Polycom HDX Series Istruzioni per il montaggio

Place a Video Call

Entering a Name or Number

1. Select Place a Call from the Home screen, or just

start entering the number on the remote control.

2. Enter the ISDN number, IP or SIP address, or

H.323 name. Include the dots in an IP address. To

enter text, press Keyboard.

3. Press Call on the remote control.

Using the Directory

1. Press Directory on the remote control.

2. Highlight the contact you want to call. You can

navigate to the contact or use the Search field.

3. Press Call on the remote control.

Using Favorites or Recent Calls

On the Favorites or Recent Calls screen, select the

contact or press the reference number that appears

next to the contact.

Using Speed Dial

To call a speed dial contact from the Home screen,

highlight it and press Call on the remote control.

Using the Calendar

If your system is configured to use the calendaring

service, you can place calls from the Calendar screen.

1. Select Calendar from the Home screen.

2. Select the Join Now button if it appears when you

highlight the meeting.

Answer a Call

Press Call or select Yes using the remote control.

End a Call

1. Press Hang Up on the remote control.

2. If prompted, confirm that you want to hang up.

Select a far-site camera or video source

Get onscreen help, system status, or call

statistics

Adjust the speaker volume

Pan/tilt the camera; navigate through

menus

Select a near-site camera or video

source

Display a menu of optional features

Enter letters or numbers; move the

camera to a stored preset

Enter a dot, colon, or asterisk

Control a programmed recording

device

Store or delete camera presets

Go back to the previous screen

Change the display layout

Place or answer a call

Display the onscreen keyboard

Select a camera or other video

source

Power the system on or off

Start and stop sending content

Zoom the camera in or out

Mute your microphone

Delete letters or numbers

End a call

Go to the directory

Select the highlighted item

View remote control operations

Return to the Home screen

For more information about setting up and using the system, refer to the Support pages at www.polycom.com.

Quick Tips for Polycom HDX Systems

Power the System On and Off

• To power on the system, press the Power

button on the remote control or on the front of the

system.

• To power off the system, press and hold the

Power button on the remote control or on the front

of the system for 2 seconds. Wait 15 seconds

before you unplug the power cord.

Tips and Tricks

• Make sure you know the name or number of the

site you want to call.

• Connect and test any additional equipment before

the meeting.

• Avoid wearing bright colors, all-light or all-dark

clothing, or “busy” patterns. Light pastels and

muted colors look the best on the screen.

• Adjust your camera so that the far site can see you.

Fill the screen with people rather than with the

table, chairs, walls, lights, or floor.

• Adjust your microphone so that the far site can

hear you. Mute the microphone before moving it so

that the far site doesn't hear you moving it.

• Make sure that you can see and hear the far-site

participants.

• Introduce all participants when the meeting starts.

• Speak in your normal voice without shouting. Use

natural gestures when you speak.

• Don’t tap on the microphone or rustle papers near

the microphone. In a multipoint call, mute your

microphone when you are not speaking.

www.polycom.com |3725-23981-002/A | April 2010

are registered trademarks and Polycom HDX™ is a trademark

of Polycom, Inc.

Quick Tips for

Polycom HDX Systems

Place a Multipoint Call

• Place a call, then press Call on the remote

control to place a call to the next site. Repeat until

all sites are connected.

• Highlight a group in the directory, and press

Call on the remote control.

• Call one or more sites, and then ask those sites to

call additional sites.

Adjust the Volume

Press Volume on the remote control.

Mute Your Microphone

Press Mute on the remote control or on the

table microphone.

Add a Contact to the Directory

From the Favorites or Directory screen, select

Options > Add a Contact.

Add to the Favorites List

• From the Favorites or Directory screen, select

Options > Add a Contact.

• From the Recent Calls screen or the Global

Directory group in the directory, highlight a site

and select Options > Add to Favorites.

Select or Adjust a Camera

1. If you are in a call, press Near or

Far to select either near-site or far-site

control.

2. Press Camera on the remote control, then

select the camera or video source you want to

use.

3. Press the arrow buttons on the remote control to

pan or tilt the camera.

4. Press Zoom to zoom out or in.
