Service Manual

Important Safeguards

TABLE OF CONTENTS

Specification

Safety Precautions

The Cooling System

Wire Diagram

Changing the Reversing Door

Changing the Bulb

Trouble Shooting

SPECIFICATION

Models

PRF735HW/ PRF736HS/ PRF737HB

Capacity

7.4 cu.ft.

Power Supply

115V/60Hz

Rated Input Power

120 W

Rated Current

1.5A

Rated Power of Lamp

10 W

Refrigerant/Amount

R600a / 1.48 oz

Net Weight

92 lbs

Unit Dimension (HxWxD)

56”x 21 1/2”x 22 3/4”

Package Dimension (HxWxD)

58”x 22 5/8”x 237/8”

Loading QTY(40HQ)

142 pcs

SAFETY PRECAUTIONS

The installation of this appliance is best carried out by 2 people.

Dispose of all packaging carefully and responsibly.

The appliance is designed for indoor use only and must be protected from rain, moisture

and extreme temperature variations.

This appliance is designed for household use. Do not use the appliance for industrial and

commercial use, or any other purpose.

The appliance MUST be positioned on a firm level base.

Do not splash water on the appliance. It may cause electrical parts to fail and result in an

electric shock.

Leave the appliance in its intended place of installation and in its correct orientation for at

least 4 hours before switching on to allow the cooling system to settle before first use or

after any transportation.

This appliance is an environmental friendly product and it contains non CFC / HFC gas

substances in the cooling system (Called R600a) and in the insulation (Called

cyclopentane) which are potentially flammable if exposed to fire. Therefore, take care not

to damage, the cooling circuit / pipes of the appliance in transportation and in use. In case

of damage do not expose the appliance to fire, potential ignition source and immediately

ventilate the room where the appliance is situated.

Do not sit, stand or place any other heavy objects on top of the appliance. This could

result in injury or damage to the appliance.

Do not allow children to play with the appliance to avoid the risk of entrapment and

suffocation.

Keep ventilation opening, in the appliance enclosure or in the built-in structure, clear of

obstruction

This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless they

have been given supervision or instruction concerning use of the appliance by a person

responsible for their safety. Children should be supervised to ensure that they do not play

with the appliance.

This appliance is not intended for use by young children or infirm persons unless they

have been adequately supervised by a responsible person to ensure that they can use the

appliance safely. Young children should be supervised to ensure that they do not play

with the appliance.

Do not use mechanical, electrical or chemical way to speed up the defrost process not

recommended by the manufacturer.

Do not use or place other electrical products inside the appliance not recommended by

the manufacturer.

Do not store liquids in glass containers in the freezer compartment as these may shatter.

Do not store flammable materials such as alcohol, gasoline, LP gas or glue etc in the

appliance.

In case there is an inflammable gas leaking, open the window for air circulation and do

not pull out the plug or turn the temperature knob. Do not touch the appliance until the

valve of gas is turned off. Otherwise, sparks may happen.

COOLING SYSTEM

WIRE DIAGRAM

CHANGING THE REVERSING DOOR

Before reversing the door swing, ensure the appliance is unplugged and empty. Provide

additional support for the doors while hinges are being removed.

Do not depend on the door magnets to hold the door in place. It is recommended that two

people perform this task. DO NOT lay the appliance completely flat as this may damage the

coolant system.

TOOLS REQUIRED

Phillips style screwdriver / Flat bladed screwdriver / Hexagonal spanner

1. Tilt the unit slightly towards the rear and

prop it securely. Two people are

required to tilt the unit during the door

reversal process.

2. Remove the 2 screw covers first,

then undo the screws underneath.

3. Remove the 2 screws on the back.

4. Lift the top cover away from the fridge.

5. Remove the three screws, then

remove the upper hinge that hold the

door in place. Lift the door and place

it on a padded surface to prevent it

from scratching.

6. Remove the bolt with a screwdriver and

flip the hinge bracket. Then reattach the

bolt to the hinge bracket.

180°

unscrew

7. Take off the middle hinge by

removing the screws. And then lift

the lower door and place it on a

padded surface to prevent it from

scratching.

8. Move the hinge hole cover of lower

door from left side to right side.

9. Remove the screws and bottom hinge.

Then remove the adjustable feet from

both side.

Unscrew

10. Unscrew and remove the bottom

hinge pin, turn the bracket over and

replace it.

Unscrew

Screw

11. Refit the bracket fitting the bottom

hinge pin. Replace both adjustable feet.

Transfer the lower door to the property

position.

Screw

12. Make the middle hinge reverse the

direction 180°C, then transfer it to the

left property position. Make the middle

hinge pin in the upper hole of the lower

door, then tight the bolts.

Ensure the freezer door is aligned

horizontally and vertically, so that the

seals are closed on all sides before

finally tightening the hinge.

13. Place the upper door back on. Ensure

the fridge door is aligned horizontally and

vertically so that the seals are closed on

all sides before finally tightening the top

hinge.

14. Insert the hinge bracket and screw it

to the top of the unit.

15. Use a spanner to tighten it if necessary.

16. Put the top cover and then screw back.

17. With the doors closed, check that the

doors are aligned horizontally and

vertically and that the seals are closed on

all sides before finally tightening the

bottom hinge. Re-adjust the levelling feet

as needed.

screw

REPLACING THE BULB

Unplug the AC power cord from the wall.

Remove the screw that holds the light bulb cover.

Remove the light bulb cover.

Unscrew the bulb.

Replace with a 10 watt bulb that is the same shape and size.

Replace the light bulb cover

TROUBLESHOOTING GUIDE

PROBLEM

POSSIBLE CAUSE

Unit does not operate.

Not plugged in.

The circuit breaker tripped or a blown fuse.

The unit temperature control is set at “0” position.

Turns on and off frequently.

The room temperature is hotter than normal.

A large amount of food has been added to the

unit.

The door is opened too often.

The door is not closed completely.

The temperature control is not set correctly.

The door gasket does not seal properly.

The unit does not have the correct clearances.

Vibrations.

Check to assure that the unit is level.

The unit seems to make too much noise.

The rattling noise may come from the flow of the

refrigerant, which is normal.

As each cycle ends, you may hear gurgling

sounds caused by the flow of refrigerant in your

unit.

Contraction and expansion of the inside walls

may cause popping and crackling noises.

The unit is not level.

The door will not close properly.

The unit is not level.

The door was reversed and not properly installed.

The gasket is dirty or bent.

The shelves, bins, or baskets are out of position.
