Racelogic VBOX Touch v2 Manuale utente

04 Screen Layout – VBOX Touch (v2/v3)

An overview of the screen layout and buttons on the VBOX Touch using firmware version 1.5.

As the name suggests, you control VBOX Touch with the capacitive touch screen.

Generally, the different areas of the screen contain the following:

• Top of the screen (header) – indicative status information

• Centre of the screen – mode and settings information (navigate by pressing the forward and back arrows or by

swiping left or right)

• Bottom of the screen (footer)– function buttons

https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/

VBOX_Touch_(v2%2F%2Fv3)/User_Guide_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)/04_Screen_Layout_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)

LEDs

VBOX Touch has 4 LEDs above the display. These can flash in different colours and different frequency patterns

depending on the process being performed. You can learn more about the behaviour of the LEDs on VBOX Touch here.

Logging Status

The red Record Icon will show when the unit is logging

data to the SD card.

https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/

VBOX_Touch_(v2%2F%2Fv3)/User_Guide_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)/04_Screen_Layout_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)

If the icon appears white after you have initiated

logging, it means that the unit is primed for logging and

is in the process of synchronising the internal real-time

clock (RTC) to GPS time. The logging will not start until

this synchronisation process is complete.

IMPORTANT

Do not remove the SD card when the Record Icon is red. You may lose data or damage the SD card if you

remove it while the unit is logging.

SD Status

The SD Card Icon displays the status of the recording

media. When an SD card has been inserted and has

free space, the icon will be green.By tapping on the

icon when it is green, you can manually start or stop the

data logging and override the Configured Logging

Strategy.

If the unit cannot detect an SD card or the media is full

or corrupted, the icon will be red.

Satellite Status

The Satellite Icon illustrates whether the unit has a valid

satellite lock.

When a lock is acquired, this icon will be solid green.

If there is no satellite lock, the icon will flash red.

Display Mode

The header shows which Display Mode is currently selected.

https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/

VBOX_Touch_(v2%2F%2Fv3)/User_Guide_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)/04_Screen_Layout_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)

Mode Data

This area will contain information that relates to the currently selected Display Mode.

Settings Button

The Settings Button will open a Settings area which

contains menus for Display Mode Settings,

General Settings,Serial Port Settings,Diagnostic

Settings, Date & Time Settings and CAN Bus

Settings.

The Display Mode settings shown on the Settings

screen depend on which mode has been selected. You

can find information about the settings for each mode in

the specific mode areas.

Screenshot Button

By pressing the Screenshot Button you can save a full

image of what is currently shown on the screen. This

screenshot will be saved to the inserted SD card as a

1.5 MB bitmap image, orientated at 90° to the original

screen image and with the prefix 'screenshot'.

The LEDs will illuminate yellow in sequence from left to

right to display the progress of writing to the SD card.

Each LED represents 25% of the progress of the save.

When the screen capture is complete, VBOX Touch

will emit an audible confirmation notification. If the

screenshot could not be saved, for example, no SD card

is inserted or the card is full, the SD Card Icon at the top

of the screen will flash 3 times and VBOX Touch

will emit an audible error notification.

IMPORTANT

NEVER remove the SD card while a screenshot is

captured and saved as it could cause the unit to

crash!

https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/

VBOX_Touch_(v2%2F%2Fv3)/User_Guide_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)/04_Screen_Layout_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)

Results Button

You can view the test results history by

selecting the Results button at the bottom of the

current test screen.

These test results will be displayed until you choose a

new test type or you press the Reset Button.

Mode Button

The Mode Button lets you choose between the 4

Display Modes available.

Reset Button

Depending on which screen you are on, the Reset

Button will reset mode results and/or history. When

pressed, the LEDs will briefly flash green twice and the

unit will emit an audible confirmation notification. If you

press the Reset button while in Lap Timing Mode, you

will see a cancel timeout screen giving you the

opportunity to cancel the reset within 5 seconds by

pressing anywhere on the screen.

Forward/Back Arrow Buttons

You can use the

Forward and Back arrow buttons to

navigate through the Display

Mode and Settings screens.

Alternatively, you can also swipe left

or right on the screen when these

buttons are visible.

https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/

VBOX_Touch_(v2%2F%2Fv3)/User_Guide_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)/04_Screen_Layout_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)

Exit Button

You can use the Exit button to return to the previous

menu or page.

https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/

VBOX_Touch_(v2%2F%2Fv3)/User_Guide_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)/04_Screen_Layout_%E2%80%93_VBOX_Touch_(v2%2F%2Fv3)
