CAMPFIRE

WARNING: If the information in this manual is

not followed exactly, a fire or explosion may

result causing property damage, personal injury,

or loss of life.

PL600HYLA/PL600HYLB

60,000BTU/Hr

PN750HYLA/PN750HYLB

75,000BTU/Hr

Manually Controlled

OWNER’S OPERATION AND INSTALLATION MANUAL

IMPORTANT: Read this owner’s manual

carefully and completely before trying to

assemble, operate, or service this heater.

WARNING: Improper installation, adjustment,

alteration, service, or maintenance can cause

injury or property damage. Read the installation,

operating and maintenance instructions

thoroughly before installing or servicing this

equipment

FOR YOUR SAFETY:

Do not store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any

other appliance.

WHAT TO DO IF YOU SMELL GAS:

-Shut off supply to the appliance.

-Extenguish any open flames.

-Immediately call your gas supplier. Follow

the gas supplier’s instructions.

-If you can not reach your gas supplier, call

the fire department.

Installation and service must be performed by

a qualified installer, service agency or the gas

supplier.

Save this manual for future reference.

Installer: Leave this manual with customer.

WARNING: For Outdoor Use Only. Do not

use for cooking

GENERAL INFORMATION

These instructions are intended as a general guide and do not supersede national or local codes in anyway.

Authorities having jurisdiction should be consulted before installation.

Installation and provision for combustion and ventilation air must confirm with the national Fuel Gas Code. This

campfire has been tested to, and complies with IAS 4-96 1997, U, S, Requirements for Outdoor Gas Fireplace

TABLE OF CONTENTS

GENERAL INFORMATION……………………………………………………………….........2

SAFETY INFORMATION………………………………………………………………...........3

INSTALLATION .……………………………………………………………………..……....... 5

OPERATING HEATER ………………………………………………..…………………........7

MAINTENANCE AND STORAGE ……………………………………………………..........8

PRODUCT FEATURES……………………………………………………………………......9

SPECIFICATION…………………………………………………………….........…………...10

TROUBLESHOOTING……………………………………………………………………... ..10

PARTS LIST…………………………………………………………… …………………….....11

WARRANTY………………………………………………………………………………….....end

Liquid propane units are designed and certified for use only with house-

hold liquid propane supply period. Do not use “portable” propane tanks of

less than 100-lbs, Capacity, LP units cannot be operated with 20-lb. Propane

tanks commonly used with portable, liquid propane gas grills.

SAFETY INFORMATION

THISGASAPPLIANCEISDESIGNEDFOROUTDOORUSEONLY.

IT IS NOT INTENDED FOR INSTALLATION IN ANY BUIDING,

GARAGE.ORENCLOSEDSTRUCTION.ITISNOTINTENDEDFOR

INSTALLATIONINORONRECREATIONALVEHICLESORBOATS.

WARNING: Follow all gas leak procedures in

this manual, prior to operation.

WARNING: Fuels used in gas fired appliances,

and the products of combustion of such fuels,

contain chemicals know to the State of California

to cause cancer, birth defects and /or other

reproductive harm. This warning is issued pursuant

to California Health & Safety Code Sec.25249.1

DO NOT ATTEMPT TO DISCONNECT THE GAS OR ANY

GASFITTINGWHILETHISAPPLIANCEISINOPERATION.

Inspect the gas connections of this appliance prior to

each use. Do not operate the unit if there is a gas leak

present.

Do not put anything flammable, on or around or be-

neath the campfire.

NEVER Leave the campfire unattended while in

operation.

NEVER Allow children to operate this appliance.

NEVER Lean over the campfire or place ,hand or fin-

gers on the screen cover or near flame.

NEVER Use liquid propane gas in a natural gas unit,

or natural gas in a liquid propane unit. Gas conver-

sions SHOULD ONLY BE DONE BY A QUALIFIED

SERVICE TECHNICIAN. DO NOT use charcoal bri-

quettes or lighter fluid in any campfire.

Storage of this appliance indoors is permissible only if

the gas is disconnected.

