PROAIM P-WV-2SD Manuale utente

Instruction Manual

7' Wave-2 Jib Crane, Dolly Stand for

Camera / Gimbals / Pan Tilt Heads

(P-WV-2SD)

Subject Page

Foreword 3

Introducon 4

Assembling 5-10

Warranty 11

At Proaim, our goal is to ensure 100% Customer Sasfacon in all that we do.

We back our sales with a 1 year warranty from the date of purchase and work hard

to resolve any problems in the unlikely event one should arise.

With our commitment to connuous improvement and your Feedback, building on

our reputaon of providing aordable, quality products is

PRIORITY #1.

Table of Contents

Dear Client,

On behalf of all the people that work so hard to provide you with the most

up-to-date, exible and cost-ecient producon gear, we would like to welcome

you into the Proaim family.

By purchasing your Proaim 7' Wave-2 Video Jib Crane With CST-100 Stand &

Portable Dolly you have just joined a host of designers, engineers, machinists,

assembly, customer service and oce sta that take great pride in all that they do.

Our mantra of connuous improvement has been the guiding principle of how we

conduct our business since day one.

Once you have the opportunity to experience your new Proaim 7' Wave-2 Video Jib

Crane, we hope you will agree that we cra quality products at a compeve price.

Products designed to meet and exceed the standards of today’s real producon

world.

Standards set by our valued clients and standards we strive to maintain.

With Best Wishes,

Proaim Team

Welcome To Proaim!

Introducon

PROAIM welcomes you to the new and modernized era with its Proaim 7' Wave-2

Video Jib Crane With CST-100 Stand & Portable Dolly , a portable lming

soluon to increase your producon value. The Robust jib crane is specically

designed travel crane for indoor & outdoor video producons. Its telescopic

arm feature adds exibility to frame perfect shots in indoor and outdoor spaces.

This video producon package includes a rugged camera dolly for smooth,

dynamic moving shots and rock solid aluminum tripod stand for immense support

Please inspect the contents of your shipped package to ensure you have received

everything that is listed below.

What’s In The Box

75mm Conversion

Ring

Cst-100mm Bowl Tripod Stand

Weight Rod with weight Closer

Proaim Portable Dolly (P-PRT-D)

Flate Base Plate

Bag packing

Wave-2 Jib Crane

Aluminum Spreader

100mm Bowl

Posion the height of the tripod by loosening all three adjustment knobs, sliding the tripod

up to the desired height and re-ghten the knobs securely.

In case of spreader, Take out the Spreader and spread it on oor and open the legs (as per

your requirement) of spreader with the help of provided knob.

You can use the Wave jib in 2 ways

Assembling

Now mount the Tripod Stand on Spreader, lock it in place with the rubber grips

Spreader Dolly

In case of Dolly, Take out the bolt from the center of dolly and spread it on oor. Then put

the bolt back through the center of dolly again.

Now mount the Tripod Stand on Dolly, lock it in place with the rubber grips.

NOTE: To keep the dolly in stac

posion, lock the wheels by pushing down

the lever.

Loosen the bolts of the hub secon and move the hub secon from their posion for proper

aaching, then again ghten the bolts to secure it.

Loosen the knob for the free lt movement of the camera plate, then aach the lower

secon of the jib as shown in the image.

Aaching the Lower telescopic jib secon.

Tighten the aaching 1st knob, the 2nd knob ghten properly for double security.

1st knob

2nd knob

Unscrew the locking lever from the Central Post of the jib. Place the Central Post in the bowl

of Tripod Stand and re-ghten the locking mechanism for a secure t.

NOTE: It is important to make sure that the Central Fork is seated in the bowl properly. That

means perpendicular to the tripod bowl. O axis installaon may hamper movement of the jib.

Also you may need the assistance of a grip stand to hold the camera end of the arm during

installaon prevenng it from falling as it will be front heavy at this point. You may also need

the grip stand or assistance at the rear of the jib when mounng the camera.

Provided are the jib panning control

knobs (as shown in the picture). Loosen

the knobs for the smooth pan

movement of the jib and ghten these

knobs to lock the pan movement of the

jib.

Unscrew the allen bolts to extend jib arm at back and reghten the allen bolts. Secure all the

connecons.

Insert the weight rod into the jib arm.

Now slide in weight to it as per your requirement and screw in weight closer

properly. (Counter weight Not Included)

NOTE: Make sure the opposite end of the jib arm is secured so that the addion of the weights

does not cause the arm to rise violently.

Mount your fluid head (Not included) onto the bowl plate in order to attach the camera (Not

included) . And then nally, secure your camera properly on the uid Head.

Loosen the bolts and remove the 100 bowl.

Attach the flate base plate and secure by tightening the bolts and then attach the Pan Tilt Head

(Not Included) and secure by tightening the bolts.

For an over slung setup, attach the flat base plate on the top and mount the camera setup and

secure the camera properly.
