PROAIM DL-ANCR-02 Manuale utente

1

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything

that is listed below.

All rights reserved.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable

copyright statutes or in wring by the Publisher.

Anchor Heavy-duty Dolly (DL-ANCR-02)

Assembly Manua l

Anchor with Studio wheels

3 x Safety Belts

2

Anchor Dolly Setup

 Loosen the knobs from the centre of dolly and

spread it on the oor. Then ghten the knobs

of dolly again to secure appropriately.

NOTE: To keep the dolly in a stac posion

(non-movable), lock down the wheels by using

provided brakes.

 Take out the allen bolts from the dolly &

remove the studio wheels. Repeat this

process for all the studio wheels.

 Insert the track wheel onto the dolly, then

ghten the allen bolts as a shown in the

image.

FOR ATTACHING TRACK WHEELS

(Not Included)

 Your Dolly with Track wheels will look like as

shown in the image.

 Now mount the stand on dolly, insert the

strap between the dolly & stand as shown in

the image.

3

Euro Mount

 Universal standard Euro/Elemac mount

threads are available on dolly. You can mount

any Euro base accessories like bazooka risers

and mount the camera setups.

YOUR PROAIM ANCHOR HEAVY-DUTY STUDIO CAMERA TRIPOD DOLLY

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period

of me, we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon

costs nor does it cover a product subjected to misuse or accidental damage. Warranty repairs are

subjected to inspecon and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from

mishandling in transit, accident, misuse, neglect, lack of care of the product, or service by anyone

other than our company.

Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise

our utmost support and care unl you use our product.

 Press the strap buon, pull out the strap and

insert the strap-end into the strap rest.

NOTE: To protect your equipment, safety straps must be

used for addional security.
