Racktivity ES1100 Series Manuale utente

User

Manual

ES1000 Series

ES1100 Series

EnergySwitch

Antwerpsesteenweg 19 - 9080 Lochristi - Belgium - www.racktivity.com v 2013.10.7

Contents

Contents.................................................................................................................................................2

Introduction ...........................................................................................................................................5

Features .............................................................................................................................................5

Applicable Models..............................................................................................................................6

Specifications .....................................................................................................................................7

Electrical Ratings ............................................................................................................................7

Operating Environment..................................................................................................................7

Dimensions.....................................................................................................................................7

User Account Overview ..................................................................................................................8

RS232 Specifications.......................................................................................................................9

CLI Specifications............................................................................................................................9

Safety ...............................................................................................................................................10

Certifications ................................................................................................................................11

Compliance...................................................................................................................................11

Recycling ..........................................................................................................................................12

Servicing & Repair ............................................................................................................................12

Additional Documentation ...............................................................................................................12

Getting Started.................................................................................................................................13

Receiving Inspection.....................................................................................................................13

Inventory ......................................................................................................................................13

Installation ...........................................................................................................................................14

Rack Mounting Instructions..............................................................................................................14

Mounting the EnergySwitch .............................................................................................................15

Connecting the EnergySwitch...........................................................................................................15

Overview ..............................................................................................................................................16

Front Panel .......................................................................................................................................16

Rear Panel ........................................................................................................................................17

Status LEDs .......................................................................................................................................18

Output LEDs (1-8) .........................................................................................................................18

Alarm LED .....................................................................................................................................18

Power LED ....................................................................................................................................18

Quick Configuration .............................................................................................................................19

Using the TFT Panel Display..............................................................................................................19

Activating the Display...................................................................................................................19

Controlling the Display .................................................................................................................19

Hot Keys .......................................................................................................................................19

Antwerpsesteenweg 19 - 9080 Lochristi - Belgium - www.racktivity.com v 2013.10.7

Network Settings..............................................................................................................................20

Firmware version 1.2 or higher ....................................................................................................20

Firmware version 1.1 or lower .....................................................................................................22

Web Interface ......................................................................................................................................26

Getting Started.................................................................................................................................26

Supported Web Browsers.............................................................................................................26

Logging in .....................................................................................................................................26

Layout...............................................................................................................................................27

Tabs..................................................................................................................................................28

Power ...........................................................................................................................................28

Environment.................................................................................................................................28

Logging .........................................................................................................................................28

Modules .......................................................................................................................................28

Management ................................................................................................................................29

Settings.........................................................................................................................................29

Network Configuration.....................................................................................................................30

SNMP Configuration.........................................................................................................................31

SNMP Settings ..............................................................................................................................31

Device Settings .................................................................................................................................32

Thresholds........................................................................................................................................32

Resetting Measurements .................................................................................................................34

Startup Delay....................................................................................................................................34

Priority..............................................................................................................................................35

Overheat Protection.........................................................................................................................35

Network Time Protocol (NTP)...........................................................................................................35

CLI.........................................................................................................................................................36

Connecting .......................................................................................................................................36

RS232 ...................................................................................................................................................38

Versions............................................................................................................................................38

UPS Integration ....................................................................................................................................39

Configuration ...................................................................................................................................39

Compatible Devices ......................................................................................................................39

Connecting the UPS ......................................................................................................................39

Enabling the Link ..........................................................................................................................41

Operation .........................................................................................................................................41

Rules.................................................................................................................................................42

Agent Communication..........................................................................................................................44

Configuration ...................................................................................................................................44

Antwerpsesteenweg 19 - 9080 Lochristi - Belgium - www.racktivity.com v 2013.10.7

Agent Service................................................................................................................................44

EnergySwitch Configuration .........................................................................................................47

Logging .................................................................................................................................................49

Event ................................................................................................................................................49

Measurement...................................................................................................................................49

Management Information Base (MIB)..................................................................................................51

Upgrade Firmware ...............................................................................................................................52

Obtaining Files..................................................................................................................................52

Troubleshooting ...................................................................................................................................53

Downloading the diagnostics ...........................................................................................................53

Resetting Login Credentials ..............................................................................................................53

Connecting to the Web Interface .....................................................................................................53

Knowing your EnergySwitch’ IP address...........................................................................................53

Support ................................................................................................................................................55

Antwerpsesteenweg 19 - 9080 Lochristi - Belgium - www.racktivity.com v 2013.10.7

Introduction

Features

The EnergySwitch PDU Family, EnergyOS and its included EnergyDNA deliver power within the

data center along with the energy utilization and capacity optimization features you demand.

These next-generation PDUs are a step into the future of data center energy management,

leveraging leading-edge EnergyDNA for highly granular visibility into rack-based energy quality

and consumption.

