PowerPoint P65555MSFW Manuale utente

Smart Frost Fridge Freezer

P65555MSFW

INSTRUCTIONS:

Please read and keepsafe forfutureuse.

Serial No.

ser

You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Features………………………………………………………………………………………………….. 3

Transportation instructions......................................................................... 4

Introduction & safety warnings.................................................................. 5

Electrical Requirements/Installation ………………… ........................................6

Food Storage …………………………………………………………………….…………………….. 7

Defrosting/Arrangement of Food ................................................................ 9

Temperature Control ………………………………………………………………………………..10

Cleaning and Care………………........................................................................ 11

Top Tips ……………........................................................................................ 12

Problem solving ........................................................................................... 14

Technical data/Health &Safety .................................................................. 16

Disposal/Warranty Information...................................................................18

Customer Care …………………………………………………………………………………………. 20

INSTALLATION AND USER INSTRUCTIONS

You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Description

1 Thermostat

2 Refrigerator Glass Shelf

3 Crisper Cover

4 Crisper

5 Frozen Upper Drawer

6 Frozen drawer

7 Adjusting foot

8 Upper bottle frame

9 Middle bottle frame

10 Lower bottle frame

Features

You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

When transporting, never tilt to more than 45 degrees

The appliance should be transported only in a vertical upright position

The packaging as supplied must be intact during transportation

If during the course of transport the appliance has to be transported

horizontally, it must only be laid on its left hand side when standing in

front of the appliance. After bringing it tothe upright position, it must

not be operated for atleast 4 hours to allow the system to settle. The

manufacturerwill not be held responsible if these instructions are

disregarded.

The appliance must be protected against rain and moisture

When positioning your appliance take care not to damage your

flooring, kitchen furniture,relatedparts and doors, pipes,wall

coverings etc.

Do not move the appliance by pulling by the door

Transportation of your Appliance

You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Hold the base and lift the refrigerator carefully

Never hold the door handle as support

Never place the refrigerator upside down or lie itdown

Move refrigerator by using its two hind roller feet as an axis and then

tilting it slightly to move.

IMPORTANT: Do NOT connect your appliance to the electricity supply until

all packing and transit protectors have been removed.

Leave to stand for at least 4 hours before switching on to allow

compressor oil to settle if transported horizontally,if the appliance is

switched off at any time, wait 30 minutes before switching back on to

allow the coolant fluid to settle

If you are discarding an old refrigerator with a lock or latch fitted to

the door, disable the lock/latch, ensure that it is left in a safe

condition to prevent the entrapment of young children

This fridge/freezer must only be used for its intended purpose i.e. the

storing and freezing of edible foodstuff

Do not dispose of the appliance ona fire

Before First Use

You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Take care not to damage the cooling circuit, if damaged immediately

ventilate the room where the appliance is situated

This appliance should not be used in an unheated, cold room i.e.

Garage, conservatory, annex, shed,out-house etc.

Ensure that the plug remains readily accessible

Failure to observe these instructions may invalidate your right to free

service during the guarantee period

We recommend a separate switch be used to ensure easy switch

on/off

Children should be supervised to ensure that they do not play with the

appliance

This appliance is intended to be used in a household environment

IMPORTANT WARNINGS:

Keep ventilation openings in the appliance enclosure and the built-in

structure clear of obstruction.

Make sure that mains cable is not caught under the appliance during

and after carrying / moving the appliance, to avoid the mains cable

becoming cut or damaged.

Care must be taken while cleaning / carrying the appliance to avoid

Touchingthe bottom of the condenser metal wires at the back of the

Appliance as you may injure your fingers and hands.

Levelling the Fridge/Freezer

If the Fridge/Freezer is not level, the door and magnetic seal

alignment will be affected and may cause you Fridge/Freezer to

work incorrectly. Once the Fridge/Freezer is placed in its final

location, adjust the levelling feet at the front by turning them.

Before you insert the plug into the wall socketmake sure that the voltage and

Electrical Requirements

You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

The frequency shown in the rating plate inside the appliance corresponds to

Your electricity supply. We recommend that this appliance is connected to the

mains supply via a suitable switched and fused socketin a readily accessible

position.

Should the mains lead of the appliance become damaged or should it need

Replacing at any time, it must be replaced by a special purpose made mains

Lead which can only be obtained from Shomar Ltd.

WARNING! THIS APPLIANCE MUST BE EARTHED

If the fitted plug is not suitable for your socket, then the plug should be

removed and an appropriate plug fitted. Destroy the old plug which is cut off

as a plug with bared cord could cause a shock hazard if inserted into a socket.

The plug on this appliance incorporates a 13 Amp fuse.Should the fuse need

to be changed a fuse of the same rating must be used. Ensure that the fuse

cover is refitted.

1. Install the refrigerator on a flat surface in order to prevent vibration

and noise.

2. The cord should be secured behind the appliance to avoid injury

3. Choose a dry well-ventilated place

4. Minimum space in the room where the refrigerator is being installed

is 10 cubic metres.

5. Choose a location where there is no heat source. Keep the refrigerator

away from direct sunlight, oven etc.

6. Do not place the appliance near cookers, radiators or in directsunlight

as this will cause your appliance to work harder.