PROPER CLEARANCES FROM COMBUSTIBLE, CON-

STRUCTION AND MATERIALS MUST BE MAINTAINED

FROM ALL SIDES, TOP AND BOTTOM OF THIS

APPLIANCE.

THIS APPLIANCE SHOULD NEVER BE PLACED ON

ANY COMBUSTIBLE SURFACE.

THISAPPLIANCESHOULD NEVER BE PLACEDUNDER

ANYCOMBUSTIBLECONSTRUCTIONORMATERIALS.

THIS APPLIANCE SHOULD NEVER BE PLACED

CLOSER THAN FORTY-EIGHT (48”) INCHES FROM

ANYSIDE TOANY COMBUSTIBLE CONSTRUCTION

ORMATERIALS.

Location

Your campfire can be installed on a flat, stable surface,

away from any combustible materials or construction.

(See FIgure 13)

Place unit on any level, outdoor, non combustible

surface.

NOTE: Do not place this appliance on grass or dirt

area , this may prevent proper venting.

HARD PIPING TO UNIT WITHOUT GAS PROXIMITY

1. TURN OFF THE GAS SUPPLY SYSTEM

NOTE: All gas connections (except for brass to

brass) require the following:

Clean pipe threads using either a wire brush or steel

wool. Apply Teflon tape or pipe dope to the steel

fittings before making any connection.

BE CAREFUL! Make sure all gas connections are

snug, but not over tighten!

2. Extend the gas supply system using1/2” black iron

pipe from current house supply. This may be ac-

complished by a teeing off” or tapping into a con-

venient gas line connection; installing the neces-

sary pipe for the distance required; and then in-

stalling a manual valve at exterior house wall. If

pipe is to pass though a foundation or house wall,

make sure to re-seal the area around the pipe with

weather sealant.

3. From manual valve, extend piping to the campfire.

While this appliance is not in use, the gas must be

turned off at the gas supply.

While this appliance is not in use, it should be covered

to protect it from weather and other adverse elements.

Note :If pipe is to be placed in an underground trench,

check with local codes for required depth and mate-

rial construction.

4. Connect the 3/8” male flare brass fitting (furnished

with campfire) to the 1/2” steel piping making sure

to clean the pipe threads and use Teflon tape or pipe

dope.(FLEX LINE NOT SUPPLIED)

5. Connect the 1/2” female X 3/8” male flare brass

fitting to the 3/8” female brass flare fitting, as

sembled on the right side of the gas line, of the

right side of the campfire.

Children and adults should be alerted to the hazards

of high surface temperatures and should stay away

to avoid burns or clothing ignition.

Young children should be carefully supervised when

they are in the area of the appliance.

Never leave the appliance unattended during

operation.

Clothing or other flammable materials should not

be placed on or near the appliance.

∙Any guard or other protective device removed for

servicing the appliance must be replaced prior to

operating the appliance

∙Installation and repair should be done by a quali-

fied service person.. The appliance should be in-

spected before use and at least annually by a quali-

fied service person. More frequent cleaning may

be required as necessary. It is imperative the con-

trol compartment, burners and circulating air pas-

sageways of the appliance be kept clean.

∙Inspect the fuel supply connection before each use

of the appliance.

IMPORTANT: Installation of natural gas and LP

should be done by a qualified installer, service

agency or gas supplier.

The appliance and its manual shutoff valve must

be disconnected from the gas supply piping sys-

tem during any pressure testing of the system

at test pressures in excess of 1/2 psig (3.5kPa).

This appliance must be isolated from the gas

supply piping system by closing its manual

shutoff valve during any pressure testing of the

gas supply piping system at test pressures equal

to or less than 1/2 psig (3.5kPa).

Location Continue

NOTE: Brass to brassw connections do not require

teflon tape or pipe dope.

(Note: show drawing of hard piping installation.

Storage of this appliance indoors is permissible only

if it has been disconnected from its fuel supply. (natural

gas line or LP gas)

LOCAL CODES

Install and use heater with care. Follow all local codes.

In the absence of local codes, use the latest edition of

The National Fuel Gas Code, ANSZ223.1, also known

as NFPA54*.

