PROAIM Victor Pro Manuale utente

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Victor Pro Video Producon Camera Cart (CT-VCTR-PRO-48)

Assembly Manua l

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

What’s In The Box

Lower Shelf

2 x Crossbars

2 x Hinge Handle

Allen key L– Type, 4 x Screws

Top Shelf

Carrying Handle

4 x Knobs

2 x Pneumac Tires Without

Break With Packing Pouch

2 x Pneumac Tires With

Break With Packing Pouch

Victor Pro Camera Cart Setup

• Open all the 4 locks which are on both sides

end of the cart.

• Unlock the re (With brake) by ipping the

knob.

4 x (31” Length) Rods With Packing

• Aer unlocking all locks, separate the upper

and lower shelf.

• Pull and ip the locking pin in upward direc-

on to open the locks.

NOTE: Two peoples are needed to assemble the cart.

Pneumac Tires With break

• The cart would look like this aer aaching

both the res (With break).

NOTE: To keep the cart in stac posion, lock

the wheels by pushing down the lever.

• Aach the unlocked re (With break) on

lower shelf’s dovetail bracket by sliding on it

as shown in the image.

• Flip the knobs to secure the aached re As

shown in image.

• Unlock the re (non break) by ipping the

knob.

• Aach the unlocked res (non break) on

lower shelf’s dovetail bracket by sliding as

shown in the image.

Pneumac Tires Without Break

• The cart would look like this aer aaching

both the res (non break).

• Tighten all the knobs provided at each corner

of the lower cart. So that all the rods are

properly aached to the cart as shown in the

image.

• Loosen the screw of the carrying handle with

the help of Allen key L-type as shown in im-

age.

• Now place the carrying handle on the side of

the boom shelf.

• Follow the same steps for all screw removal

before aaching it to lower shelf.

• Loose all the 4 knobs of lower shelf’s corner

hole and insert rod into it, as shown in image.

• Now, screw the carrying handle to lower shelf

with the help of allen key L-Type.

Rod

Carrying Handle

• Tighten all the 4 corner knobs of upper shelf

so that upper shelf doesn't fall down.

• Tighten knobs ghtly to set crossbar properly

on the rods.

• Now place the clamps of crossbar on rods, as

shown in image.

• Loosen the knob to open clamp of the cross-

bar.

• Now mount the upper shelf on the top of

the rods by aligning it in the corners.

• Follow same steps for all screws to check

whether they are properly set.

Upper Shelf

Crossbar

• Place handle clamp on the rod and adjust the

hinge handle accordingly.

• Follow same steps to aach second hinge

handle.

NOTE: It helps create the leverage needed while

liing the cart quickly over obstacles, stairs or

other incline surfaces.

• Follow the same step with second knob and

open the ap.

• Loosen the handle to open clamp of hinge

handle.

• Unlatch upper shelf’s ap by sliding the knob.

• The crossbar would look like this aer

aaching both clamps, as shown in image.

Hinge Handle

• The cart would look like this aer following all

the steps correctly.

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and

evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

support and care unl you use our product.

YOUR PROAIM VICTOR PRO VIDEO PRODUCTION CAMERA CART

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)
