Red Hat NETWORK 3.7 - Manuale utente

Red Hat Network 3.7

Client Conﬁguration Guide

Red Hat Network 3.7: Client Conﬁguration Guide

Red Hat, Inc.

1801 Varsity Drive

Raleigh NC 27606-2072 USA

Phone: +1 919 754 3700

Phone: 888 733 4281

Fax: +1 919 754 3701

PO Box 13588

Research Triangle Park NC 27709 USA

RHNclient-conﬁg(EN)-3.7-RHI (2005-03-16T12:14)

Open Publication License, V1.0 or later (the latest version is presently available at http://www.opencontent.org/openpub/).

Distribution of substantively modiﬁed versions of this document is prohibited without the explicit permission of the copyright

holder.

Distribution of the work or derivative of the work in any standard (paper) book form for commercial purposes is prohibited

unless prior permission is obtained from the copyright holder.

Red Hat and the Red Hat "Shadow Man" logo are registered trademarks of Red Hat, Inc. in the United States and other

countries.

All other trademarks referenced herein are the property of their respective owners.

The GPG ﬁngerprint of the [email protected] key is:

CA 20 86 86 2B D6 9D FC 65 F6 EC C4 21 91 80 CD DB 42 A6 0E

Table of Contents

1. Introduction..................................................................................................................................... 1

2. Client Applications.......................................................................................................................... 3

2.1. Deploying the Latest Red Hat Network Client RPMs ....................................................... 3

2.2. Conﬁguring the Client Applications .................................................................................. 3

2.2.1. Registering with Activation Keys ....................................................................... 4

2.2.2. Using the --configure Option ........................................................................ 4

2.2.3. Updating the Conﬁguration Files Manually ....................................................... 6

2.2.4. Implementing Server Failover............................................................................. 7

2.3. Conﬁguring the Red Hat Network Alert Notiﬁcation Tool with Satellite...................... 8

3. SSL Infrastructure.......................................................................................................................... 9

3.1. A Brief Introduction To SSL.............................................................................................. 9

3.2. The RHN SSL Maintenance Tool.................................................................................. 10

3.2.1. SSL Generation Explained................................................................................ 11

3.2.2. RHN SSL Maintenance Tool Options ............................................................ 11

3.2.3. Generating the Certiﬁcate Authority SSL Key Pair.......................................... 14

3.2.4. Generating Web Server SSL Key Sets .............................................................. 15

3.3. Deploying the CA SSL Public Certiﬁcate to Clients ....................................................... 16

3.4. Conﬁguring Client Systems ............................................................................................. 16

4. Importing Custom GPG Keys...................................................................................................... 17

5. Using RHN Bootstrap ................................................................................................................... 19

5.1. Preparation ....................................................................................................................... 19

5.2. Generation........................................................................................................................ 20

5.3. Script Use......................................................................................................................... 20

5.4. RHN Bootstrap Options ................................................................................................. 21

6. Manually Scripting the Conﬁguration........................................................................................ 23

7. Implementing Kickstart ............................................................................................................... 25

A. Sample Bootstrap Script.............................................................................................................. 27

Index................................................................................................................................................... 31

Chapter 1.

Introduction

This best practices guide is intended to help customers of RHN Satellite Server and RHN Proxy Server

more easily conﬁgure their client systems.

By default, all Red Hat Network client applications are conﬁgured to communicate with central Red

Hat Network Servers. When connecting clients to RHN Satellite Server or RHN Proxy Server, how-

ever, many of these settings must be altered. Altering client settings for a system or two may be

relatively simple. But a large enterprise environment, containing hundreds or thousands of systems,

will likely beneﬁt from the mass reconﬁguration steps described here.

Because of the complexity of this undertaking, customers have been given the option of generating and

using a pre-populated script that automates many of the tasks required to get your systems using your

RHN Server. Refer to Chapter 5 Using RHN Bootstrap for details. Nevertheless, Red Hat believes

you should understand the implications of these changes and therefore describes the manual steps for

reconﬁguration in earlier chapters. Use your best judgement in determining the ideal solution for your

organization.

Although many of the commands provided within this guide can be applied as they appear, it is impos-

sible to predict all of the potential network conﬁgurations adopted by customers. Therefore, Red Hat

encourages you to use these commands as references that must take into account your organization’s

individual settings.