Available from :

American National Standards Institute, INC.

1430 Broadway, New York, NY10018

National Fire Protection Association, INC.

Battery march Park Quincy. MA 02269

Do not use this appliance if any part has been under

water. Immediately call a qualified service technician

to inspect the appliance and to replace any part of

control system and any gas control which has been

under water.

Installation

LOGS LIST

PL600HYLA PN750HYLA

FIG 2 The LOG sets for PL600HYLA/ PN750HYLA

PL600HYLB PN750HYLB

FIG 3 The LOG sets for PL600HYLB/ PN750HYLB

Installation continue

Check to make sure you have the correct parts before

assembling.

. Logs: 5

Caution: Some of the steel edges may be

sharp. Please use caution when assembling

the unit.

INSTALLATIONINSTRUCTIONS:

1. Remove log from inside the box. Please note each log fits

the number marked on foam package.

2. Next remove campfire from box.

3. You may use bricks or blocks to create your sur-

round to place your campfire on.

4. Make sure that the campfire is placed on a flat

surface.

5. Check the log piece (FIG-4).

Fig.-4 Check the log piece

6. Make sure that the logs were installed correctly.

(FIG.-5).(Base logs are pre-installed.)

Fig.-5 Install and check the base logs

7. Install the No.#1 log as indicated on base log .Fix

the log on the bracket by the screw .

(FIG.-6).

Fig. 6 Install the LOG #1

8. Install the No.#2 log as indicated on base log.

(FIG.-7).

Fig. -7 install the LOG #2

9. Install the No.#3 log as indicated on the base log

( FIG.-8).

Fig. -8 install the LOG #3

Installation (continue)

11. install the No. # 4 log as indicated on the base

(FIG.-9).

Fig. -9 Install the LOG #4

12. Install the No. #5 Log as indicated on the base log

(FIG. 10).

FIG. -10 Insatll the LOG #5

CONNECTING TO GAS SUPPLY

Note: Apply a mixture of liquid soap and water to all

joints. Do not use an open flame. Bubbles forming

show a leak. Check all connections for leaks

immediately.

FUEL REQUIREMENTS:

Natural gas models

l - Connect the ON/OFF gas valve of the appliance

to the incoming gas supply line. See Figure 10. -

- Make certain all gas connections are right.

- Turn the ON/OFF valve at the appliance slowly

to the “ON” position. Use a soap and water

solution to test for leaks.

Fig. 11 Natural gas burner assembly

OPERATING HEATER

Your campfire burener is build to operate with natural

gas or build for LP gas.

This appliance is lit a piezo ignitor, follow these instruc-

tions exactly when lighting the campfire. BEFORE

LIGHTING, smell arround the appliance the appliance

area for gas. Be sure to smell to next to the ground as

liquid propane gas heavier than air and will settle to the

ground.

Follow adaptable lighting instructions. Apply soap solu-

tion to all joints. Bubbles forming indicates a leak. Do

not use a match or an open flame to detect leak. Light

heater after ensuring that no gas leak exists.

LIGHTING INSTRUCTIONS

WARNING:FOR YOUR SAFETY READ

BEFOR LIGHTING

1. STOP! Read the safety information above.

2. Make sure manual shutoff valve is fully open.

3. Press in and turn control knob clockwise 90

degree to the OFF position.

4. Wait five (5) minutes to clear out any gas. Then

smell for gas around log set and near floor. If you

smell gas, STOP! Follow the safety information

above. If you don’t smell gas, go on to the next step.

5. Turn control knob counterclockwise 90

degree to the PILOT position and press in. Keep con-

trol knob pressed in for five(5) seconds.

Note: You may be running this log set for first time

after hooking up to gas supply. If so, the control

knob may need to be pressed in for 30 seconds.

This will allow air to bleed from the gas system.

6. With control knob pressed in, push down and re-

lease ignitor button. This will light the pilot. The pi-

lot is attached to the side of the front burner. If

needed, keep pressing ignitor button until pilot

lights.

