Precor 903 Manuale utente
page 1
Owner’s Manual
Assembly and Operation
Electronic
Console
withthe
PulseFeature
R
USA
page 2
Safety Information
Pleasereviewandobservethefollowingsafetyguidelineswhen
assemblingandusingthePrecor903/904electronicconsole:
Before beginning any fitness program, you should see your
physician for a thorough physical examination.
• Read the Owner’s Manual and follow all instructions.
These instructions are written to ensure your safety
and to protect the equipment.
• Handle the Precor 903/904 electronic console with
care. Do not drop the equipment. It might damage the
device and you could void the Precor limited warranty.
• After extensive use, the batteries may wear out which
causes the information on the display to flicker
erratically or not appear at all. If you need to replace
the batteries, refer to
Replacing the Batteries
in the
maintenance section of this manual.
• Do not operate the treadmill for a 24-hour period after
installing the magnet and reed switch. A 24-hour
period is required so that the adhesive on the
mounting pads can bond properly.
The Precor 903/904 electronic console is designed to
enhance your workout. By following the above precautions
and using good common sense, you will have many safe
and enjoyable hours of healthy exercise with your Precor
products.
Obtaining Service
Do not attempt to service the 903/904 electronic console
yourself other than assembling the magnet and reed switch
and maintaining the electronic console as discussed in this
manual.
For information about product operation or service, contact
an authorized Precor dealer (or a Precor Factory Authorized
Service Company). To locate the Precor dealer or service
company nearest you, call 1-800-4-PRECOR.
page 3
Table of Contents
SafetyInformation ........................................................... 2
Obtaining Service ........................................................ 2
Before You Begin .......................................................... 4
Unpacking the Electronic Console ................................ 4
Installing the Electronic Console ................................. 5
903 Assembly Procedures........................................... 5
904 Assembly Procedures........................................... 9
Installing the Mounting Pads ....................................... 12
Attaching the Magnet and Reed Switch ....................... 14
Using the Electronic Console ....................................... 17
Electronic Console Buttons.......................................... 17
Electronic Console Displays......................................... 18
Setting the Timer ......................................................... 19
Setting the Distance..................................................... 20
Choosing a Target Heart Rate ...................................... 20
ResettingYourWorkoutStatistics .................................... 22
MaintainingtheElectronicConsole .................................... 23
Replacing the Batteries................................................ 23
Appendix A — Flywheel Template ............................... 26
page 4
BeforeYouBegin
Thank you for purchasing the easy-to-use electronic
consoleoptionforyourPrecor903Manualor904TotalBody
Treadmill. Before assembling the console onto your
treadmill, take the time to read through this manual so that
you are familiar with the contents of the package and the
features on the electronic console.
Obtaintheappropriatetoolsbeforeassemblingtheelectronic
consoleontothe903or904treadmill.YouwillneedaPhillips
headscrewdrivertoattachtheelectronicconsoleontothe
handrailclamp.
Unpacking the Electronic Console
Carefullyunpacktheelectronicconsoleanditscomponents.
Makesurethatyouhavethefollowingitems:
❑oneelectronicconsole
❑onemountingbracketwithfour(twoshortandtwo
long) Phillips head screws
❑one reed switch and wire
❑onemagnet
❑oneearclipandwireconnector
❑threeCclips—holdsreedswitchwiretohandrail
❑twomountingpads(onethickandonethinpad)
Ifanyitemsaremissing,contactthedealerfromwhomyou
purchasedthetreadmillorcall1-800-4-PRECORforthedealer
nearestyou.
page 5
InstallingtheElectronicConsole
The handrail clamp can be used on either the 903 or 904
treadmill. However, the steps used to install the console
onto the clamp are slightly different depending on which
treadmill you have. Please refer to the steps that apply to
your treadmill.
903 Assembly Procedures
To install the 903 electronic console, take the following
steps:
1. Locatethehandrailclampintheboxthataccompaniesthe
electronic console’s box. Remove the long and short
screwsfromthehandrailclampusingyourfingersora
Phillipsheadscrewdriver.Setthescrewsaside.Youcan
discardtheshortscrewssincetheyareonlyusedforthe
904assembly.
