PROAIM RCSW-CM Manuale utente

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

Camera Arm Mount Kit for Magnus Rickshaw (RCSW-CM)

Assembly Manua l

2 x Sliding Rod

Main Rod

Mounng Clamp

Support Bracket with Clamp

 Insert the sliding rod into the outer locking

lever of the main axle of the Rickshaw.

 Once the rod is inserted, ghten the knob to

secure it.

 Align together the mounng clamp holes and

the sliding rod, and insert the rods into the

clamp, as shown in the images.

Note: You can adjust the mounng clamp

according to your requirement.

 Once the mounng clamp is mounted,

securely ghten it with the help of the knob.

Next, insert the main rod into the mounng

clamp.

 Loosen the support bracket clamp knob as

per your requirements and then aach it to

the main rod.

Camera Arm Mount Kit Setup

 Tighten the knob to secure the main rod.

YOUR PROAIM CAMERA ARM MOUNT KIT FOR MAGNUS RICKSHAW

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Note: You can adjust the support bracket with

clamp according to your setup.

 Loosen the knobs of the airwave arm, mount it

to the main rod, ghten the knobs to secure

the arm.

 Your setup is ready to use.

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