NOTE: If pilot does not stay lit, contact a qualified

service person or PRO-COM’s 800# on the back

of this manual. Until repairs are made, light pilot

with the piezo.

7. Keep control knob pressed in for 30 seconds after

lighting pilot. After 30 seconds, release control knob.

Note: If pilot goes out, repeat steps 3 through 7.

If control knob does not pop up when released, con-

tact a qualified service person or PRO-COM’s 800#

on the back of this manual.

8. Turn control knob counterclockwise 90

degree to the ON position. Burner should light. If

burner does not light, call a qualified service person

or PRO-COM’s 800# on the back of this manual.

Fig12 The operationg board

MAINTENANCE AND STORAGE

1. Storage of an appliance indoors is permissible

only if the gas supply system is disconnected and

removed from the appliance. .

2. Have the heater inspected by qualified service

man before each use or at least annually.

3. Check the POL fitting for any damage before each

use and replace if any damage is found.

4. Spiders and insects can nest and live in outdoor

appliances, especially in the burners and orifices.

This will interrupt the normal flow of LP gas to

the heater and can be a very dangerous situation.

Inspect for insect infiltration of burner/orifice when

one of the following occurs:

A. The smell of gas along with predominating yel-

low tipping of the burner flames.

B. Heater can not reach desired temperature.

C. Uneven burner flow.

D. Burner makes popping noises during normal

use or shutdown.

5. Adopt rainproof cover (provided with the heater)

to avoid rust of heater when not in use.

WARNING: If you do not follow these in-

structions exactly, a fire or explosion may

result causing property damage, personal in-

jury or loss of life.

TO TURN OFF GAS TO APPLIANCE

Shutting Off Appliance

1. Turn control knob clockwise 90 degrees to

the PILOT position.

2. Press in and turn control knob clockwise 90

degrees to OFF position.

Shutting Off Burner Only (pilot stays lit)

Turn control knob clockwise 90 degrees to the

PILOT position.

PRODUCT FEATURES

SAFETY PILOT

The heater has a pilot with a safety shutoff system.

The safety pilot is a required feature for outdoor

heaters. It shuts off the heater if flame is extinguished

by rough wind.

PIEZO IGNITION SYSTEM

This heater has a piezo igniter. This system requires

no matches, batteries, or other sources to light heater.

*Option Screen*

For Your safety

You may purchase the screen to maintain a clearance

around the campfire

CAUTION

PLEASE DO NOT TOUCH SCREEN OR PLACE ANY

OBJECTS ON SCREEN WHILE BURNER IS ON

Children and adults should be alerted to the hazards

of high surface temperatures and should stay away

from SCREEN to avoid burns or clothing ignition,

SERVICE INDICATIONS:

A hazardous condition may result if a heater has been

modified or is not functioning properly. When the

heater is working properly:

1. The flame is essentially yellow.

2. There is no strong disagreeable odor, eye burn-

ing or other physical discomfort.

3. No smoke or soot exists internal or external to the

campfire.

4. No unplanned or unexplained shut down of the

heater occur.

REPLACEMENT

REPLACEMENTPARTS:

Note: Use only original replacement parts. This will

protect your warranty coverage for parts replaced un-

der warranty.

PARTS UNDERWARRANTY:

Contact authorized dealers of this product. If they can’t

supply original replacement part(s) call PRO-COM’s

Technical Service Department at 1-877-886-5989 for

referral information.

When calling PRO-COM or your dealer, have ready

Your name

Your address

Model and serial numbers of your heater

How heater was malfunctioning

Type of gas used (propane/LP or natural gas)

Warranty card

Usually, we will ask you to return the defective

part back to retail store.

PARTS NOT UNDER WARRANTY:

Contact authorized dealers of this product or Parts

Central if they can’t supply original replacement part

(s) Call PRO-COM’s Parts Department at 1-877-886-

5989 for referral information.

When calling PRO-COM, have ready

Model number of your heater

The replacement part number

FIG. 13 The screen

VALVE CONTROL SYSTEM

This heater has a control valve to control the gas flow,

with the control valve, you can chose the proper flame

of the fire.

