Pulsar Krypton XG Manuale utente
Krypton XG
Manual
Content
Description
Package Contents
Features
Components and Controls
Button Operation
Using the Battery Pack
Battery Charging
Battery Installation
Precautions
Recommendations for Use
External Power Supply
Operation
Installing Thermal Imaging Module on the Optical Device
Installing Pulsar 5x30 B Monocular on to the Krypton XG
Powering on and Image Setting
Microbolometer Calibration
Status Bar
Quick Menu Functions
Main Menu Functions
Enter the Main Menu
Mode
Image Detail Boost
Wi-Fi Settings
General Settings
Auto Shutdown
Device Information
Defective Pixel Repair
Defective Pixel Repair
Restore Default Pixel Map
Microphone
Bluetooth
Calibration Mode
Video Recording and Photography
Wi-Fi Function
Display-Off Function
Wireless Remote Control
Descriptions of Controls
Remote Control Activation
Stream Vision 2
Firmware Update
USB Connection
Technical Inspection
Description
The Krypton XG50 thermal imager is designed for a variety of applications, including hunting
surveillance, security activities, day and night photo and video shooting.
The Krypton XG50 thermal imaging module can be mounted (using the correct Ring Adapter)
on to the objective lens housing of various daylight optical devices, converting them into a
highly-sensitive thermal imaging device.
To get started, see the sections:
Battery Charging
Battery Installation
Installing Thermal Imaging Module on the Optical Device
Installing Pulsar 5x30 B Monocular on to the Krypton XG
Powering on and Image Setting
Package Contents
Krypton XG50 thermal imager
Pulsar 5x30 B Monocular
Carrying Case
Wireless Remote Control
IPS7 Battery Pack
Battery Pack Charger
Power Adapter
USB Cable
Quick Start Guide
Lens-Cleaning Cloth
Warranty Card
Neck strap
Features
High resolution thermal imaging microbolometer
Microbolometer pixel size of 12 microns
High-resolution AMOLED display
Easily converts daylight optical devices into thermal imaging devices
Preserves the benefits of daylight optics in night-time conditions
Three calibration modes (manual, semi-automatic and automatic)
Four observation modes: Forest, Rocks, Identification, User
Compatible with a wide range of daylight optical magnifications
Detection distance up to 2300 m
Wireless remote control
Instant start
Display off function
Built-in video recording
Remote Firmware update
Fully watertight (IPX7 protection class)
Wide operating temperature range (-25 °? – +50°?)
Video/audio recording
Built-in video recorder
Integration with iOS and Android devices
Wi-Fi Smartphone remote control and surveillance
YouTube Live broadcasting and direct recording on the Internet via a smartphone and the
Stream Vision app
Storing photos and videos in Cloud when using the Stream Vision 2 app
Battery Pack
Quick-change IPS7 Li-ion battery pack
USB charging option
Components and Controls
1. Lens cover
2. Eyepiece cover
3. Battery compartment cover
4. Battery locking lever
5. Battery pack
6. RIGHT/REC button
7. MENU button
8. LEFT/MODE button
9. ON/OFF/CALIBRATION button
10. Lens focus knob
11. MicroUSB port
12. Weaver rail
13. Objective lens end of daylight optical device
14. Insert
15. Adapter
16. Screws
17. Tightening screw
18. Screw
19. Adapter lever
20. Mount
21. Pulsar 5x30 B Monocular
Button Operation
Operation Button
Power device on short press
Power device off long press for 3 secs
Turn display o? long press for less than 3 secs
Turn display on short press
Calibrate the microbolometer short press
Switch observation modes short press
Turn on/off the Black Hot palette long press
Video recorder Button
Start/pause/resume video recording short press
Stop video recording long press
Switch to video / photo long press
Capture Photo short press
Main Menu Button
Enter main menu long press
Navigation down/counter-clockwise short press
Navigation up/clockwise short press
Con?rm selection short press
Exit submenu without con?rming
selection long press
Exit menu (switch to viewing mode) long press
Quick Menu Button
Enter quick menu short press
Switch between quick menu options short press
Increase value short press
Decrease value short press
Exit quick menu long press