2 Chapter 1. Introduction

Chapter 2.

Client Applications

Most of the enterprise-class features of Red Hat Network have required changes to the Red Hat Net-

work client applications themselves. Of course, it’s difﬁcult to get the latest versions of these applica-

tions until the systems are registered with Red Hat Network. This sort of chicken-and-egg problem is

especially problematic for customers who want to migrate large numbers of older systems to Red Hat

Network. This chapter identiﬁes techniques that may be used to resolve this dilemma.

Important

Red Hat strongly recommends that clients connected to RHN Proxy Server or RHN Satellite Server

be running the latest update of Red Hat Enterprise Linux to ensure proper connectivity.

2.1. Deploying the Latest Red Hat Network Client RPMs

Since Red Hat Update Agent (up2date) and Red Hat Network Registration Client

(rhn_register) are prerequisites for using much of Red Hat Network’s enterprise functionality,

it’s crucial to install them before trying to use RHN Proxy Server or RHN Satellite Server in your

environment.

There are several sensible approaches to doing this, but they are all similar; each involves storing the

RPMs somewhere that is accessible by all client systems and deploying the packages with the simplest

command possible. This command will vary from organization to organization.

Remember, only systems running Red Hat Enterprise Linux 2.1 need to use the Red Hat Network

Registration Client to register with RHN. Systems running Red Hat Enterprise Linux 3 and later can

use the registration functionality built into the Red Hat Update Agent.

This document presumes that the customer has installed RHN Satellite Server and/or RHN Proxy

Server on the customer network. With either server type, the latest versions of both up2date and

rhn_register should have been downloaded and installed to the RHN Satellite Server or RHN

Proxy Server itself, as part of the importing process used to get the package repository populated and

up-to-date. Known working versions of both applications are placed in the /var/www/html/pub/

directory of the Proxy or Satellite.

Conﬁrm the precise paths of the client packages before running the following command, as they may

not reside in the top-level /pub directory but instead in its subdirectories. When run from a client, this

command would then install these RPMs to that client, assuming the domain name, paths, and RPM

versions are correct:

rpm -Uvh \

http://your_proxy_or_sat.your_domain.com/pub/rhn_register-2.8.27-1.7.3.i386.rpm \

http://your_proxy_or_sat.your_domain.com/pub/rhn_register-gnome-2.8.27-1.7.3.i386.rpm \

http://your_proxy_or_sat.your_domain.com/pub/up2date-3.0.7-1.i386.rpm \

http://your_proxy_or_sat.your_domain.com/pub/up2date-gnome-3.0.7-1.i386.rpm

Note the inclusion of the associated gnome RPMs. Keep in mind, the architecture (in this case, i386)

may need to be altered depending on the systems to be served.

4 Chapter 2. Client Applications

2.2. Conﬁguring the Client Applications

Not every customer will need to connect securely to an RHN Satellite Server or RHN Proxy Server

within their organization. And not every customer will need to build and deploy a GPG key for custom

packages. (Both of these topics are explained in detail later.) But every customer who uses RHN Satel-

lite Server or RHN Proxy Server will need to reconﬁgure the Red Hat Update Agent (up2date) and

possibly the Red Hat Network Registration Client (rhn_register) to be directed to the Satellite

or Proxy.

Important

Although this isn’t conﬁgurable, users should still make note that the port used by the Red Hat Update

Agent is 443 for SSL (HTTPS) and 80 for non-SSL (HTTP). By default, up2date uses SSL only. For

this reason, users should ensure their ﬁrewalls allow connections over port 443. To bypass SSL, in

/etc/sysconfig/rhn/up2date change the protocol for serverURL from https to http. Similarly,

if you will be using RHN’s Monitoring feature and probes requiring the Red Hat Network Monitoring

Daemon, note that client systems will need to allow connections on port 4545 (or port 22, if they will

use sshd instead).

By default, the Red Hat Network Registration Client and the Red Hat Update Agent refer to the

main Red Hat Network Servers. Users must reconﬁgure client systems to refer to the RHN Satellite

Server or RHN Proxy Server. This can be done in three different ways: using the --configure op-

tion, updating the conﬁguration ﬁle(s) manually, or scripting a change to multiple settings at once. To

see how virtually all reconﬁguration can be scripted, see Chapter 6 Manually Scripting the Conﬁgu-

ration.

