Project Timber Evolution My Den Manuale di istruzioni
10x8
Evolution My Den
Building Instructions
Cover Size:
Please read the instruction carefully
and retain for future reference
For Queries and Help please contact 01777 802300
Please note that all images are for illustration purpose only.
V1.4 20.04.22 INS0137
10x8 My Den - Metal Roof
Side Opening Window (RIGHT)
Building shown
10x8 Evolution My Den
Metal Roof
Side Window Opening (RIGHT)
shown Floor Assembly
1467mm x 1217mm (4)
Metal Roof
position 610mm
505mm
1000mm
585mm
1220mm 1220mm
Back Panels
position
Front Panels
position
610mm
Single
Door
Panel
610mm 610mm
1220mm1220mm
1220mm
(LOW)
1220mm
(LOW)
1220mm
(HIGH)
585mm
610mm 610mm
610mm
Side
Window
Opening
(RIGHT)
Door
Position
(LEFT)
10x8 Floor Plan
Front of Building
Door Position (LEFT)
Door Position (RIGHT)
Door and Front Windows position options
Single Door Panel
(LEFT)
Glazing Units
(610mm)
Single Door Panel
(RIGHT)
Glazing Units
(610mm)
To p
Panel
Bottom
Panel
To p
Panel
Bottom
Panel
IMPORTANT: Always check the internal lining corner gap of the panels
Side Opening Window (LEFT)
position option
Front
Left Side
1220mm1220mm
1220mm
(LOW)
1220mm
(LOW)
1220mm
(HIGH)
585mm
610mm 610mm
610mm
Side
Window
Opening
position
(LEFT)
Door
Position
RIGHT
Floor Plan
Front of Building
2135mm
1220mm
Side Window
Opening Panel
(LEFT)
Diagram
ID: PT25521
Drip Edge
Flashing
Barge Board
Flashing
Gable Panel
(LEFT - Low)
Gable Panel
(LEFT - High)
Back Corner
Trims
Front Corner
Trims
Base Module
A - LEFT
Base Module
A - RIGHT
Base Module
B - CENTRE
11mm Floor
Panels
8ft Gable
Plinth
10ft Plinth
Top Plain
Panel
Bottom Plain
Panel
Single Door
Panel / UPVC
Single Door
(LEFT SIDE)
Gable Panel (High)
with Window Opening
Gable Panel
(Right - Low)
Plain Panel
Back - LEFT
(1220mm WIDTH)
Window Panels
(610mm WIDTH)
Roof Section
1000mm Width
Roof Section
505mm Width
Roof Section
610mm Width
Roof Section
1000mm Width
Rear Frame
Standoff
Gable Frame
Standoff
Plain Panel
(585mm WIDTH)
Plain Panel
Back - RIGHT
(585mm WIDTH)
10ft Front Monopitch
Ridge Flashing
10ft Back Water
Deflector Flashing
Building Parts: 10x8 Evolution My Den
Metal Roof
Building Parts
Part ID
PT25544
PT25545
PT25524
PT25533
PT25535
PT20322
PT25547
21140
21148
21192
21181
21182
21183
21177
15603
15606
PT18490
PT25522
PT25534
PT20329
19525
PT25385
PT25386
PT18177
PT21078
Wood Kit
1
1
1
1
1
1
1
2
1
1
1
1
1
2
2
2
3
1
1
1
1
2
1
4
QTYNo.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
13
2
4
5
6
7
8
8
9
10
11
12
13
14
15
16 17
18
19
20
21 21
22
23
24
24
24
24
Base Module Woodkits
1220mm 585mm
Base Modules (For each end of the assebled base)
Gable Bearers
Fixing Kit
1. Base Module A - 1220mm x 2528mm (2)
[ID: PT23585]
2. Base Module B - 585mm x 2528mm (1)
[ID: PT25386]
3. Gable Bearers - 38mm x 2452mm (2)
[ID: PT23598]
Parts List required:
Base Module fixing
Side
Front
Module A x2
Module B x1
1220mm 1220mm
585mm
A
A
B
1
Side
1220mm
Module
Pilot drill
holes before
fixing
Base Module fixing
100mm
Screws
ID: PT25385
2
Side
585mm
Module
Pilot drill
holes before
fixing
Base Module fixing
100mm
Screws
ID: PT25386
3
Base Module Stages
Side
Front
Back
Position the gable bearers each side to
the fully assembled base. Secure with
S70 screws
Base Module fixing
70mm
Screws
ID: PT23598
Side
Front
Gable Bearers are fitted on each side of
fully assembled base. This gives extra
room for the floor sections. (see diagram)
Pilot drill holes
before fixing
Base Module fixing
70mm
Screws
Side
Front
Back
Alternate sides
to screw together
Pilot drill holes
before fixing
Base Module fixing
70mm
Screws
Side
Front
Back
Ensure the ground must be flat and level,
before laying the base module assembly.
Base Module fixing
Check the base module can sit level to the
ground. Use spirit level when leveling all
corners of the base.
Base Module fixing
Side Front
Floor Joist
Floor Boards
Side of
Base Module
Plinth
Gable
Bearer
Base Module fixing
4
78 9
5 6
Floor Section Stages
Side
Front
Back
Lay and fix the Plinth
lengths together at
the corner
Pilot drill
holes
Floor Stages
4 70mm
Screws
ID: 15603
ID: 15606
Plinth
Base Module
Position the plinth into the top of
assembled base module
Floor Stages
Base Module fixing
Side
Front
Fix and secure the
plinth and base
module together
Side
Front
Back
Floor Stages
Pilot drill holes
before fixing
70mm
Screws
Fix the Floors together
Floor Stages
Side
Front
Back
11mm Floor
assembly shown
ID: PT18177
Floor Sections Diagram
Wall
Panel
Plinth
Gap
Base Module
Side View
Floor
Boards
Floor Joist
10
13 14 15
11 12
Floor Section Stages
Wall Panels Section Stages
Panel Position Diagram
Front of Building
Rear
Side
(Left)
Side
(Right)
Side
(LEFT) Front
1. Door Panel - LEFT (1)
2. UPVC Single Door - LEFT (1)
3. Left Gable Panel - HIGH (1)
4. Left Gable Panel - LOW (1)
5. Gable Cloaking Strip (1)
60mmx16mmx2050mm
Parts List required:
ID: PT20329 / 19503 ID: PT25534
16mm
2135mm
74mm1146mm
1220mm
Lining Flush
16mm
2135mm
1220mm
Lining Flush
Single Door Panel
Diagram Left Gable Panel (HIGH)
Diagram
12 50mm
Screws
Floor Stages
Fix the Floors with
screws in angled
position
Back
Side
16
Floor Stages
Side
Front
Back
Place the floor assembly
inside the plinth and
base module.
17
Wall Panels Section Stages
2 50mm
Screws
Front
Side
(LEFT)
Pilot drill holes
before fixing
*Check the Side Opening
Window (LEFT) position
option floor plan for
guidelines.
Position and fix
the plain gable
panel (Left)
Left Gable (High) Panel Stages
ID: PT25534
50mm
Screws
Front
Side
Front
Side
(LEFT)
Pilot drill holes
before fixing
Align and fix the door
panel to the left gable
panel (high) and plinth
Left Gable and Door Panel (LEFT) Position
Front
Side
Lining
Flush
Lining
Flush
Left Gable (High) Panel Stages
Front
Side
(LEFT)
Align and fit the UPVC Door Cill
to the door panel (LEFT)
UPVC Door fixing
ID: 19503
80mm
Screws
Front
Fix and secure the UPVC
Door Cill to the door panel
UPVC Door fixing
ID: 19503
50mm
Screws
Side
Front
Pilot drill holes
before fixing
Fit the Plain Gable
Panel and Door
Panel in this position
Gable and Door Panel Position
18
21 22 23
19 20
Wall Panels Section Stages
80mm
Screws
Front
Fix and secure the UPVC Door
section to the door panel
UPVC Door fixing
ID: 19503
50mm
Screws
Side
(LEFT)
Pilot drill holes
before fixing
Cloaking Strip is used to fix
the panels together
Position and fix
the gable
cloaking strip
LEFT - Gable Cloaking Strip (CS)
ID: PT21078
Front
Side
(LEFT)
Position and fit the UPVC Door
section to the door panel (LEFT)
UPVC Door fixing
ID: 19503
50mm
Screws
Side
(LEFT)
Front
Pilot drill holes
before fixing
Position and fix the Side
Gable (Low) Panel
Left Gable (Low) Panel Stages
ID: PT25533
16mm
2094mm
1220mm
Lining Flush
Left Gable (Low) Panel Diagram
ID: PT25533
24
27 28
25 26
