RAGU Z400 Manuale di istruzioni
Multimedia Home Entertainment
Video Projector
Quick User Guide-Z400
To ensure safe and proper use, please read this instruction before operating the product.
English
English
1
Warranty
Contact Us
Your projector comes with a free
replacement or a full refund
within 1 year that lets your
product with confidence.
Whether you need further assistance,are looking for answers,or just
want to share your reviews with us,you will find many ways to
contact us right here.
• E-mail:[email protected]
• Call:1-262-299-0397
(available for customers in the •
United States currently)•
• Facebook:www.facebook.com/iragu001/
Download the detailed instruction •
manual using the link below:•
XXXXXXXXXXXXXXXXXXXXXXXXX•
• Don't block any
ventilation openings •
• Place the projector
on a flat surface •
• Use in a well-
ventilated area•
• Unplug the projector
after shutdown •
• Don't use the projector
near water or moisture •
• Use a soft and dry
cloth for cleaning •
• Don't use chemical
detergents to clean •
• Don't look directly
into the light •
• Don't disassemble
the projector •
Important Safety Instructions
2
English
3-in-1 AV cable
Remote controlPower cordHDMI cable
RAGUZ400 Projector
RAGU Z400 projector
Box Contents
Instruction manual
3
Note: Adjust the focus ring and the keystone ring before using
the projector. Turn off this product when not in use to prolong
the life of the projector.
English
Lens
Built-in speakerAir intake port
Keystone ring
Focus/Zoom ring
Air exhaust port
4
Product Parts
AV USB 5V-OUTHDMI
2 3 4 5 6 7
VGA
1
1. VGA port
2. SD card slot
3. AV input port
4. Audio jack
5. HDMI port
6. USB port
7. 5V output port
6. Right button
5. Ok button
4
English
1. Input button
2. Esc button
3. Left button
4. Power button
1
8
10
6
4
5
2
3
7
9
11 13
12
15
14
Remote Control
5
1. Power Button (turns the projector on or off)
2. Mute Button (turns off sound)
3. Fast Backward Button
4. Play/Pause Button (plays/stops playing audio or video)
5. Fast Forward Button
6. Ok Button (selects options)
7. Up (selects upward movement)
8. Down (selects downward movement)
9. Left (selects leftward movement)
10. Right (selects rightward movement)
11. Esc Button (cancels/exits functions)
12. Menu Button (accesses projector menu system)
13. Source Button (selects of the input source)
14. Volume Down Button (adjusts speaker volume)
15. Volume Up Button (adjusts speaker volume)
English
Projector Operations
6
1. Connect the power cord to the projector's power inlet,
press the Power Button to turn on the projector.
2. Rotate the Focus Ring and the Keystone Correction
simultaneously until to get the clear image.
English
7
3. Press the Menu Button. Press Left/Right to select Option.
Choose OSD Language under Option.
4. Press Ok to access the submenu of OSD Language and
press Up/Down/Left/Right to select the language.
English
OSD Language
日本語 English Français
Español Hrvatski
ItalianoDeutsch
Dansk
MENU
OPTION
Software Update(USB)
Restore Factory Default
OSD Language English
Color Range 0~255
OsdDuration Off
8
AV USB 5V-OUTHDMI
5. To connect a device, press the Input Button or the Source Button.
6. Select the correct input source and prepare the cable for
device connections if necessary.
English
INPUT SOURCE
PC-RGB
HDMI
AV
USB
SD CARD