ACCESSORIES

In the U.S.A., Input BTU shall be derated 4%(1 orifice

size) per 1000ft, for above 2000ft.. In Canada, input BTU

shall be derated 10% (2 orifice size) at altitudes from

2000ft.to 4500ft..

TROUBLESHOOTING

POSSIBLE CAUSE

1. Air in gas lines.

2. Inlet gas pressure is too low.

3. Gas supply turned off.

4. Air passageway on heater blocked.

5. Burner orifice clogged.

6. Control knob not in ING/ON position.

7. Control knob not fully pressed in while

in ING/ON position.

1. Ignitor electrode positioned wrong.

2. Ignitor broken.

3. Broken ignitor cable.

4. Ignitor electrode not connected to ignitor cable.

1. Damaged thermocouple.

2. Thermocouple electrode corrosion.

3. Damaged control valve.

4. Control knob not pressed long enough.

5. Thermocouple connection loose at control valve.

6. Pilot flame not touching thermocouple.

When ignitor buttons

pressed in, there is no

spark at safety Pilot.

OBSERVED PROBLEM

Burner does not light

Burner fire does not last.

REMEDY

1. Continue holding down control knob.

Repeat igniting operation until air is

removed.

2. Check gas pressure.

3. Fully open gas supply.

4. Check air passageway.

5. Clean burner.

6. Turn control knob to ING/ON position.

7. Press down control knob.

1. Reposition ignitor.

2. Replace pilot

3. Replace ignitor cable.

4. Connect electrode to ignitor cable.

1.Replace thermocouple.

2. Clean thermocouple electrode.

3. Replace control valve.

4. After pilot lights, keep control knob

pressed in for 30 seconds.

5. Hand tighten connection or replace

thermocouple.

6. Contact qualified service man.

HIGH ALTITUDE DERATE

Purchase the accessories from your local dealer or

Parts Central. If they cannot supply these accessories

call PRO-COM’s Sales Department at 1-877-886-5989

for referral information. You can also write to the ad-

dress listed on the back page of this manual.

SPECIFICATIONS

Model L600HYLA/B PN750HYLA/B

Btu (LP/NG) 60.000 75.000

Gas Type LP NG

Ignition Piezo Piezo

Inlet Gas Pressure* (In. of water)

Maximum 14” 10.5”

Minimum 11” 5.5”

Dimensions, Inches (H x W x D)

Stove 17 3/4” x22 7/8”x18 1/8” 17 3/4” x22 7/8”x18 1/8”

Carton 15” x25 ”x20 1/4” 15” x25 ”x20 1/4”

Weight, Lbs

Stove 32/33 32/ 33

Shipping Weight 55/58 55/ 58

* For purpose of shipment adjustment.

Minimum clearances: Bottom: (This appliance may not be place on any combustible materials)

Top: 8 FT. (2.4m)

Side /walls (around): 48 inch (1220mm)

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Procom Camino esterno

Procom

Procom AL500HYLA Guida rapida

Manuali Camino esterno popolari di altre marche

Outdoor Plus

Outdoor Plus PISMO OPT-2448 Manuale utente

Legacy

Legacy Fire Pit Manuale utente

Coleman

Coleman 5055-710 Manuale utente

Uniflame

Uniflame GAD1348HN Manuale utente

Jensen

Jensen 300NG Manuale utente

FEUERHAND

FEUERHAND PYRON Manuale utente

Firegear

Firegear KWB-NG1 Guida rapida

Classics

Classics FP35077 Manuale utente

Jensen

Jensen 1590LP Manuale utente

Mayer Barbecue

Mayer Barbecue HEIZA MFK-220 Manuale utente

Costway

Costway NP11018 Manuale utente

Target

Target Foxborough Manuale utente

Blumfeldt

Blumfeldt Merano Manuale utente

Blooma

Blooma Brasero Ulong Manuale utente

The Fireplace

The Fireplace JETMASTER 700 D Manuale utente

Superior

Superior VRE4543EN Manuale utente

Morsø

Morsø Forno Manuale utente

dobar

dobar CONICO 35439E Manuale utente
