PROAIM P-CBTR-01 Manuale utente
1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Cube Trio-Reector w Reversible Silver/White
Reector Panels (P-CBTR-01)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
3 x Reversible silver / white reector
2 x Reector Arm
1 x T-Bar
2 x Standard
Adaptors
Spigot Mul Angle
Adapter 12 Quick Clips
(16mm)
4mm, 2.5mm Allen Key
Assemb ly Manua l
2
• Aer mounng the T-Bar, secure it by
ghtening its knob.
• Now, loosen the knob of the Reector arm.
• Aach the Reector arm with the T-Bar.
• Repeat the same process with the second
Reector arm.
• Aer aaching the Reector arm, ghten
its knob to secure the arms properly.
• Loosen the adapter from the Reector arm.
• Set the adapter per your requirement and
ghten it.
Cube Trio-Reector Setup
• Loosen knob of the T-Bar and mount it a
C-Stand (Not Included), as shown in the
image.
• The Reector arm can be moved per your
requirement.
3
• Aach the Quick clips to the Reector and
secure them using the bolts from the
backside.
• Aach the Reector with the reector arm,
as shown in the image.
NOTE: Quick clips are included on both panel
sides for mounng the reector arms.
• The reversible silver/white Reector has a
mul-angle adapter for posioning at any
angle.
Feature: The Silver Fabric is more reecve.
The white cloth removes uncorrected glare
from the subject.
• Loosen the knob of the Mul adaptor and
mount it on the standard adaptor.
• Remove bolts from the Quick clips, as shown
in the image.
• Loosen the knob of the standard adapter
and mount it on the C-Stand (Not Included).
• Now, secure it by ghtening back the knob.
Feature: The reector ts standard 5/8 light
stands and c-stands with its compable baby
pin receiver.
4
• Now, insert the Spigot in the mul-adapter.
• Aer the inseron, secure it by ghtening
the knob.
• Mount the T-bar with the Reector arm on
the Spigot.
• Aer mounng on the Spigot, ghten the
knob and loosen the adapter for the
movement of the Reector, as shown in the
image.
• Aer mounng the Mul adaptor, secure it
using the knob.
• The setup is fully assembled.
Feature: The Reector can be mounted
separately or all three together with 360°
panel orientaon, allowing you to set panels
horizontally, vercally, single panels in a row,
or at any angle without moving the enre
setup.
5
YOUR PROAIM CUBE TRIO-REFLECTOR W
REVERSIBLE SILVER/WHITE REFLECTOR PANELS
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