Note that the latest versions of the Red Hat Update Agent can be conﬁgured to accommodate several

RHN Servers, thereby providing failover protection in case the primary server is inaccessible. Refer

to Section 2.2.4 Implementing Server Failover for instructions on enabling this feature.

2.2.1. Registering with Activation Keys

Red Hat recommends using activation keys for registering and conﬁguring client systems that will

be using RHN Proxy Server or RHN Satellite Server. Activation keys can be used to register, entitle,

and subscribe systems in a batch. Refer to the Activation Keys section of the Red Hat Update Agent

chapter within the RHN Management Reference Guide for instructions on use.

It is possible to incorporate activation keys into a scripted conﬁguration process, such as the one

described in Chapter 6 Manually Scripting the Conﬁguration. To do this, create a bootstrap.sh ﬁle

much like the one described, place it in the Proxy or Satellite’s /pub directory and combine it with

the rhnreg_ks utility. For example:

wget -O http://your-satellite-FQDN/pub/bootstrap.sh | bash \

&& rhnreg_ks --activation-key b0fa829d751aEXAMPLE6983a72c8346e \

--serverUrl https://your-satellite-FQDN/XMLRPC

Warning

Systems running Red Hat Enterprise Linux 2.1 and versions of Red Hat Linux prior to 8.0 may

experience problems using Activation Keys to migrate SSL certiﬁcate settings from rhn_register

to up2date. All other settings, such as the server URL, will be properly transferred. Therefore, the

SSL certiﬁcate information on those systems will have to be set manually.

Chapter 2. Client Applications 5

2.2.2. Using the --configure Option

Both the Red Hat Network Registration Client and the Red Hat Update Agent that ship with

Red Hat Enterprise Linux provide interfaces for conﬁguring various settings. For full listings of these

settings, refer to the chapters dedicated to the applications in the RHN Management Reference Guide.

Each application offers a graphical user interface (GUI) for conﬁguration that enables you to change

the settings required by RHN Proxy Server or RHN Satellite Server. The only requirement for using

this option is to have the client systems running the X Window System. The command to launch the

GUI conﬁguration interface will look like:

application_filename --configure

To reconﬁgure the Red Hat Update Agent, as root, run the following command:

up2date --configure

You are presented with a dialog box offering various settings that may be reconﬁgured. In the Gen-

eral tab, under Select a Red Hat Network Server to use replace the default value with the

fully qualiﬁed domain name (FQDN) of the RHN Satellite Server or RHN Proxy Server, such as

https://your_proxy_or_sat.your_domain.com/XMLRPC. Retain the /XMLRPC at the

end. Then click OK.

Figure 2-1. Red Hat Update Agent GUI Conﬁguration

Make sure you enter the domain name of your RHN Satellite Server or RHN Proxy Server correctly.

Entering an incorrect domain or leaving the ﬁeld blank may prevent up2date --configure from

launching. This may be resolved, however, by editing the value in the up2date conﬁguration ﬁle.

Refer to Section 2.2.3 Updating the Conﬁguration Files Manually for precise instructions.

6 Chapter 2. Client Applications

Warning

Systems running Red Hat Enterprise Linux 3 or newer have registration functionality built into the Red

Hat Update Agent and therefore do not have the Red Hat Network Registration Client installed.

Systems running Red Hat Enterprise Linux 2.1 (and versions of Red Hat Linux prior to 8.0) still need

to reconﬁgure and use the Red Hat Network Registration Client, as well as the Red Hat Update

Agent.

To reconﬁgure the Red Hat Network Registration Client, conduct an almost identical set of steps.

As root, run the following command:

rhn_register --configure

You are presented with a dialog box offering basic settings that may be reconﬁgured. Under

Select a Red Hat Network server to use: replace the default value with the fully

qualiﬁed domain name (FQDN) of the RHN Satellite Server or RHN Proxy Server, such as

https://your_proxy_or_sat.your_domain.com/XMLRPC. Retain the /XMLRPC at the

end. Then click OK.

Figure 2-2. Red Hat Network Registration Client GUI Conﬁguration

If your version of rhn_register does not display the server ﬁeld, and you cannot upgrade to a later

version, you may enter the domain name of your RHN Satellite Server or RHN Proxy Server directly

into the rhn_register conﬁguration ﬁle. Refer to Section 2.2.3 Updating the Conﬁguration Files

Manually for precise instructions.

