Pro-Ject Audio Systems X1 Manuale utente

1Unpack all items from accessory bag. 2Remove dust cover carton from the box. 4

Lift the wrapped turntable out of the box.

5Unpack the acrylic platter. 7Put the drive belt on the pulley

& sub-platter. 8Put the platter on the turntable.

9Remove tonearm twist tie. 10 Put the counterweight in place. 11 Lower the tonearm lift and place the

tonearm between platter & armrest.

Balance the tonearm by turning the

counterweight until it stays level.

13 Turn the front scale of the counterweight

to Zero without moving the weight itself.

14 Turn the counterweight counterclockwise

until the scale reads roughly 18.

15 Put the needle protection cover back

on the cartridge.

X1 Setup Guide

Please read before unpacking.

Getting started:

Make sure you have enough space to unpack your turntable.

Always unpack and setup in a clean enviroment

Important for warranty: Do not throw packaging away.

counterweight

Connect it E

RCA cable

single adapter

& Allen key

drive belt

Antiskating

Weight

3Unpack the power supply.

6Carefully remove the protection covering.

Remove the needle protection cover.

Put the loop of the Antiskating Weight

in the second groove on the tonearm

17 Unpack Dust Cover and put it on

the turntable.

18 Plug in power supply and Connect it E.

19 Connect to your sound system and you

are ready to enjoy your records!

Small pulley- 33/45 RPM

Big pulley - 78 RPM (round belt)

0°

www.project-audio.com/en/products/x1

Technical Data

Speed

Principle

Speed cariance

Wow & utter

Platter

Main bearing

Tonearm

33, 45, 78 (electronic speed change)

belt drive

33: 0.30% 45: 0.25%

33: 0.15% 45: 0.13%

20mm thick, 1.5 kg heavy acryl

stainless steel/brass

8,6” carbon/aluminium sandwich

Eective arm length

Overhang

Eective tonearm mass

Tracking force range

Power consumption

Dimensions

Weight

218,5 mm

18 mm

10,0g

0 - 30mN

5,0 watts max /< 0.3 watt standby

415 x 125 x 335 mm (WxHxD)

7 kg net / 9.5 kg gross weight

gloves

Tonearm is fragile!
