PROAIM P-18-JS Manuale utente

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Central

Post

LCD Mounng Arm

Tools

18 Camera Crane Jib with Stand for Gimbals

Pan-Tilt & Fluid Head (P-18-JS)

A s s e m b l y M a n u a l

Jib Stand

Secon 1st

Secon 2nd

Secon 3rd

Secon 4th

Secon 5th

Weight Closer

Weight Rod

Accessory Wire Tensioner Knob

Slide Central Post of Jib onto the Jib Stand

and ghten knob-2 to secure it.

Jib Stand Setup

Open shank from central post. Leave the

black washers at one side help of wrench.

Insert the secon 4 inside central post then

Align holes of secon with central post to

screw in the shank back.

Then ghten the bolt properly with the help

of a wrench, and to aach secon 5 to 4,

loosen the bolt from secon 4.

Knob 2

Jib Secon Setup

Secon-5 has connecng bars aached with

secon-4 on both ends and then ghten

them together using provided allen key.

Connue the Arm build by sliding in secon 3

onto secon 4 as shown in the image.

Loosen the bolt from the connecng bar with

the help of a 6mm Allen key and wrench, and

then insert the bolt using the holes provided.

Then ghten them together using provided

allen key.

Connue the Arm build by sliding in secon 2

onto secon 3, and nally secon 1 onto sec-

on 2.

Connect the Wire/Cable Tensioner with

cable. Simply rotate the mid-secon handle

to ghten the cable adding required amount

of strength to the system.

Connecng Bar

Tighten Bolt

Then ghten them together using provided

allen key. As shown in the image.

Secure your camera setup with weight

closers as shown.

NOTE: Once you discover correct balance,

consider marking the weights for that parcu-

lar camera; facilitang an easier set up the next

me.

Aach LCD mounng arm onto central fork

then ghten the knob.

Lock the pin for keeping your camera in a

xed angle to take stable shots.

Insert weight rod of secon 5 then with a 1”

hole, according to your camera setup

requirements. Secure them with Weight

Closers.

NOTE: The Central Fork has provision to attach

LCD Monitor (Not Included) via LCD Mounng

Arm.

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.

YOUR PROAIM 18 CAMERA CRANE JIB WITH STAND FOR GIMBALS, PAN-TILT & FLUID HEAD

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)
