WAVE500-2B & WAVE500-2 Manual
1. Antenna connection
2. BUS-L (+, -, L)
3. Channel 1 operation LED
4. Channel 2 operation LED
5. Programming push button
6. Memory reset jumper
7. Impulse/bi-stable jumper
8. Power supply
9. Relay 1 output
10. Relay 2 output
11. Memory card connection
12. TRO connection
TECHNICAL CHARACTERISTICS
WAVE500-2
WAVE500-2B
Frequency
868.35MHz
Coding
High security rolling code
Memory
500 codes
Number of relays
2 (expandable to 4)
Supply
230Vac
12/24Vac/dc
Power supply range
±10%
9-23 / 22-35Vdc
8-16 / 16-27Vac
Relay contacts
1A
Standby/Op. consumption
35mA / 50mA
60mA / 350mA
Access control output
(3 readers max without external power supply)
BUS-L
Op. temperature
-20⁰C to +85⁰C
Watertightness
IP54 (with glands IP65)
Box dimensions
140x220x55mm
INSTALLATION AND CONNECTIONS
Attach the rear part of the housing to the wall using the plugs and screws provided. Pass the cables
through the bottom of the receiver. Connect the power cables to the terminals marked on the circuit
board, as indicated. Connect the relay outputs and access control readers as required. Fix the receiver
cover to the rear part using the screws provided.
OPERATING
The pilot lights are activated every 5 seconds to indicate the correct power supply to the equipment.
Upon receiving a code, the receiver checks whether it is in its memory, activating the corresponding relay.
The relay activation mode is selected in either impulse or on/off using the Imp/Bies jumper (only with relay
2).
PROGRAMMING
MANUAL PROGRAMMING
Press the receiver programming button for 1 second, an acoustic signal will be heard, release the button.
The receiver will enter standard programming (see table). If the receiver programming button is held
pressed down, the receiver will enter special programming, cyclically passing from one configuration to the
next. Once the programming configuration for the transmitter to be registered has been chosen, send the
code to be programmed by pressing the transmitter. Every time a transmitter is programmed, the receiver
will issue an acoustic signal for 0.5 seconds.
After 10 seconds without programming or pressing the first two transmitter buttons, the receiver will exit
programming mode, issuing two acoustic signals of 1 sec. If upon programming a transmitter the receiver
memory is full, it will issue 7 acoustic signals of 0.5 sec. and exit programming.
Configuration of transmitter programming in the receiver
R1 LED
R2 LED
Standard programming (default option, the receiver is always
configured on pluri-channel)
The relays are activated 1st relay by channel 1, 2nd relay by
channel 2 (3rd relay by channel 1, 4th relay by channel 2)
Flashing
Flashing
Special programming
By pressing any transmitter channel, relay 1 on the receiver will
be activated
ON
OFF
By pressing any transmitter channel, relay 2 on the receiver will
be activated
OFF
ON
By pressing any transmitter channel, both relays on the receiver
will be activated at the same time*
ON
ON
* If working in ON/OFF activation mode, relay 1 will act as impulse and relay 2 as ON/OFF. Therefore, on the
first press relay 1 will close and open the contact and relay 2 will only close. On the second, relay 1 will close
and open the contact and relay 2 will open.
N.B.: Each transmitter can be configured independently on the receiver.
TOTAL RESET
In programming mode, the programming button is held down and the “MR” reset jumper is bridged for 3
secs. The receiver will issue 10 short acoustic warning signals followed by others at a faster pace to indicate
that the operation has been successful. The receiver is now in programming mode.
After 10 seconds without programming or quickly pressing the programming button, the receiver will exit
programming mode, issuing two acoustic signals of 1 sec.
USE OF THE RECEIVER
These receivers are designed for use as remote controls for garagedoors. Their use is not guaranteed for
directly activating anyotherequipment differentto thatspecified.
The manufacturer reserves the right to modify equipment specifications without prior notice.
IMPORTANT ANNEX
Disconnect the power supply before handing the unit.
In compliance with the European Directive low-voltage electrical equipment, we hereby inform users of the
following requirements:
·
For units which are permanently connected, an easily accessible circuit-breaker device must be built into
the
wiring system.
·
This unit must always be installed in a vertical position and firmly fixed to the structure of the building.
·
This unit must only be handled by a specialised installer, by his maintenance staff or by a duly trained
operator.
·
The instruction manual for this unit must always remain in the possession of the user.
·
Terminals of maximum section 3,8mm2 mustbe used for thepower supply connections.
·
Use time delayed fuses.
