Powerware 5125 Manuale utente

Powerware®5125

Tower

User’s Guide

1000–2200 VA

www.powerware.com

Requesting a Declaration of Conformity

Units that are labeled with a CE mark comply with the following harmonized standards and EU directives:

Harmonized Standards: EN 50091-1-1 and EN 50091-2; IEC 950 Second Edition, Amendments A1, A2, A3, and A4

EU Directives: 73/23/EEC, Council Directive on equipment designed for use within certain voltage limits

93/68/EEC, Amending Directive 73/23/EEC

89/336/EEC, Council Directive relating to electromagnetic compatibility

92/31/EEC, Amending Directive 89/336/EEC relating to EMC

The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of the EC

Declaration of Conformity, contact:

Powerware Corporation

Koskelontie 13

FIN-02920 Espoo

Finland

Phone: +358-9-452 661

Fax: +358-9-452 665 68

Powerware is a registered trademark and Advanced Battery Management Plus (ABM Plus), X-Slot, and ConnectUPS are

trademarks of Powerware Corporation.

reproduced in any way without the express written approval of Powerware Corporation.

Class A EMC Statements

(1000–1500 VA Models)

FCC Part 15

NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

ICES-003

This Class A Interference Causing Equipment meets all requirements of the Canadian Interference Causing Equipment

Regulations ICES-003.

Cet appareil numérique de la classe A respecte toutes les exigences du Reglement sur le matériel brouilleur du Canada.

EN50091-2

Some configurations are classified under EN50091-2 as “Class-A UPS for Unrestricted Sales Distribution.” For these

configurations, the following applies:

VCCI Notice

Special Symbols

The following are examples of symbols used on the UPS to alert you to important information:

RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present and the

associated warning should be observed.

CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual for

additional information, such as important operating and maintenance

instructions.

RJ-45 RECEPTACLE - For 230V units only: this receptacle provides network

interface connections. Do not plug telephone or telecommunications equipment

into this receptacle.

This symbol indicates that you should not discard the UPS or the UPS batteries

in the trash. The UPS may contain sealed, lead-acid batteries. Batteries must be

recycled.

Powerware®5125 Tower (1000–2200 VA) User’s Guide

Rev B www.powerware.com

TABLE OF CONTENTS

1 Powerware 5125 – One of the Best! 1..................................

2 Safety Warnings 3.................................................

3 Installation 17.....................................................

Inspecting the Equipment 17.......................................................

Installing the UPS 17.............................................................

UPS Rear Panels 20..............................................................

4 Operation 25......................................................

Operating Modes 25.............................................................

Normal Mode 26.............................................................

Buck and Double Boost Mode 26..................................................

Battery Mode 27.............................................................

Standby Mode 27.............................................................

Sleep Mode 27..............................................................

Turning the UPS On 27...........................................................

Starting the UPS on Battery 27...................................................

Turning the UPS Off 28...........................................................

Initiating the Self-Test 28.........................................................

5 Additional UPS Features 29..........................................

X-Slot Modules 29..............................................................

Single-Port Module 30.........................................................

Network Transient Protector 31.....................................................

Load Segments 32..............................................................

6 UPS Maintenance 33...............................................

UPS and Battery Care 33..........................................................

Storing the UPS and Batteries 33..................................................

When to Replace Batteries 33......................................................

Replacing Batteries 34...........................................................

How to Replace Extended Battery Modules 34........................................

How to Replace Internal Batteries 35...............................................

Testing New Batteries 37.........................................................

Recycling the Used Battery 38......................................................

Table of Contents

ii Powerware®5125 Tower (1000–2200 VA) User’s Guide

Rev B www.powerware.com

7 Specifications 39..................................................

8 Troubleshooting 43.................................................

Audible Alarms and UPS Conditions 43................................................

Silencing an Audible Alarm 44....................................................

Service and Support 46...........................................................

Powerware®5125 Tower (1000–2200 VA) User’s Guide

Rev B www.powerware.com

CHAPTER 1

POWERWARE 5125 – ONE OF THE BEST!

The Powerware

5125 uninterruptible power system (UPS) protects

your sensitive electronic equipment from basic power problems such as

power failures, power sags, power surges, brownouts, and line noise.

Power outages can occur when you least expect it and power quality can

be erratic. These power problems have the potential to corrupt critical

data, destroy unsaved work sessions, and damage hardware — causing

hours of lost productivity and expensive repairs.

With the Powerware 5125, you can safely eliminate the effects of power

disturbances and guard the integrity of your equipment. The Powerware

5125 was designed for critical applications such as PCs, severs,

workstations, and telecommunications equipment. Figure 1 shows the

Powerware 5125 UPS with an optional Extended Battery Module (EBM).

Powerware 5125 – ONE OF THE BEST!

2Powerware®5125 Tower (1000–2200 VA) User’s Guide

Rev B www.powerware.com

Providing outstanding performance and reliability, the Powerware

5125’s unique benefits include the following:

Advanced Battery Management Plus (ABM Plus

) doubles battery

service life, optimizes recharge time, and provides a warning before

the end of useful battery life.

Buck and Double Boost regulation ensures consistent voltage to your

load by correcting voltage fluctuations without using battery power.

Hours of extended run time with up to four EBMs.

Hot-swappable batteries simplify maintenance by allowing you to

replace batteries safely without powering down the critical load.

Start-on-battery capability allows you to power up the UPS even if

utility power is not available.

Advanced power management with the Software Suite CD for graceful

shutdowns and power monitoring.

Sequential shutdown and load management through separate

receptacle groups, called load segments.

Network Transient Protector guards your network communications

equipment from surges. Low voltage models can also protect

modems, fax machines, or other telecommunications equipment.

Optional X-Slot

modules provide enhanced communication

capabilities for increased power protection and control.

