Pyle PL1SN104 Manuale utente

Adjustable Viewing Angle

(Maximum Angle 360°)

10.1'' Touch Screen TFT/LCD Monitor

Single Din MP5 Player With Swivel Screen, Phone Link, With Backup Camera

PL1SN104

User’sManual

www.PyleUSA.com

Precautions

Wiring Diagram

General Operation

AM/FM Tuner Operation

Multimedia player

Music playing interface

Viedo or Picture playing interface

AUX in/ Rearview Camera

Wireless BT Streaming

AutoLink Software (Phone Link)

Setting Menu

Troubleshooting

Systematic Parameter

Disassembly Steps of Display

Rear View Backup Camera Installation

Precautions

1. When the interior of the car is extremely cold and the unit is used soon after switching on the

heater, moisture may form on the disc or the optical parts of the player and proper playback

may not be possible. If moisture forms on the disc, wipe it off with a soft cloth. If moisture forms

on the optical parts of the player, do not use the player for about one hour. The condensation

will disappear naturally allowing normal operation.

2. This unit uses precision parts and components for its operation. In the event that trouble arises,

never open the case, disassemble the unit, or lubricate the rotating parts. Contact your service

center.

3. This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec

tion against harmful interference in a residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio reception, which can be determined by turning the

equipment off and on, the user is encouraged to consult an experienced radio technician for

help.

www.PyleUSA.com

Wiring-Back Panel:

Wiring-Color Wiring:

www.PyleUSA.com

General Operation:

Profile of main interface

1.Time Setting

2. Radio

3. Bluetooth

4. USB

5. SD Card

6. Navigation (optional)

Note: If there is no any device connection, icons for USB, SD will be showed no device. Click is

invalid in this case. Display setting is invalid if there is no audio or video playing.

Radio

• Radio Region: Set the unit for one for the following regions: Europe, America, China, Russia,

Japan, RDS (on/off)

Multimedia player

• Support lots of video and audio formats

• Subwoofer: Tum the subwoofer output On or Off

• EQ-Sertting: Pop, Rock, Classic, Jazz or Off

Time

• Slide the figures in the set time interface

Language

• Language: Select desired language(English, Spanish, Deutsch, Russian, Portuguese, French,

Chinese, etc.

Camera input

• Connect the camera with this device, can be auto detected brake signal when reversing.

(Note: Camera is not included)

1 2 3 7

54 6 10

11 12

7. Steering Wheel Control Setting

8. EQ

9. Wallpaper

10. AUX

11. AutoLink

12. Settings

Car logo

• Preset car logo to match your car brand

Steering wheel control

• Set the function button on you steering wheel via the system learning setting

AUX Input

• Connect an optional audio video source to the Aux input

AM/FM Tuner Operation

Radio interface RDS turn on function

Touch Radio icon in main interface to switch to radio mode.

Multimedia player

• Support MP3.WMA.AVI,MOV,MP4,RMVB,VOB,FLV,etc media format

• Support SD,USB,MMC

• Support JPEG,BMP,PNG etc.picture format

Music interface

• The system will automatically read USB, SD.

• The user can directly click options in directory menu to perform play.

www.PyleUSA.com

Short press this buttonto downward search the station semi-automatically

Short press this button to upward search the station semi-automatically

Switch the receiving band

Locate / remote channel

Single track, In FM band, press this button to switch between STand MONO,

The default setting is ST.AM band doesn”t have this function

Scan

www.PyleUSA.com

1.Click the icon to enter the playlist

Play / Pause

Select Previous Program / Title / Song

Select Next Program / Title / Song

Volume

Selection

Title Menu

Video or Picture playing interface

Note: Sliding the controlling bar in the bottom to show the next page.

AUX in (Auxiliary device input)

Click in from the main interface SRC key in remote control to switch to

AUX in Mode.AUX in enables external media sources to connect to the

system, like camera, video games, Walkman, external navigation box

(controlled by remote controller)etc. No auxiliary device input shows at the

below picture. Connect external devices through the 3.5mm auxiliary

audio/video input. It can display the corresponding picture as the output

video.

Rearview Camera

Auto operation: After connect with reverse camera, it will automatically

detect the reverse signal and show the reverse pictures. The system will

swift to any mode to rear view lens mode automatically. When reverse is

over, the system will come back to previous mode.

Wireless BT Streaming

Wireless BT Music

The phone must support A2DP agreement. Press BT Music icon in the main interface. Under the

connected mode, click play keys in Wireless BT interface to play different music formats restored

in the phone. Due to different types of phones, music can be played either by choosing music

player on the phone or click the play key in the Wireless BT interface.

www.PyleUSA.com

EQ Setup

Phone BT Phone

Phone Book BT Music

Dialing

Call records

Phone book

Bluetooth music

Settings

Settings Default Options Function

BT On BT is in standby when the device is

turned on

Device Not Paired Device Name

When connected, the current Wireless BT

device name will be displayed. Press the

device name to display a list of available

devices that can be connected.

Connect Auto After connect with the same device one

time, it will be auto connected next time.

Auto Answer Manual Manual You must press the Talk button to answer

an incoming call

Auto All incoming calls will be automatically

answered

www.PyleUSA.com

AutoLink Software(Phone Link)

Connect yourANDROID phone or iPhone to the unit with original USB cable,

touch theAutoLink icon,open the menu,then follow the instructions.

AutoLink connects your device to yourAndroid mobile phone and iPhone

through the standard USB port and transfer the picture and sound from the

phone to the device. You can control the phone through the device's screen ,

such as receiving calls, dialing calls, listening to music, watching movies or

photos.

AutoLink