Diagram 1
2. Placethehandrailclamparoundthemid-portionofthe
handrail as shown in Diagram 1. Place a hand on
either side of the handrail clamp to gently pull it apart
so that you can slide it onto the handrail’s foam grip.
Important:Donotmounttheclamponthepaintedsurface
ofthehandrails.
page 6
3. Unlockandremovethemountingbracketfromthebackof
theelectronicconsole.Unlockthemountingbracketby
pushingitdowntowardthebaseoftheconsole.See
Diagram2.
Diagram 2
Diagram 3
4. Positionthemountingbracketontothehandrailclampso
thatthesmoothsideoftheplateisfacingyou.See
Diagram3.
page 7
5. Securethemountingbracketandclampbyinsertingthe
twolongscrewsthroughthemountingholes.Youmay
needtosqueezetheendsoftheclamptogethertoinstall
thescrews.SeeDiagram3.Tightenthescrewsintothe
recessedholesonthemountingplateusingthePhillips
headscrewdriver.Donotovertightenthescrews.Agap
shouldremainbetweentheoppositesidesofthehandrail
clamp.
Diagram4
6. Unwrapthereedswitchwire.Routetheconnectorand
wirethroughtheholeinthehandrailclamp.See
Diagram4.
7. Plug the connector into the receptacle as shown in
Diagram 4. Do not force the connection. The
connector is designed to engage in one direction only.
A tab on the connector and a slot on the receptacle
help you determine the proper alignment.
8. Align the back of the console with the mounting
bracket and slide the electronic console onto it. Gently
pull the excess wire through the hole in the handrail
clamp while you slide the console toward the rear of
the treadmill.
page 8
Diagram 5
9. AttachtheCclipsaroundthehandrailasshownin
Diagram5.PositiontheslightprotrusionontheCclip
aroundthereedswitchwireandmicro-adjustmentknob
cable.SqueezetheCclipstogethertoclosethemand
securethewiresinplace.
10. Withtheelectronicconsolesuccessfullymounted,continue
to
InstallingtheMountingPads
.
903
USA
R
page 9
904 Assembly Procedures
Toinstallthe904electronicconsole,takethefollowingsteps:
1. Removethehandrailclampfromitsbox.Takethelongand
shortscrewsoutofthehandrailclampusingyourfingersor
aPhillipsheadscrewdriver.Setthescrewsaside.
2. Position the handrail clamp over the right handrail’s
micro-adjustment knob as shown in Diagram 6. Place
a hand on either side of the handrail clamp to gently
pull it apart so that you can slide it onto the handrail’s
foam grip and into position (about 8 inches above the
base of the foam grip).
Important:Donotmounttheclamponthepaintedsurface
ofthehandrails.
Diagram 6
page 10
3. Insert the long screws through the mounting holes on
the clamp. See Diagram 7. You may need to squeeze
the ends of the clamp together to install the screws.
Tighten the screws using a Phillips head screwdriver
until the clamp remains securely in place. A gap
should remain between the opposite sides of the
clamp. See Diagram 7.
Note:Ifyouhavedifficultyholdingtheclamptogether,you
maywanttouseaCclamp(seeinsertonDiagram7)to
helpcompresstheclampendswhileyoutightenthe
screws.
4. Unlock and remove the mounting bracket from the
back of the electronic console. (Unlock the mounting
bracket by pushing it down toward the base of the
console.) Refer to Diagram 2 on page 6.
5. Positionthemountingbracketontothehandrailclampso
thatthesmoothsideoftheplateisfacingyou.Referto
Diagram7.Securethemountingbracketbyinsertingthe
twoshortscrews.Tightenthescrewsintotherecessed
holesonthemountingplateusingthePhillipshead
screwdriver.Donotovertightenthescrewsbecausetoo
muchpressuremaycracktheplasticmountingplate.
6. Unwrapthereedswitchwire.Thereedswitchwirehasa
connectorononeendandtheoblong-shapedreedswitch
ontheoppositeend.RefertoDiagram5onpage8.
Diagram 7
C clamp