2.2.3. Updating the Conﬁguration Files Manually

As an alternative to the GUI interface described in the previous section, users may also reconﬁgure the

Red Hat Network Registration Client and the Red Hat Update Agent by editing the applications’

conﬁguration ﬁles.

Altri manuali per NETWORK 3.7 -

Indice

Altri manuali Red Hat Software

Red Hat

Red Hat ENTERPRISE LINUX 3 - FOR IBM S-390 AND IBM ESERVER... Manuale utente

Red Hat

Red Hat ENTERPRISE LINUX 3 - FOR X86-ITANIUMTM-AMD64 AND INTEL EXTENDED MEMORY 64... Manuale utente

Red Hat

Red Hat NETWORK 3.2 - PROVISIONING Manuale utente

Red Hat

Red Hat ENTERPRISE LINUX WS 2.1 - Manuale utente

Red Hat

Red Hat CLUSTER SUITE FOR ENTERPRISE LINUX 5.1 Manuale utente

Red Hat

Red Hat NETWORK 3.4 - PROVISIONING Manuale utente

Red Hat

Red Hat ENTERPRISE LINUX 4 - LVM ADMINISTRATOR Manuale utente

Red Hat

Red Hat NETWORK - USER REFERENCE GUIDE 2.0 Scheda informativa del prodotto

Red Hat

Red Hat ENTERPRISE LINUX 4 - DEVELOPER TOOLS GUIDE Manuale utente

Red Hat

Red Hat ENTERPRISE LINUX 4 - DEVELOPER TOOLS GUIDE Manuale di istruzioni

Red Hat

Red Hat ENTERPRISE 5.4 RELEASE NOTES Manuale di istruzioni

Red Hat

Red Hat CERTIFICATE SYSTEM 7.2 - MIGRATION GUIDE Manuale utente

Red Hat

Red Hat NETWORK SATELLITE SERVER 4.1.0 Manuale utente

Red Hat

Red Hat NETWORK 4.1.0 - Manuale utente

Red Hat

Red Hat NETWORK 4.0 - Manuale utente

Red Hat

Red Hat ENTERPRISE LINUX 3 - SECURITY GUIDE Manuale utente

Red Hat

Red Hat ENTERPRISE LINUX 4 - DEVELOPER TOOLS GUIDE Manuale utente

Red Hat

Red Hat NETWORK 3.4 - PROVISIONING Manuale utente

Red Hat

Red Hat ENTERPRISE LINUX 5.1 - LVM ADMINISTRATION Manuale utente

Red Hat

Red Hat NETWORK 4.0 - Manuale utente

Red Hat

Red Hat LINUX 7.2 - OFFICIAL LINUX CUSTOMIZATION... Manuale utente

Red Hat

Red Hat NETWORK 2.7 - ENTERPRISE Manuale utente

Red Hat

Red Hat ENTERPRISE LINUX 5 - VIRTUAL SERVER... Manuale utente

Red Hat

Red Hat ENTERPRISE VIRTUALIZATION - DATASHEET FOR... Manuale utente

Manuali Software popolari di altre marche

COMPRO

COMPRO COMPROFM Manuale utente

Muratec

Muratec OFFICEBRIDGE ONLINE Manuale utente

Oracle

Oracle Contact Center Anywhere 8.1 Manuale utente

Adobe

Adobe 65007312 - Photoshop Lightroom Manuale

Avaya

Avaya NULL One-X for RIM Blackberry Manuale utente

HP ProLiant BL420c Manuale utente

PS Audio

PS Audio PowerPlay Manuale del proprietario

Brady

Brady LOCKOUT PRO 3.0 Manuale di servizio

Avaya

Avaya Interaction Center Manuale utente

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuale

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuale utente

Oracle

Oracle Application 9i Manuale utente

Acer

Acer RDM Manuale utente

Canon

Canon Vixia HF21 Manuale utente

Canon

Canon ZR950 Manuale utente

Samsung

Samsung Auto Backup Manuale utente

Polycom

Polycom Vortex EF2201 Istruzioni per l'installazione e il funzionamento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuale utente
