ProtoArc EKM01 Plus Manuale utente
CONTENTS
- 1 -
Product Features
2.4G USB Connection
Mouse Bluetooth Connection
Keyboard Bluetooth Connection
How to Switch Mouse Device Channels
How to Switch Keyboard Device Channels
Charging Guide
Multimedia Function Button
Product Specification
Sleep Mode
Tips
Packing List
2
4
5
6
7
7
8
9
10
11
11
11
Product Features
2.4G Indicator
BT2 Indicator
Backward Button
Left Button
Scroll Wheel Button
Power Switch
BT1 Indicator
Channel Switch Button
Forward Button
Low Power / Charging Indicator Type-C Charging Port
DPI Button
Right Button
Press the DPI button to adjust the cursor sensitivity. A single flash of indicator
light corresponds to DPI level 800, two to 1300, and three to 2000.
DPI Button
- 2 -
Power Switch
2.4G
Channel
Bluetooth
Channel 1
Bluetooth
Channel 2
Caps Lock Indicator
USB Receiver
Low Power /
Charging Indicator
Type-C Charging Port
BT1 Indicator
B2 Indicator
2.4G Indicator
- 3 -
4 4
4. Press the mode switch button on
the left of the mouse to channel 1,
the 2.4G indicator will be on, now
the mouse is in 2.4G mode.
4. Press key to switch to 2.4G
channel, the white indicator will
flash slowly, the keyboard now is in
2.4G mode.
2.4G USB Connection
1 1
2 3
1. Switch the keyboard ON.
2. Take out the USB receiver.
1. Switch the Mouse ON.
3. Plug it into a USB port on your
computer.
- 4 -
Mouse Bluetooth Connection
1
3
4
2
1. Turn the power switch to ON. 2. Press the channel switch button to
channel 2 or 3 until the corresponding
channel indicator is on.
3. Long press the channel switch
button for 3~5 seconds until the
corresponding channel indicator
flashes quickly, the mouse enters
Bluetooth paring mode.
4. Turn on the Bluetooth settings on your device, search or select “ProtoArc
EKM01 Plus” and start Bluetooth pairing until the connection is completed.
Bluetooth
Settings
ProtoArc EKM01 Plus
ProtoArc EKM01 Plus Connected
On
1
2
3
4
- 5 -
Keyboard Bluetooth Connection
1
3
4
2
1. Turn the power switch to ON. 2. Press the channel switch
button / until the
corresponding channel indicator
is on.
3. Long press the channel switch
button for 3~5 seconds until the
corresponding channel indicator
flashes quickly, the keyboard
enters Bluetooth paring mode.
4. Turn on the Bluetooth settings on your device, search or select “ProtoArc
EKM01 Plus” and start Bluetooth pairing until the connection is completed.
Bluetooth
Settings
ProtoArc EKM01 Plus
ProtoArc EKM01 Plus Connected
On
1
2
3
4
- 6 -
How to Switch Mouse Device Channels
How to Switch Keyboard Device Channels
After BT1, BT2 and 2.4G USB mode is connected, press the mode switch
button on the left side of the mouse to switch between multiple devices.
After are connected, press the corresponding channel key to
switch between devices.
BT 1 Device Channel
BT 1 Device Channel
BT 2 Device
Channel
2.4G USB
Device Channel
BT 2 Device
Channel
2.4G USB
Device Channel
- 7 -
Charging Guide
1. When the battery is low, the indicator light will turn red and start flashing until
the keyboard/mouse is turned off.
2. Insert the Type-C port into the Keyboard/Mouse and the USB-A port into the
computer to charge, the red light stays on while charging.
3. It takes 2–3 hours for one cycles full charged, and the indicator turns green
when fully charged.
- 8 -
Multimedia Function Button
Open Setting / / /
- 9 -
