Primera CX1200 Pre?Die Cut Guida rapida

1



Section1:UpdatetheHardware



Thefollowingitemsareincludedinthisupgradekit:

•InstallationDisc

•ReplacementMPFeederDoorwithintegratedblackmarksensor.

•InstallationInstructions

1.Disconnectthe6‐pinminidincablefromtheMPFeederdoor.

 

2.Remove4Phillipsscrewsthatsecurethecircuitboardaccesscover.Besuretokeepthescrewtothe

blackplasticdoorholderstrap.

3.Removetheblackcablefrom

circuitboard.Useaflatscrewdriver

topushbackthecatchsothatthe

connectorcanberemoved.



CX1200Pre‐DieCutUpgradeInstructions

511321‐021412

2



4.Pullthecableoutoftheplastichookneartheprinter.



 

5.Oncetheblackcableandthe6‐pinminidincablearedisconnected,youcanremovethedoor.Press

thegraybuttonnearthebackoftheprinter.Liftupthebacksideofthedoorfirsttoremoveit.

6.LocatethereplacementMPFeederDoorwithintegratedblackmarksensor.



 

7.Remove5Phillipsscrewsthatsecurethecircuitboardaccesscoverandthemetalsensorguard.



3



8.Attachthereplacementdoortotheprinter.Connectthefrontsidefirst.





9.Connectthebacksideofthedoorbypressingthegreybuttonagainandsnappingthepegintothe

correspondingholeontheprinter.Makesuretheblackcableandtheblackplasticdoorholderstrapare

abovethedoorbeforeyouattachitontheprinter.

10.Routetheblackcableasshownandconnectittothecircuitboard.

 

11.Replacetheaccesscoverandthemetalsensorguard.Connecttheblackplasticdoorholderstrap.

12.Reconnectthe6‐pinminidincable.



4



Section2:UpdatetheSoftware

Updatesoftwarefromthewebsite‐http://www.primeralabel.com/support/cx1000.htmlorinsertthe

installationdiscthatyoureceivedwiththeupgradekit.BrowsetothediscthroughMyComputer.There

arethreeseparateupdatefilesthatshouldberun.

1.Firmware

RuntheCX1200FWUpdater.exetoupdatethefirmware.Thefollowingwindowwillappear.Click

Updatetoupdatethefirmware.



2.StatusMonitor

RuntheCX1200v1.8.0StatusMonitor.exetoupdatetheStatusMonitor.



3.PTPrint



1.RunthePTPrint‐012712.exetoupdatePTPrint.Followthepromptsandchoosethedefaultoptions

exceptfortheitemsmentionedbelow.

2.Youwillbepromptedtoenterthelocationofthelicensefiles.BrowsetoC:\PTPrint.



5



3.Choose“No”whenpromptedaboutusingyourexistingconfigurationfile.





4.Finally,chooseFULLInstallfortheinstallationtype.

5.Thisinstallationwilltakeseveralminutestocomplete.





6



Section3:PrintingtoPre‐DieCutStock.

1.ToopenPTPrintgotoStart‐AllPrograms‐PTPrintfolder‐PTPrintorclickthePTPrinticononyour

desktop.



2.Theprintlayoutwizardwillappear.ClicktheBrowsebuttontofindthelabelyouwanttoprint.The

followingformatsaresupportedviatheprintlayoutwizard:BMP,EPS,JPG,GIF,PCX,PNG,TIFF.



3.Oncethegraphichasbeenselectedthesize

anddpiwillautomaticallyappearinthefields

below.Thegraphicshouldbe300dpior

greatertoachievethebestquality.Resolutions

above300dpiarenotnecessaryandonlyserve

toincreasethefilesize.Adjustthelabelsizeas

necessary.Bydefault,aspectratiowillbe

maintained.TheDPIwillbeincreasedifyou

decreasethesizeofthelabel.



4.Makesure“UsingPre‐diecutstock”hasbeen

checked.



DesignTip!Designyourlabelwiththe.125”bleedincluded.Thiswillincreasethesizeofyourgraphic.

Forexample,ifyouwantyourfinallabeltobe3”x4”,designyourlabeltobe3.125”x4.125”.Addinga

bleedisNOTthesameasincreasingthesizeofyourimage.Typicallyyouwouldaddableedtoanimage

bydoublingthesizeoftheborderaroundtheimageinyourdesignprogram.









NoBleedWithBleed

CutPosition

7



5.IfyouhavepurchasedPrimeraPre‐diecutstock,youwillfindastockstickerattachedtoeveryrollof

pre‐diecutlabelstock.



6.Matchthevaluesonthestockstickerwiththecorrespondingvaluesinthesetupwizard.



7.OnceyouhavechosentheimportedgraphicandtheStep&Repeatcolumnsareset,clickOKtoview

thelayout.

8.SavetheFile.GotoFile‐Save.

9.Beforeprintingmakesurethat“UsingPre‐diecutstock”ischeckunderthesettingstabofthestatus

monitor.



10.ClickFile‐Print.

StockSticker

SetupWizard

8



Section4:AdjustingPrintOffsets

Usethefollowingtabletodiagnoseprint

offsetproblems.Beforeadjustingany

offsetsmakesureyouhaveenteredthe

correctlabelsize,verticalspacing,and

horizontalspacinginthePTPrintlabel

setupwizard.Offsetscanbeadjustedon

theoptionstabofthestatusmonitor.

Onlyverticaloffsetscanbeadjustedwhile

theprinterisprinting!





Problem:

ImageisoffsettotheleftorRight.



Solution:

AdjustVerticalOffset.Measuretheoffsetamount

accountingforthebleed.Adjustinthedirection

indicatedusingtheoffsetadjustmentsonthe

optionstaboftheStatusMonitor.



Cut(BlackLine)

PrintedImagewith

bleed(GrayArea)

FeedDirection

FrontofPrinter

‐

9



+

‐



Problem:

Imageisoffsettothebackorfront.



Solution:

AdjustHorizontalOffset.

Measuretheoffsetamount

accountingforthebleed.

Adjustinthedirectionindicated

usingtheoffsetadjustmentson

theoptionstaboftheStatus

Monitor.

Problem:

Imageisoffsetbothfrontorbackandleftorright.



Solution:

AdjustHorizontalandVerticalOffset.Measurethe

offsetamountaccountingforthebleed.Adjustin

thedirectionindicatedusingtheoffsetadjustments

ontheoptionstaboftheStatusMonitor.



Problem:

Imageistooshort/narrowortall/wideforthecut.



Solution:

TheimagesizemaynotbesetcorrectlyinPTPrint.



Problem:

Imageslinesupwithcutontherightsideofthe

pagebutgetsgraduallyworseasitmovesleft.



Solution1:

PrinterStretchCalibrationisrequired.



Solution2:

ImagesizemaynotbesetcorrectlyinPTPrint.

10