The Powerware 5125 is backed by worldwide agency approvals.

Powerware®5125 Tower (1000–2200 VA) User’s Guide

Rev B www.powerware.com

CHAPTER 2

SAFETY WARNINGS

Read the following precautions before you install the UPS.

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS. This manual contains important instructions that you

should follow during installation and maintenance of the UPS and batteries. Please

read all instructions before operating the equipment and save this manual for future

reference.

DANGER

This UPS contains LETHAL VOLTAGES. All repairs and service should be performed

by AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER

SERVICEABLE PARTS inside the UPS.

WARNING

This UPS contains its own energy source (batteries). The output receptacles may

carry live voltage even when the UPS is not connected to an AC supply.

Do not remove or unplug the input cord when the UPS is turned on. This removes

the safety ground from the UPS and the equipment connected to the UPS.

To reduce the risk of fire or electric shock, install this UPS in a temperature and

humidity controlled, indoor environment, free of conductive contaminants.Ambient

temperature must not exceed 40

C (104

F). Do not operate near water or

excessive humidity (95% max).

To complywith internationalstandards and wiring regulations,the totalequipment

connected to the output of this UPS must not have an earth leakage current

greater than 1.5 milliamperes.

Safety Warnings

4Powerware®5125 Tower (1000–2200 VA) User’s Guide

Rev B www.powerware.com

CAUTION

Batteries can present a risk of electrical shock or burn from high short-circuit

current. Observe proper precautions. Servicing should be performed by qualified

service personnel knowledgeable of batteries and required precautions. Keep

unauthorized personnel away from batteries.

Proper disposal of batteries is required. Refer to your local codes for disposal

requirements.

Never dispose of batteries in a fire.Batteries mayexplode whenexposed to flame.

Sikkerhedsanvisninger

VIGTIGE SIKKERHEDSANVISNINGER

GEM DISSE ANVISNINGER

DENNE BRUGERVEJLEDNING INDEHOLDER VIGTIGE

SIKKERHEDSANVISNINGER

FARE

Denne UPS indeholder LIVSFARLIG HØJSPÆNDING. Alle reparationer og

vedligeholdelse bør kun udføres af en AUTORISERET SERVICETEKNIKER. Ingen af

UPS’ens indvendige dele kan repareres af brugeren.

ADVARSEL!

Denne UPS indeholder egen energiforsyning (batterier). Udgangsnetstikkene kan

lede strøm, selv når UPS’en ikke er tilsat en AC-energikilde.

Netledningen må ikke fjernes og stikket må ikke trækkes ud, mens UPS’en er

tændt. Dette fjerner sikkerhedsjorden fra UPS’en og fra det udstyr, der er sat til.

Installér denne UPS i et temperatur- og fugtighedskontrolleret indendørsmiljø, frit

for ledende forureningsstoffer for at formindske risikoen for brand og elektrisk

stød. Rumtemperaturen må ikke overstige 40

C. UPS’en bør ikke betjenes nær

vand eller høj fugtighed (maksimalt 95%).

I overensstemmelse med internationalenormer ogbestemmelser for el-installation

må det udstyr, der er forbundet til udgangen af denne UPS, tilsammen ikke

overskride en jordafdelingsspænding på mere end 1,5 milliampere.

Altri manuali per 5125

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Powerware UPS

Powerware

Powerware 9315 Manuale utente

Powerware

Powerware 300 VA Manuale utente

Powerware

Powerware UPS 1000 - 2200 Manuale utente

Powerware

Powerware Uninterruptible Power Supply Manuale utente

Powerware

Powerware 5110 Manuale utente

Powerware

Powerware 9125 Manuale utente

Powerware

Powerware 9170+ Manuale utente

Powerware

Powerware 5105 Manuale utente

Powerware

Powerware 5119 Manuale utente

Powerware

Powerware 9355 Manuale utente

Powerware

Powerware 5140 Manuale utente

Powerware

Powerware 9910 p Series Manuale utente

Powerware

Powerware 9155 Manuale utente

Powerware

Powerware 5140 Manuale utente

Powerware

Powerware 9305 HS Series Manuale operativo

Powerware

Powerware 5115 Manuale utente

Powerware

Powerware Prestige series 9 Manuale utente

Powerware

Powerware 3110 Manuale utente

Powerware

Powerware 9170+ Manuale utente

Powerware

Powerware BPIV Manuale utente

Powerware

Powerware 5125 Tower Manuale utente

Powerware

Powerware 3105 Manuale utente

Powerware

Powerware 9170+ Manuale utente

Powerware

Powerware 9155 Manuale utente

Manuali UPS popolari di altre marche

Pylontech

Pylontech Victron & Pylontech US5000 Manuale utente

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuale utente

Mecer

Mecer ME-1000-WTU Manuale utente

Mustek

Mustek PowerMust 530(B) Plus Manuale di installazione e funzionamento

Emerson

Emerson Liebert NXL series Manuale utente

MAKELSAN

MAKELSAN BOXER SERIES Manuale utente

Block

Block PC-0524-400-0 Manuale utente

CyberPower

CyberPower CP585LCD Manuale utente

Eaton

Eaton 3S Istruzioni per il montaggio

CyberPower

CyberPower Office Tower Series UPS 1000 Manuale utente

CyberPower

CyberPower BM100 Manuale utente

Best Power

Best Power 610 Manuale utente

Best Power

Best Power Unity/I UT3K Manuale utente

Mustek

Mustek PowerMust 400 Offline Manuale utente

Xantrex

Xantrex Trace 512 UR-UPS Manuale utente

Forza

Forza SL-1501UL Manuale utente

LEGRAND

LEGRAND keor 310081 Manuale utente

ABB

ABB Conceptpower DPA 500 Manuale utente