7. Don’t install this appliance in a wall recess or into fitted cabinets.

8. Allow a gap of 3.5” between the back grille and the wall.

9. Allow a gap of 2 cm either side of the unit.

Installation Instructions

You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

10. Toensure that your appliance is level adjust the levelling feet at the

front by turning them

Before you start using the refrigerator check that:

1. The interior is dry and air can circulate freely at the rear of the

cabinet.

2. Clean the interior as recommended under "CLEANING AND CARE."

3. Insert the plug into the wall socket and switch on the electricity

supply.

4. You will hear a noise as the compressor starts up. The liquid and gases

sealed within the refrigeration system may also give rise to noise,

whether the compressors running or not which is quite normal.

5. Frontedges of the cabinet may feel warm. This is normal.

6. Do not load the appliance immediately it is switched on. Wait until the

Correct storage temperature has been reached. We recommend that

You check the temperature with an accurate thermometer or wait 24

hours.

How to Use the Refrigerator Compartment:

Cooked /fresh foods may be stored in your refrigerator. Hotfoods

must first be allowed to reach room temperature before storage

Eggs and Bottle’s should be stored on the shelves provided in the door

Meat and fish should be covered to prevent loss of moisture and

odours,wrap such foods in aluminium foil or polythene or store in an

airtight container

It is advisable to store cooked food on top shelves and fresh food on

the lower shelves to prevent cross contamination

How to Use the Freezer Compartment:

Food Storage

You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Pre-packed commercially frozen food should be stored in accordance

with the frozenfood manufacturer's instructions for a frozen

food storage compartment

To ensure that the high quality achieved by the frozen food

manufacturerand the food retailer is maintained, the following

should be observed:

- Put packets in the freezer as quickly as possible after purchase.

- Ensure that contents are labelled and dated.

- Do not exceed "Use By" or "Best Before" dates on the packaging

If there is a power failure do not open the door. Frozen food should

not be affected if the failure lasts forless than 14 hrs. If the failure is

longer, then the food should be checked and either eaten

immediately or cooked and then refrozen

Freezing Fresh Food:

Do not freeze too large a quantity atany one time. The quality of the

food is best-preserved when it is frozen right through as quickly as

possible

Do not exceed the freezing capacity of your appliance in 24 h which is

4 kg (9lb)

Placing warm food into the freezer compartment causes the

refrigeration compressor to operate continuously until the food is

frozen solid. This can temporarily lead toexcessive cooling of the

refrigeration compartment.

Defrosting

You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

After a period of time frost will build up in certain areas in the Freezer

compartment. As a temporary measure, this frost should be scraped away

using the plastic scraper included with the appliance.

NEVER use a metal or sharp instrument. Complete defrosting will however

become necessary approximately once per year, or if the frost layer exceeds

5mm to maintain the efficiency of the Fridge/Freezer.

This should be carried out if the frost build-up cannot be scraped away, or if it

begins to interfere with the food storage. Chose a time when the stock of

frozen food is low and proceed as follow:

1. Take out the frozen food, turn the Fridge/Freezer off at the mains supply

and leave the doors open. Ideally the frozen food should be put into

another Freezer.

2. Scrape away as much frost build-up as possible using the plastic scraper.

To accelerate the thawing process place bowls of hot water inside the

Freezer cabinet.

As the solid frost loosens, prize it away with the plastic scraper and

remove.

3. When thawing/defrosting is complete, remove the water in water tray

that is located atthe back of the appliance above the compressor. Then

clean and dry out your Fridge/Freezer with a dry cloth.

ARRANGEMENT OF FOOD IN THE FRIDGE/FREEZER

The following guidelines and recommendations are suggested to obtain the

Best results:

1. The fridge compartment is for the short term storage of fresh food

and drinks.

2. The freezer compartment is rated and suitable for the freezing and

storage of pre frozen food. The recommendation for storage as

stated on the food packaging should be observed at all times.

You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)

Indice

Altri manuali PowerPoint Frigorifero

PowerPoint

PowerPoint P4471CKW Manuale utente

PowerPoint

PowerPoint DF214 Manuale utente

PowerPoint

PowerPoint P4554FML Guida

PowerPoint

PowerPoint P4504MDW Manuale utente

PowerPoint

PowerPoint P467TTIBWDW Manuale utente

PowerPoint

PowerPoint P64864MSFW Manuale utente

PowerPoint

PowerPoint P98317SKGRB Manuale utente

PowerPoint

PowerPoint P9383WDKSS Manuale utente

PowerPoint

PowerPoint P1271185MFZIN Manuale utente

PowerPoint

PowerPoint P450TTIBMDW Manuale utente

PowerPoint

PowerPoint P87030EMBI Manuale utente

PowerPoint

PowerPoint P450TTLMW Manuale utente

PowerPoint

PowerPoint P450TTIBLM Manuale utente

PowerPoint

PowerPoint P4481IBMDW Manuale utente

PowerPoint

PowerPoint P4554LMW/2 Manuale utente

PowerPoint

PowerPoint P7531M/3 Guida

PowerPoint

PowerPoint P4481IBM Manuale utente

PowerPoint

PowerPoint P450TTLFW Manuale utente

PowerPoint

PowerPoint P45514ML1W Manuale utente

PowerPoint

PowerPoint P65564FFSS Manuale utente

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Samsung

Samsung RF323TE Manuale utente

Beko

Beko CSA31022 Manuale utente

IKEA

IKEA FROSTIG C 185 E Manuale utente

Electrolux

Electrolux ER 6821 D Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente
