Premio CT-DBT0x Manuale utente

USER’S

MANUAL

CT-DBX0x

3.5” Industrial Single Board

Computer with Intel®

Celeron® J1900 Series

CT-DBT0X l User’s Manual

Table of Contents

Prefaces …………………………………………………….…………………………………………….04

Revision …………………………………………………………………………………………..……………….……….. 04

Disclaimer ………………………………………………………..…….…….………………………….……………….. 04

Trademarks Acknowledgment …………..……………………………………………………….................. 04

Environmental Protection Announcement …………………………….………………….…………..….. 04

Safety Precautions ………………………………………….……………………………….…………….……….... 05

Technical Support and Assistance …………………………………….…………….…………….………….. 06

Conventions Used in this Manual ………………………………………………………………….….………. 06

Chapter 1 Product Introductions ………………………………………………………..…07

1.1 Product Description ……….………………………………..………….………………..………. 08

1.2 Specifications ………………..………………………….....…………….…………..…..………… 09

1.3 Available Models …………………..……………………..…………………………………..…... 10

1.4 Block Diagram ………………………………..…………………………..………..……….………. 11

Chapter 2 Mechanical Specifications ….…………………..………………………..….12

2.1 Dimensions ……………………………….…………………………………..…….…..……..….... 13

2.2 Board Layout ……………………………………………………….……….…….………............ 14

2.2.1 Connectors & Jumpers ………………………………………………....……………… 14

2.3 Jumpers Definition ………….………..…............................................................. 15

2.3.1 Serial Port COM1 …………….…………………………………………....……………… 15

2.3.2 VGA Connector ………..…….…………………………………………....……………… 16

2.3.3 USB 3.0 Connector ……..……….……………………………………....……………… 17

2.3.4 USB 2.0 Connector ……..……….……………………………………....……………… 17

2.3.5 HDMI Connector ……..…..……………………………………………....……………… 17

2.3.6 LAN Connector ………..…………..……………………………………....……………… 17

2.4 Internal Connectors ………….……………........................................................... 18

2.4.1 Front Panel Audio Connector (AUDIO) ………….……………....……………… 18

2.4.2 Backlight Control Connector (CN1) …………………………………………..…… 18

2.4.3 COM2-4 Serial Ports (COM2-4) ………………………..……………………..….… 18

2.4.4 LPC Connector (DBG) ……………………………………………………………………. 19

2.4.5 Fan Connector (FAN) …………………………………………………………………….. 19

2.4.6 GPIO Connector: GPIO …….…………………………………………....………………19

2.4.7 Power Button Pin Header (JP3) ………….………………………....……………… 19

2.4.8 Reset Button Pin Header (JP4) ……………………………………....……………… 20

2.4.9 Reset Button Pin Header (JP6) ……………………………………....……………… 20

2.4.10 I2C Pin Header (I2C1) ………………………………………………....……………… 20

2.4.11 Multi-LED Pin Header (LED) ………………………………………...……………… 20

2.4.12 LVDS Connector: LVDS ……………………………………………….……………….. 21

2.4.13 microSD Coonector (MICRO_SD) ………………………………………………… 21

2.4.14 Mini-PCIe Slot #1 (PCIE1_MSATA) ……………………………...……….……… 22

2.4.15 Mini-PCIe Slot #2 (MINI_PCIE1) …………………………….…………….…….. 23

2.4.16 ATX Power Connector (POWER_CONN) …………………...………………… 23

2.4.17 PS/2 Keyboard/Mouse Connector (PS2) …………………….……………….. 23

2.4.18 SATA Signal Connectors: SATA1_2 …………………………………………..…… 24

2.4.19 SATA Power Connectors (SATA1/2_PWR) …………………...………….…… 24

2.4.20 USB 2.0 Pin Header (USB_1/2) ……….………………………….……………….. 24

CT-DBT0X l User’s Manual

2.5 Jumper Settings ………..…….……………............................................................ 25

2.5.1 Backlight Power (JP1) ………….………………………………………..……………… 25

2.5.2 Panel Power (JP2) ……………….………………………………………..……………… 25

2.5.3 Clear CMOS (JP8) ………….…….………………………………………..……………… 25

Chapter 3 Features & Interfaces ………………………………………………………..…26

3.1 Processor ……………………….………………………………..………….………………..………. 27

3.2 BIOS ……………………………..………………………….....…………….…………..…..………… 27

3.3 System Memory ……….…………..……………………..…………………………………..…... 27

3.4 Graphics ………………………………………..…………………………..………..……….………. 27

3.5 USB ……………………………….………………………………..………….………………..………. 27

3.6 Ethernet ……..………………..………………………….....…………….…………..…..………… 27

3.7 SATA ………………..……….…………..……………………..…………………………………..…... 27

3.8 Audio ………………………………..…………..…………………………..………..……….………. 27

3.9 Expansion ……………………..………………………….....…………….…………..…..………… 28

3.10 General Purpose Input Output ……………………..…………………………………..…... 28

3.10.1 GPIO Configuration ……………………..……….………………………………..…... 28

3.11 Watchdog Timer ………………..…………..…………………………..………..……….………. 29

3.11.1 Board Design ……………..………………..……….………………..……………..…... 29

3.11.2 Psuedo Code ……………..………………..……….……………………..………..…... 29

Chapter 4 Driver Installation ….…………………..………………..……………..…..…. 30

Chapter 5 System BIOS ….…………………………..………………..……………..…..…. 32

5.1 Advanced ……………………………….…………………………………..……….…..……..….... 33

5.1.1 ACPI Settings …………….…………………………………………....…………………… 34

5.1.2 F81866 Super IO Configuration ………..…….………………..…………..……… 34

5.1.3 Hardware Monitor ……..……….……………………………………....……………… 36

5.1.4 Serial Port Console Redirection ……..……….……………....………………..… 36

5.1.5 CPU Configuration ……..……………………………………………....…………..…… 37

5.1.6 SATA Configuration …………..……………………………………....……………….… 38

5.1.7 Miscellaneous Configuration …………….………………………....……………… 38

5.1.8 LPSS & SCC Configuration ………..…….………………..………………………….. 39

5.1.9 Network Stack Configuration ……..……….…………………....………………… 39

5.1.10 CSM Configuration ……..……….………………………….………....……………… 40

5.1.11 SDIO Configuration ……..………………………..…………………....……………… 41

5.1.12 USB Configuration …………..…………………..……………….…....……………… 42

5.1.13 Security Configuration …………..……..…………………………....……………… 43

5.2 Chipset ………….………………………………........................................................... 44

5.2.1 Northbridge Configuration …………..……………………………....……………… 44

5.2.2 Southbridge Configuration …………..……………………………....……………… 47

5.3 Security …….……………………..……………........................................................... 48

5.3.1 Security Boot Menu …………..………..……………………………....……………… 49

5.4 Boot ……………..………………………………........................................................... 50

5.5 Save and Exit …………………………………........................................................... 50

Chapter 6 Address Map ….…………………………..………………..……………..…..….51

6.1 I/O Port Address Map ……………………………..…………………..……….…..……..….... 52

6.2 Interrupt Controller (IRQ) Map ……..……………………..……..……….…..……..….... 55

6.3 Memory Map ……………………….………………..…………………..……….…..……..….... 63

CT-DBT0X l User’s Manual

Revision

Disclaimer

All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio

Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The

information in this document is subject to change without notice and does not represent a commitment on

the part of Premio Inc.

Premio Inc. disclaims all warranties, express or implied, including, without limitation, those of

merchantability, fitness for a particular purpose with respect to contents of this User’s Manual. Users must

take full responsibility for the application of the product.

electronic or mechanical, including photocopying, recording, or information storage and retrieval systems,

TrademarksAcknowledgment

Intel®, Celeron® and Pentium® are trademarks of Intel Corporation.

Windows® is registered trademark of Microsoft Corporation.

AMI is trademark of American Megatrend Inc.

IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business Machines Corporation

All other products and trademarks mentioned in this manual are trademarks of their respective owners.

EnvironmentalProtection Announcement

Do not dispose this electronic device into the trash while discarding. Please recycle to minimize pollution

and ensure environment protection.

Prefaces

Revision Description Date

100 Initial release 2015/04/13

110 Correct USB_1/2 connector drawing;

POWER_CONN & COM2-4 connector descriptions 2015/05/06

120 Modify COM_2/3/4 connector table and drawing 2015/12/08

130 Remove E3827 sku 2020/07/22

Preface

CT-DBT0X l User’s Manual

Safety Precautions

Before installing and using the equipment, please read the following precautions:

⚫Put this equipment on a reliable surface during installation. Dropping it or letting it fall could

cause damage.

⚫The power outlet shall be installed near the equipment and shall be easily accessible.

⚫Turn off the systempower and disconnect the power cord from its source before making any

installation. Be sure both the systemand the external devices are turned OFF. Sudden surge

⚫of power could ruin sensitive components. Make sure the equipment is properly grounded.

⚫When the power is connected, never open the equipment. The equipment should be opened

only by qualified service personnel.

⚫Make sure the voltage of the power source is correct before connecting the equipment to the

power outlet.

⚫Disconnect this equipment from the power before cleaning. Use a damp cloth. Do not use

liquid or spray detergents for cleaning.

⚫Avoid the dusty, humidity and temperature extremes.

⚫Do not place heavy objects on the equipment.

⚫If the equipment is not used for long time, disconnect it from the power to avoid being

damaged by transient over-voltage.

⚫The storage temperature shall be above -40°C and below 85°C.

⚫The computer is provided with a battery-powered real-time clock circuit. There is a danger of

explosion if incorrectly replaced. Replace only with the same or equivalent type

recommended by the manufacturer.

⚫If one of the following situation arises, get the equipment checked be service personnel:

•The power cord or plug is damaged.

•Liquid has penetrated into the equipment.

•The equipment has been exposed to moisture.

•The equipment does not work well or it cannot work according the user’s manual.

•The equipment has been dropped and damaged.

•The equipment has obvious signs of breakage.

Preface

CT-DBT0X l User’s Manual

Technical Support and Assistance

1. Visit the Premio Inc website at www.premioinc.com where you can find the latest information about

the product.

2. Contact your distributor, our technical support team or sales representative for technical support if

you need additional assistance. Please have following information ready before you call:

⚫Model name and serial number

⚫Description of your peripheral attachments

⚫Description of your software (operating system, version, application software, etc.)

⚫A complete description of the problem

⚫The exact wording of any error messages

Conventions Used in this Manual

Preface

This indication alerts operators to an operation that, if not strictly observed,

may result in severe injury.

WARNING

This indication alerts operators to an operation that, if not strictly observed,

may result in safety hazards to personnel or damage to equipment.

CAUTION

This indication provides additional information to complete a task easily.

NOTE

Chapter 1

Product Introductions

CT-DBT0X l User’s Manual

1.1 Product Description

The CT-DBT0x is a single board computer in 3.5” SBC form factor featuring the Intel® Celeron® J1900

Series in FCBGA1170 package on 22nm process technology in a single chip solution. One 204-pin

SODIMM sockets supports non-ECC/unbuffered DDR3L 1333MHz memory up to 4GB. The Intel® HD

graphics controller integrated within the processor supports three independent displays (VGA, HDMI,

LVDS). The CT-DBT0x supports 2x Gigabit Ethernet, USB 3.0/2.0, COM, GPIO, 2x Mini-PCIe slots,

microSD card SIM card to support a variety of industrial applications.