Main Features:

Real-Time, True RMS measurements

Metered and Switched per outlet

Serial out-of-band management ports

Role-based Authentication

Usage and Access Event Logging

Instant-On technology

Physical and Logical current protection

Sequential Outlet startup

Programmable Thresholds and alarms

Support for Racktivity’s EnergySensor family

Flash Upgradable

Ultra-Low power consumption

Antwerpsesteenweg 19 - 9080 Lochristi - Belgium - www.racktivity.com v 2013.10.7

Applicable Models

Unless specified otherwise, all information in this document is applicable to the following

Racktivity EnergySwitch ES1000 models:

ES1008-16

ES1108-16

Antwerpsesteenweg 19 - 9080 Lochristi - Belgium - www.racktivity.com v 2013.10.7

Specifications

Electrical Ratings

Input:

Voltage

100V - 240V

Frequency

50/60Hz

Current

16A

Output:

Connection

8x C13

Voltage

100V - 240V

Current total

16A

Current per C13

The model number, input and output ratings and certification information for the EnergySwitch

are also shown on the label found on the case of the unit.

Operating Environment

Operating temperature

0°C to 50°C

32°F to 122°F

Storage temperature

-10°C to 60°C

14°F to 140°F

Humidity

5% to 85% RH

non-condensing

Dimensions

Dimensions cm (WxHxD)

48.55 x 4.45 x 14.20

Dimensions inch (WxHxD)

19.00 x 1.75 x 5.59

Antwerpsesteenweg 19 - 9080 Lochristi - Belgium - www.racktivity.com v 2013.10.7

User Account Overview

The EnergySwitch has 3 types (levels) of user accounts: admin, restricted and guest. The

following table shows an overview of the functionality of each type:

admin

restricted

guest

Open website

Yes

Open CLI session

Yes

View current status (states, data & values)

Yes

Toggle outlets

Yes

Edit thresholds

Yes

Edit outlet names

Yes

Change SNMP notification settings

Yes

Edit device settings

Yes

View & download logs

Yes

Default user name

admin

restricted

guest

Default password

1234

The same features and options apply to both the website and the Command Line Interface (CLI).

To change the login credentials for the users please refer to the Device Settings chapter.

Antwerpsesteenweg 19 - 9080 Lochristi - Belgium - www.racktivity.com v 2013.10.7

RS232 Specifications

The RS232 ports on the EnergySwitch have the following pin lay-out (as seen on the male plug):

Compatibility

The following brands/devices can be connected directly to the RS232 ports of the EnergySwitch

using a standard straight-through RJ45 patch cable (unless noted otherwise):

Cisco

Cisco devices that have a Console which uses the pin lay-out of the 72-3383-01

Management cable (RJ45 - DB9)

Hewlett-Packard

HP devices that have a Console which uses the pin lay-out of the 5188-3836 Console

cable (RJ45 - DB9) require that Pin3 (RxD) and Pin6 (TxD) are switched

Fortinet

Fortinet devices require that Pin3 (RxD) and Pin6 (TxD) are switched

CLI Specifications

The CLI port on the EnergySwitch has the following pin lay-out (as seen on the male plug):

Function

RxD

GND

TxD

Function

TxD

GND

RxD

Antwerpsesteenweg 19 - 9080 Lochristi - Belgium - www.racktivity.com v 2013.10.7

Safety

Save these instructions!

This Safety Information contains important instructions that should be followed during

installation and maintenance of the EnergySwitch. It is intended for Racktivity customers who set

up, install, relocate, or maintain Racktivity equipment. Changes and modifications to this unit not

expressly approved by Racktivity could void the warranty.

Electrical Hazard!

Read the following information before installing or operating your EnergySwitch:

Do not work alone under hazardous conditions.

High current through conductive materials could cause severe burns.

Follow all local and national codes when installing the EnergySwitch.

To avoid possible electrical shock and equipment damage, use only the supplied hardware.

The EnergySwitch should be connected to a single-outlet dedicated circuit, protected by a

circuit breaker with the same current rating as the EnergySwitch.

The plug serves as the disconnect for the EnergySwitch. Make sure the utility power outlet

for the EnergySwitch will be close to the EnergySwitch and readily accessible.

Make sure the utility power outlet and the EnergySwitch power cord and plug are in good

condition.

Do not connect the EnergySwitch to an ungrounded utility power outlet.

Do not operate your EnergySwitch with any covers removed or when it is damaged.

This EnergySwitch contains potentially hazardous voltages. There are no user serviceable

parts inside the EnergySwitch. All repairs and service should be performed by authorized

service personnel only.

The power requirement for each piece of equipment connected to the EnergySwitch must

not exceed the individual outlet’s load rating.

The EnergySwitch provides convenient multiple power outlets, but it does not provide surge

or line noise protection for connected equipment.

The EnergySwitch is designed for indoor use only in a controlled environment away from

excess moisture, temperature extremes, conductive contaminants, dust, direct sunlight or

magnetic sources.

The total power requirement for equipment connected to the EnergySwitch must NOT

exceed the maximum load rating for the EnergySwitch.

Do not attempt to mount the EnergySwitch to an insecure or unstable surface.

Never attempt to install electrical equipment during a thunderstorm.

Use of this equipment in life support applications or any medical applications is strictly

prohibited since failure of this equipment can reasonably be expected to cause the failure of

the life support equipment or to significantly affect its safety.

Putting several EnergySwitch units in cascade is NOT allowed.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Racktivity Interruttore

Racktivity

Racktivity ES2000 Seriesl Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente
