MT-7602 USER'S GUIDEMT-7602 USER'S GUIDE

4 IN 1Fiber Optic PowerMulti-Meter4 IN 1Fiber Optic PowerMulti-Meter

English

USER'S GUIDE

4 IN 1Fiber Optic PowerMulti-Meter

WARNINGWARNING

You arecautioned that changesor modifications not espressly

approved in thisdocument could void yout authority tooperate this

equipment.To reducethe risk of fire or electric shock,donot expose

this apparatus torain or moisture.To avoid electricalshock, do not

open the cabinet.Refer servicing to qualified personnel only.

Precautions for Use

Use batteries

At the sametime, can not use different styleor different

capacitance batteries. Andonly charge the rechargeablebatteries.

Avoiding condensation problems

As much aspossible, avoid sudden temperature changes. Donot

attempt to usethe drive immediately after moving itfrom a cold

to a warmlocation, to raising the room temperaturesuddenly,

as condensation may formwith in the drive.If the temperature

changes suddenly while usingthe drive, stop usingit and take

out batteries forat least an hour.

Storage

When long timeno use,must take out the batteriesto avoid

destroying the device.

3-VFL optic adapter

2-LED

1-InGaAs detector(FC/UPP)

4-LCD

5-Wavelength Select Button

6-Glint@VFL and Unit@VFL Function Button

7-Switch/Function Select Button

8-Network cable LED

9-MiniUSB Charging Socket

10-RJ45 TestingSocket

10 11

11-RJ11 TestingSocket

Description

12345678

FUNC

GLINT

UNIT

1.Pull the battery coverlock 2.Raise the batterycover

3.Installing the batterycorrectly 4.Push the battery coverand lock

Installing the battery

1 2 345 6 78

FUNC

GLINT

UNIT

On/Off and Permanent On

Press button will turnon the meter. Press

button again fortwo seconds ormore will turn off the

meter.

This meter hasa power-saving function, normal boot

and ten minuteswithout any operation,the device will

automatically shut down. If you needto shield this

function and enablethe meter keepson working, only

need to pressthe button and holdwhen you

boot the instrument.After twoseconds, the meter

display will show"PERM" which meanspermanent power

on.

FUNC

1 2 345 6 78

FUNC

GLINT

UNIT

Function Selection

Optical Power Meter

Visual Fault Locator

Flashlight

Network cable/

Telephonewire Testing

After booting,the default functionis the optical

power meter.Press button, you cancycle

through switch toOptical Power Meter, VFL,

Flashlight, Network cable/Telephone wire Tester.

FUNC

Long press button until the LCD shows up

REF words, you canset the currentpower value as

a reference value.Long press button , and

when the screendisplay REF , you can check the REF

value.

GLINT

UNIT

12345678

FUNC

GLINT

UNIT

Optical Power Meter

GLINT

UNIT

As opticalpower meter,press button can

select different wavelengthsto measure. This meter's

standardized wavelengths are850nm, 1300nm, 1490nm,

1550nm, 1625nm. Theunit displayed is mW / uW value

and dBm value,which can switchthrough pressing

button.

GLINT

UNIT

Optical Power Meter

1 2 345 6 78

FUNC

GLINT

UNIT

Visual Fault Locator

GLINT

UNIT

As avisual fault locator, press button, you

can choose thelaser remains onor flashing. In the flashing

state, the screendisplay identifier , and the

flashing frequency is2Hz.

GLINT

UNIT