Chapter 1: Product Introductions

CT-DBT0X l User’s Manual

Chapter 1: Product Introductions

1.2 Specifications

Processor

•Intel® Celeron® Processor J1900 (2.0GHZ/4C/10W)

System Memory

•One 204-pin DDR3L SODIMM socket

•Non-ECC/unbuffered

•Data transfer rates up to 1333MT/s

•Memory sizeup to 4GB

BIOS

•AMI uEFI 8MB SPI flash

Graphics

•Intel 7th generation graphics and media

encode/decode engine

Ethernet

•2 x Intel I210IT GbE Controller

Audio

•Realtek ALC886

Watchdog Timer

•H/W Reset, 0 –255 steps

•Step = 1 sec. or 1 min

H/W Monitor

•Voltages monitoring

•Temperature monitoring

•Smart fan supported

TPM

•TPM1.2 supported (Optional)

Mechanical & Environmental

•Dimension:146mm x 102mm

•Power Input: DC +12V input

•Power Management: ACPI 5.0 compliant

•Operating Temp: -20°C ~ 70°C

•Storage Temp: -40°C ~ 85°C

•OperatingHumidity: 10% ~ 90% relativehumidity,

non-condensing

I/O

•Internal I/O

1 x 2-ch 24bitLVDS

1 x SATA 2.0

3 x RS-232/422/485

4 x USB 2.0

1 x Line-In, Line Out & Mic-In

1 x 8-bitGPIO

1 x PS/2 keyboard mouse

1 x microSD card socket

1 x SIM card socket

1 x FAN connector

•Rear I/O

1 x HDMI

1 x VGA

1 x RS-232/422/485

1 x USB 3.0

1 x USB 2.0

2 x GbE

•Expansion

2 x Full sizemini PCIeslot(CT-DBT01)

1 x Full sizemini PCIeslot,1 x mSATA (CT-DBT02)

•Storage Temp.

-40°C ~ 85°C, 95% (non-condensing),Non- operating

•RelativeHumidity

10% ~ 90% relativehumidity,non-condensing

ORDERING INFORMATION

Packing List

•1 x COM port cable

•1 x PS/2 cable

•1 x SATA cable

•1 x Power cable

•1 x Driver DVD

Ordering Information

•CT-DBT0X-J1900

w/ Intel® Celeron® Processor J1900

(2.0GHz/10W)

CT-DBT0X l User’s Manual

1.3 Available Models

Chapter 1: Product Introductions

Model No. Processor Ordering Information Part Number

CT-DBT01

Celeron® J1900

-DBT01-J1900

-DBT0104S100-P0

CT-DBT02

Celeron® J1900

-DBT02-J1900

-DBT0204S100-P0

Mini PCIe slot #1 Mini PCIe slot #2

-DBT01

PCIe

x1 only

PCIe x1 & USB 2.0

-DBT02

mSATA only

PCIe

x1 & USB 2.0

Mini PCIe Slot BOM Options

Indice

Altri manuali Premio Computer a scheda singola

Premio

Premio CT-DWL01 Manuale utente

Manuali Computer a scheda singola popolari di altre marche

WIN Enterprises

WIN Enterprises PL-80910 Manuale utente

AXIOMTEK

AXIOMTEK SBC81206 Series Manuale utente

Embest

Embest SOM-PH8800 Manuale utente

SeaLevel

SeaLevel SBC-R9 Manuale utente

SMART Embedded Computing

SMART Embedded Computing ATCA-8310 Manuale utente

WinSystems

WinSystems PPM-LX800-G Manuale utente

GIGAIPC

GIGAIPC QBiX-PPC Series Manuale utente

OLIMEX

OLIMEX A10S-OLinuXino-MICRO Manuale utente

Commell

Commell FS-978 Manuale utente

GIGAIPC

GIGAIPC QBiP-8665A/ Manuale utente

VersaLogic

VersaLogic Python EBX-11 Manuale utente

Micro Computer Specialists

Micro Computer Specialists IRV-3702 Manuale utente

CompuLab

CompuLab SB-A510 Manuale utente

Boser

Boser HS-7321 Manuale utente

Premier Farnell

Premier Farnell Embest SBC8530 Manuale utente

MicroSys Electronics

MicroSys Electronics miriac SBC-LS1043A2 Manuale utente

Aaeon

Aaeon UP Manuale utente

Portwell

Portwell WUX Series Manuale utente
