Addingacontactmanually ............................16

Assigning speed dials and ring tones . . . . . . . . . . . . . . . . . . . . 17

Addingacontactfromacall...........................18

Editingacontact....................................18

Editingnamesandnumbers...........................18

Quicklyﬁndingacontact..............................19

Page ii

Deletingacontact...................................19

Chaindialing.......................................19

CallingFeatures:Basics.................................20

Caller ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Speakerphone......................................20

Lastnumberredial ..................................20

Mutingacall.......................................21

Usingspeeddialkeys................................21

Receiving a second incoming call . . . . . . . . . . . . . . . . . . . . . . . 22

Tipsformobilecalls..................................22

Viewing and editing the Call Log . . . . . . . . . . . . . . . . . . . . . . . . 23

Table 1: Headset button functions. . . . . . . . . . . . . . . . . . . . . . . 24

Table 2: Headset alerts ...............................24

Table 3: Handset screen icons . . . . . . . . . . . . . . . . . . . . . . . . . 25

Settings.............................................26

Adjustingtheringervolume............................26

Turningtheringeroff.................................26

Selectingaringtone.................................26

Adjusting the screen contrast . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Settingthedateandtime .............................27

Setting the default language . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Turning the keypad tone on or off . . . . . . . . . . . . . . . . . . . . . . . 28

Lockingthekeypad..................................28

Switching between tone dialing and pulse dialing . . . . . . . . . . . 29

Voicemail............................................30

Settingupquickvoicemail.............................30

Checkingvoicemail..................................30

Transferring Outlook Contacts into Phonebook . . . . . . . . . . . . . . . 31

Systemrequirements ................................31

Installingthesoftware................................31

Using the Outlook®Phonebook Utility . . . . . . . . . . . . . . . . . . . . 32

Phonebookstorage..................................34

CreatinganOutlookcontact...........................34

EditinganOutlookcontact ............................35

DeletinganOutlookcontact...........................36

Restoringyourphonebook ............................36

Page iii

Customizing the Outlook Phonebook Utility . . . . . . . . . . . . . . . 36

Viewing your updated contacts on your handset. . . . . . . . . . . . 36

Answering Calls from Your Computer’s VoIP Program . . . . . . . . . . 37

Systemrequirements ................................37

Installing the VoIP Utility software . . . . . . . . . . . . . . . . . . . . . . . 37

Using the PerSonoCall VoIP Utility. . . . . . . . . . . . . . . . . . . . . . . 39

Using the Handset with the Charging Base . . . . . . . . . . . . . . . . . . 40

Locating the handset from the charging base . . . . . . . . . . . . . . 40

Registering your handset with the charging base . . . . . . . . . . . 40

UsingaDifferentHeadset ...............................41

Pairingwithanewheadset............................41

Usingacordedheadset ..............................41

Troubleshooting.......................................42

ProductSpeciﬁcations..................................48

Headsetspeciﬁcations ...............................48

Handsetspeciﬁcations ...............................48

Help/Contact.........................................49

Technicalassistance.................................49

Warranty ............................................49

Limitedwarranty....................................49

FCC/RegulatoryNotices ................................50

FCC Compliance Class B Digital Device . . . . . . . . . . . . . . . . . . 50

FCC Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . 50

CanadianCompliance ...............................51

Federal Communications Commission (FCC) Part 68 Statement 51

Industry Canada CS-03 Declaration of Conformity . . . . . . . . . . 52

SafetyInstructions.....................................53

Page iv

Page 1

Contents

When you open the package, the battery, cables, and adapter can be

found in the compartment beneath the Calisto charging base.

Product & Accessories Documentation

Charging base Getting Started Guide

QuickTips Card

(stored under base)

Handset/Phone

Headset

Handset/Phone battery

door

AC power adapter

Telephone cord

USB cable

Cable splitter

(to use your phone jack with

more than one phone)

Software CD

Note: For information on optional accessories and replacement parts, visit

www.plantronics.com/calistopro.

Page 2

Components

Volume button

Waist clip

Corded headset jack

Ignore Answer

Incoming Call

John Smith

123-456-7890

Soft keys

(to select screen

options)

Menu navigation

Call end button

Keypad

Handset button

(illuminated when

handset is active)

Speakerphone button

(illuminated when

speakerphone is active)

Talk/Flash button

HANDSET

For descriptions of these

icons, see page 25.

Keypad lock

Voicemail

speed dial

OK/Select button

Speaker for

speakerphone

Battery

compartment

access

Page 3

Handset locator button

Headset

charging

contact

Handset charging cradle

CHARGiNG BASE

HEADSET

Earloop

Indicator light

Headset button

Eartip

Noise-

canceling

microphone

Headset

charging

cradle

Page 4

Setup

Hooking up the base

Remove the QuickTips card from

under the base.

Plug the AC power adapter into the

bottom of the Calisto base, and then

plug it into an available wall outlet.

Route the AC power adapter cable

under the cable holder as shown.

Plug one end of the telephone cable into the Calisto base and the

other end into an available wall telephone jack. If needed, use the

splitter included to share the wall jack with another device.*

Route the phone line cable under the cable holder as shown.

To use the VoIP capability, plug smaller end of the USB cable into

the Calisto base and the other end into an available USB port on

your computer.

Insert the Calisto Pro Series CD-ROM into your computer,

and follow the onscreen instructions. If the CD-ROM doesn’t

automatically play, double-click the My Computer icon on

the Windows desktop and choose the CD-ROM. Then run the

program Setup.exe.

* For use with a 4-wire 2-line wall outlet (RJ14C) a 2-line, 3-way jack adapter is required. Like most

landline phones, DSL users will need a DSL ﬁlter.

Completed system
