Razer BlackWidow Ultimate Stealth Edition Manuale utente
1 | razer™
Go ninja with the Razer BlackWidow Ultimate Stealth Edition. Outfitted with tactile
and silent instead of tactile and clicky mechanical key switches, gamers are getting the
same crisp, tactile actuations and gaming-grade responsiveness as they have come to
known with the award-winning original Razer BlackWidow –just with a quieter
feedback for those who favor silent sneak attacks and meticulous pwnage from the
shadows.
The newest edition of the Razer BlackWidow Ultimate Stealth comes with improved
anti-ghosting which supports up to 10 simultaneous key presses in gaming mode. This
means that gamers can assassinate the competition with as many deadly ninja key
presses as there are fingers on their hands, and have them all registered accurately in-
game.
The improved Razer BlackWidow Ultimate Stealth is a ruthless weapon of power, and it
demands a merciless gamer ready to wield it.
2 | For gamers by gamers™
CONTENTS
1. PACKAGE CONTENTS / SYSTEM REQUIREMENTS.................................... 3
2. REGISTRATION / TECHNICAL SUPPORT................................................... 3
3. TECHNICAL SPECIFICATIONS................................................................... 4
4. DEVICE LAYOUT ...................................................................................... 5
5. SETTING UP YOUR RAZER BLACKWIDOW ULTIMATE SE.......................... 6
6. USING YOUR RAZER BLACKWIDOW ULTIMATE SE .................................. 7
7. CONFIGURING YOUR RAZER BLACKWIDOW ULTIMATE SE ..................... 9
8. SAFETY AND MAINTENANCE................................................................. 22
9. LEGALESE.............................................................................................. 24
3 | razer™
1. PACKAGE CONTENTS / SYSTEM REQUIREMENTS
PACKAGE CONTENTS
Razer BlackWidow Ultimate SE Gaming Keyboard
Quick Start Guide
Master Guide
SYSTEM REQUIREMENTS
PC / Mac with 2 free USB ports
Windows® 8/ Windows® 7 / Windows Vista® / Windows® XP (32-bit) /
Mac OS X (v10.6 to 10.8)
Internet Connection
200 MB of free hard disk space
2. REGISTRATION / TECHNICAL SUPPORT
REGISTRATION
Please visit www.razerzone.com/registration for online product registration.
TECHNICAL SUPPORT
What you’ll get:
1 year limited manufacturer’s warranty.
Free online technical support at www.razersupport.com.
4 | For gamers by gamers™
3. TECHNICAL SPECIFICATIONS
Fully Programmable Mechanical Keys With 45g Actuation Force
1000hz Ultrapolling
Extreme Anti-Ghosting Capability Of Up To 10 Keys
Razer Synapse 2.0 Enabled
Individually Backlit Keys With Adjustable Brightness
20 Customizable Software Profiles With On-The-Fly Switching
Braided Fiber Cable
Approximate Size : 475 mm / 18.70” (Width) x 171 mm / 6.73” (Height) x 30 mm
/ 1.18” (Depth)
Approximate Weight: 1500 g / 3.31 lbs
5 | razer™
4. DEVICE LAYOUT
A. Volume Control Keys
B. Media Keys
C. On-The-Fly Macro Record Key
D. Gaming Mode Key
E. LED Control Keys
F. Sleep Mode Key
G. LED Indicators
H. 5 Extra Macro Keys
I. Audio Out Jack
J. Microphone In Jack
K. USB Passthrough Port
6 | For gamers by gamers™
5. INSTALLING YOUR RAZER BLACKWIDOW ULTIMATE SE
Note: You may skip Steps 2-4 if you already have a Razer Synapse 2.0 installed and an existing account.
Step 1: Plug the Razer BlackWidow Ultimate SE to your computer.
Step 2: Download the Razer Synapse 2.0 installer from
www.razerzone.com/synapse2.
Step 3: Run the installer and follow the onscreen instructions.
Step 4: Register for a Razer Synapse 2.0 account and confirm your new account.
Step 5: Open Razer Synapse 2.0 and log in to your account.
Step 6: Wait until the software automatically downloads and installs.
7 | razer™
6. USING YOUR RAZER BLACKWIDOW ULTIMATE SE
Pressing the “FN” key in combination with the function keys will activate their
secondary features.
Function Keys
Secondary Features
The audio volume controls allow you to
mute ( ), decrease ( ) and increase
( ) the audio output.
The media keys allow you to play/pause
( ) a track or skip tracks backward
( ) and forward ( ).
The LED control keys allow you to decrease
( ) or increase ( ) the brightness
of your keyboard’s LEDs.
The sleep key allows you to suspend all
operating system activities. This function
allows you to save electricity while the
computer is idle.
8 | For gamers by gamers™
ON-THE-FLY MACRO RECORDING
Follow these steps to create an OTF Macro Recording:
1. Press the key combination to start recording.
2. The Macro Recording Indicator will light up to show that the device is ready to
record.
3. Type in the keys you want to record.
4. Press FN + F9 to stop the recording or the ESC key to cancel recording. The Macro
Recording Indicator will start to blink to show that the device has stopped
recording and is ready to save the macro.
5. Press the desired key where you want to save your macro.
GAMING MODE
The Gaming Mode disables the Windows Key function to avoid accidental usage.
Furthermore, you can maximize the effect of Anti-Ghosting by activating the Gaming
mode function. You can also choose to disable the Alt + Tab and Alt + F4 functions by
using the Gaming Mode Tab in Razer Synapse 2.0. An indicator will light up when
Gaming Mode is active.
9 | razer™
7. CONFIGURING YOUR RAZER BLACKWIDOW ULTIMATE SE
Disclaimer: The features listed here require you to log in to Razer Synapse 2.0. These features are also subject
to change based on the current software version and your Operating System.
KEYBOARD TAB
The Keyboard Tab is your default tab when you first install Razer Synapse 2.0. This tab
allows you to customize your device’s profiles and key assignments.
10 | For gamers by gamers™
Profile
A profile is a convenient way of organizing all your custom settings and you can have an
infinite number of profiles at your disposal. Any changes made within each tab are
automatically saved to the current profile and stored into the cloud servers.
You can create a new profile by clicking the button or delete the current
profile by clicking the button. The button allows you to Copy, Import,
and Export profiles. Your current profile by default is named “Profile” however; you can
rename it by typing on the text field below PROFILE NAME.
Each profile can be set to FN + 0 - 9 using the SHORTCUT dropdown menu for fast
profile switching. Each profile can also be set to automatically activate when you run a
program or application through the use of the LINK PROGRAM option.
