Plexon Multi-Wavelength Photometry Manuale utente

Multi-Wavelength Photometry

Quick Start Guide

Photometry

Please provide feedback and comments to:

support@plexon.com

Plexon Inc Proprietary

e information contained herein is the property of Plexon Inc and it is proprietary and restricted solely to assist Plexon Inc customers.

Neither this document nor the contents may be disclosed, copied, revealed or used in whole or in part for any other purpose without

the prior written permission of Plexon Inc. is document must be returned upon request of Plexon Inc.

Information is subject to change without notice. Plexon Inc reserves the right to make changes in equipment design or components as

progress in engineering or manufacturing may warrant.

PLEXON®, Plexon®, the ve-line symbol, CereStage™, CineCorder®, CineLAB®, CineLyzer®, CinePartner™, CinePlex®, CineTracker®,

CineTyper™, DigiAmp™, MiniDigi™, Oine Sorter™, OmniPlex®, PL2™, PlexBright®, PlexDrive™, PlexSort®, PlexStim™, Plextrode®,

Radiant™, RapidGrid™, TrackSort® and the Plexon logo are trademarks of Plexon Inc, Dallas, Texas, USA. Other product and company

names mentioned are trademarks of their respective owners.

(Initial Issue - September, 2020)

Plexon Multi-Wavelength Photometry Quick Start Guide Page 1 of 11

Photometry

Introduction

Plexon’s multi-wavelength photometry system has the capability to deliver multiple

wavelengths of excitation light and the ability to detect multiple wavelengths of emitted

light. The photometry system oers three excitation ranges centered at 560 nm, 465 nm, and

410 nm and two detection ranges centered at 600 nm and 525 nm. The system can monitor

multiple brain regions and track behavior simultaneously, which is useful in studying the

connection between dierent brain regions and the neural correlates of behavior.

Photometry System function

The uorescence of genetically encoded calcium indicators (GECIs), such as GCaMP

proteins, enables real-time optical monitoring and recording of neural activity of deep

brain structures in behaving animals. This camera-based system includes three built-in

LEDs for excitation and two optical sensors, which allow for detection of green and red

uorescence simultaneously. A branching patch cable provides the user with the ability to

record from multiple brain regions or multiple animals. The system interleaves the 410 nm

and 465 nm LEDS and the camera detecting green uorescence captures light for each of

these wavelengths independently, which allows the user to identify the calcium-dependent

uorescence (isobestic control).

This Quick Start Guide explains how to congure the Plexon® MultiWavelength Multi-ber

Photometry System (Photometry System).

Page 2 of 11Plexon Multi-Wavelength Photometry Quick Start Guide

Multi-Wavelength Photometry System and

Component Overview

The Photometry System components and connections are shown below.

The individual components are described in the pages that follow.

The Photometry System includes the following components:

Photometry

1. AC Power Cord

2. Power Supply

3. Multi-ber patch cable

4. Digtial IO Status Indicator

5. Trigger Box to Behavioral Camera Cable

6. USB cable type A to type B

7. Trigger Box

8. Trigger Box to Photometry Module cable

9. Multi-wavelength Multi-ber Photometry Module

10. Digital Input Generator

11. Trigger Box to Photometry Camera Cable (x2)

12. USB3 cable type A to type B with screwlocks (x2)

13. Fiber stub implants

14. USB cable type A to type mini-B

15. Photometry Behavioral Camera & Trigger Board

16. Computer

Page 3 of 11Plexon Multi-Wavelength Photometry Quick Start Guide

3.4.

10.

11.

12.

13.

14.

15.

16.

See Appendix A for more detailed part information

Photometry Hardware Setup

Each researcher will need to evaluate the experimental set up to determine the

optimal location for the placement of the photometry hardware. The multi-

ber patch cable will be connected directly to the photometry module and will need

to be positioned so that the terminating end of this patch cable can be connected to the

subject.

Setup Instructions

1. Verify that the computer is turned o (powered down).

2. Connect the cameras on the Multi-wavelength Multi-ber Photometry Module (9) to the Computer (16)

using the two USB3 cable type A to type B with screwlocks (12).

3. Next, connect the Cameras located on the Multi-wavelength Multi-ber Photometry Module (9) to the

Trigger Box (7) using the two Trigger Box to Photometry Camera cables (11).

4. Now, connect the Multi-wavelength Multi-ber Photometry Box (9) to the Trigger Box via the Trigger Box

to Photometry cable (8).

Page 4 of 11Plexon Multi-Wavelength Photometry Quick Start Guide

Photometry Module Trigger Box

IMPORTANT NOTE: Make sure to plug the cable from camera 1 on the photometry box

into the rst Trigger Box connector. The cable from Camera 2 should be plugged into the

second Trigger Box connector.

Page 5 of 11Plexon Multi-Wavelength Photometry Quick Start Guide

5. Connect the Trigger Box (7) to a power source with the AC Power cord (1) and

Power Supply (2).

6. Connect the Trigger Box (7) to the Computer (16) using the USB cable type A to type B (6).

7. Connect the Trigger Box (7) to the Photometry Behavioral Camera (15) using the Trigger Box to

Behavioral Camera Cable (5).

8. Connect the Computer (16) to the Photometry Behavioral Camera (15) using the USB cable type A to

type mini-B (14).

Page 6 of 11Plexon Multi-Wavelength Photometry Quick Start Guide

9. Connect the provided keyboard and mouse to the computer.

10. Insert the license key into one of the built in USB ports.

11. Connect the multi-ber patch cable (3) to the Multi-ber Multi-wavelength Photometry Module

(9).

12. Turn on the Trigger Box.

13. You can now turn on the computer and begin.

Key Collar

Slot

Patch cable

Photometry Module

CAUTION

All system components need to be connected, plus the Trigger Box power switch

needs to be in the “ON” position, before the software starts.

If started rst, the software will not recognize the photometry system hardware and either

will not start or will switch to File mode.

Page 7 of 11Plexon Multi-Wavelength Photometry Quick Start Guide

Appendix A - Part List (Name, Part Number, SL)

1. AC Power Cord

2. Power Supply / Plexon 08-06-A-37 / 40612

3. Multi-ber patch cable / Plexon 08-60-A-04-C /

4. Digital IO Status Indicator (optional) / Plexon 07-04-A-04-C / 20118

Page 8 of 11Plexon Multi-Wavelength Photometry Quick Start Guide

5. Trigger Box to Behavioral Camera Cable / Plexon 06-06-A-12-A / 41004-015

6. USB cable type A to type B / 40783

7. Trigger Box / Plexon 07-12-A-00-P3 / 92304

8. Trigger Box to Photometry Box Cable / Plexon 06-06-A-14 / 92301-003

Page 9 of 11Plexon Multi-Wavelength Photometry Quick Start Guide

9. Multi-wavelength Multi-ber Photometry Module / Plexon 08-61-A-07-A

10. Digital Input Generator (optional) / Plexon 07-04-A-03-B / 27901

11. Trigger Box to Photometry Camera Cable / Plexon 06-06-A-13 / 41005-015

12. USB3 cable type A to type B with screwlocks (x2) / 41018-003, 41018-005

Page 10 of 11Plexon Multi-Wavelength Photometry Quick Start Guide

13. Fiber stub implants / Plexon 08-44-A-10 / 90880

14. USB cable type A to type mini-B / 40520

15. Behavioral Camera / Plexon 07-04-A-24-A /
