VGA/Stereo Audio/IR/RS232 Twisted Pair over single CAT cable
PTN Electronics Limited 1www.PTN-electronics.com
1. Introduction
1.1. Introduction to TPVG201
TPVG201 is a VGA/Stereo Audio/IR/RS232 Twisted Pair Transmitter (TPVG201T) and
Receiver (TPVG201R), which has been designed for reliability and exceptional high
resolution image performance.
TPVG201 uses PTN's unique VGA/Stereo Audio transmission technology to deliver
perfect computer-video images & audio up to QUXGAresolution (1920*1200), as well
as control signal(IR or RS232), over a single CAT5/CAT5e/CAT6/CAT7 cable. The
maximum transmission distance is up to 100 meters with CAT5 cable.
1.2. Package Contents
1 x TPVG201T
1 x TPVG201R (Packed separately form TPVG201T)
4 x Mounting ears (Separated from TPVG201)
8 x Screws
2 x Power adapter (DC 5V)
2 x Captive screw connectors
1 x User manual
Notes：Please confirm if the product and the accessories are all included, if not, please
contact with the dealers.
2. Features
Transmits high resolution computer-video signals at 100 meters, over single CAT5,
CAT5e or CAT6 STP cable.
HDTV Compatible. High Definition Transmission, up to 1080p.
Bandwidth: 300MHz.
Compatible with RGBHV, RGBS, RGsB signals.
Built-in VGA output splitter.
Level &EQ adjustable.
H/V polarity adjustable.
Built-in VGA local monitor for the user to check the live video display.
Wall/table-mountable aluminium enclosure, PT case design.
Audio follows video, sync-transmission.
External international power supply (100Volt~240Volt AC, 50/60Hz).
