Plus M-5 Manuale utente

Copyboard M-5

Quick Reference Guide

This quick reference guide is written for computers running

Windows Me/2000/XP. For all other windows operating

systems please refer to the M-5 Copyboard manual.

These operations are required when storing the drawings

on the copyboards’s sheet in the memory and when

moving the sheet surface using buttons.

Basic Operation

Connecting the AC power adapter and turning the power on and off

Connect the AC power adapter.

Connect the AC power adapter to the copyboard’s DC

power jack.

Connect the AC power cord to the AC power adapter.

Plug the AC power cord into a AC power outlet in a wall.

The explanations below assume this condition.

Insert plugs securely

AC power outlet

AC power cord

AC power adapter

Press the POWER button to turn on the power.

The POWER indicator blinks for approximately 20 seconds, then

stops blinking, remaining lit. The copyboard is now ready to scan

images (the fluorescent lamp is lit).

Drawings on the copyboard’s sheet can now be stored in the

memory.

Scrolling the Sheet

Scrolling the sheet automatically

Press the FEED/STOP button.

The sheet scrolls one sheet’s worth to the left (or upwards).

• To stop in the middle, press the FEED/STOP button again.

Scrolling the sheet manually

The sheet can be scrolled even if the copyboard’s power is turned off.

Move the sheet using your palm. The sheet moves either right or left

(up or down *1). Place your palm at the center in the vertical (or hori-

zontal *1) direction and move the sheet gently.

(*1When the copyboard is installed in the vertical position.)

Note:Moving the sheet too abruptly may damage the copyboard’s

drive mechanism.

Saving the Image on the Sheet

Images drawn on the sheet can be stored either in the built-in memory or on a CF memory card.

This is a black and white copyboard. Images drawn in color are stored in black and white.

Saving sheet images in the built-in memory

Preparations: Check that the POWER indicator is lit. If it is off, press the POWER button.

Press the FEED/STOP button to move the sheet image you want to

save to the front.

Press the MEMORY button to store that image in the memory.

• The sheet scrolls one page’s worth to the left (or upwards), scanning starts,

and the image is stored in the built-in memory.

• The MEMORY indicator blinks slowly while the image is being stored in the

memory.

MEMORY

FEED

STOP

MEMORY

POWE

CLEAR

FEED

STOP

Saving sheet images on a CF memory card

Press the MEMORY button to store that image in the memory.

• The sheet scrolls one page’s worth to the left (or upwards), scanning starts,

then the image is stored on the CF memory card.

• The MEMORY indicator blinks slowly while the image is being stored in the

memory.

Removing the CF memory card

Check that the MEMORY indicator has stopped blinking and turned off, then pull

the CF memory card out.

Preparations: Check that the POWER indicator is lit. If it is off, press the POWER button.

MEMORY

FEED

STOP

Insert the CF memory card into the copyboard’s card slot.

Press the FEED/ STOP button to move the sheet image you want

to save to the front.

Insert the CF memory card into the copyboard’s card slot.

Press the FEED/ STOP button to move the sheet image you want

to save to the front.

Storing/Deleting Directly with USB Connections (from built-in memory or CF memory card)

Connect the USB cable.

Use the included USB cable to connect the

copyboard’s USB connector to the computer’s

USB port.

MEMORY

POWER

CLEAR

OP SO

FEED

TOP

To store image files from a CF memory card, insert the

CF memory card into the copyboard’s card slot.

Open “My Computer” of the computer.

Right-click the “My Computer” icon, then left-

click “Explorer” from the menu.

• “My Computer” can also be opened by click-

ing on its icon.

Two additional removable memory devices ap-

continued on next page

pear in “My Computer”.

Select and open “Removable Disc [F]” (the drive character de-

pends on the computer system).

For the CF memory card, select and open “Removable Disc

[G]” (the drive number depends on the computer system) from

among the removable memory devices.

Clearing the built-in Memory

Use this procedure to clear all the image files in the built-in memory.

Press the CLEAR button and hold it in for more 3 seconds.

Once the CLEAR button has been held in for more 3 seconds, the MEMORY

indicator blinks slowly and file clearing starts.

Store the copyboard’s image folder onto the computer.

The folder name for the copyboard’s image files is “PVM”.

Select the PVM folder, specify the destination folder to copy it at

“Edit” →“Copy to folder” in Explorer, then click “OK”. This is just

one example of how to copy the folder.

Disconnect the USB cable.

The disconnecting procedure depends on the computer’s op-

erating system. For details, refer to the computer’s operating

instructions or help files.

Using a PC Card Adapter or Memory Card Reader/Writer (USB type)

Prepare the optional or commercially available memory card reader/writer or PC card adapter (for CF memory cards).

Using a PC card adapter

Insert the CF memory card into the PC card adapter.

Insert the PC card adapter into the

computer’s card slot.

Open “My Computer” of the computer.

“My Computer” can also be opened by clicking on its icon.

From among the removable memory devices shown in “My

Computer”, select and open “Removable Disc [F]” (the drive

character (“F” in this example) depends on the computer sys-

tem).

Using a memory card reader/writer (USB type)

Insert the CF memory card into the CF memory card

slot on the memory card reader/writer.

Connect the memory card reader/writer to the

computer’s USB port.

Open “My Computer” of the computer.

“My Computer” can also be opened by clicking on its icon.

From among the removable memory devices shown in “My

Computer”, select the drive corresponding to the CF memory

card.

The drive character depends on the computer system and the

number of slots in the memory card reader/writer. If you do not

know, search for the removable drive on which the PVM folder

is stored.

Deleting files

If the built-in memory or CF memory card gets full, some im-

age files must be deleted.

(The built-in memory can be cleared completely using the

CLEAR button on the copyboard’s control panel.)

(1)Select the drive for the built-in memory or the CF memory

card (steps to above).

(2)At step , open the PVM folder, select the image files you

want to delete, then select open “File” menu in Explorer and

click “Delete”.

To delete all the image files at once, delete the PVM folder.
