Reliable F3-56 Series Manuale utente

(Note: not all versions of sprinkler shown,

please see pages 2 through 13)

Model

K-Factor

gpm/psi1/2

(lpm/bar1/2)

Approvals*

Max. Working

Pressure

psi (bar)

Sprinkler

Identication

Number (SIN)

F3-56 Dry Pendent 5.6 (80) cULus, FM, LPCB, CE. VdS 175 (12.0)

cULus 250 (17.2) R5314

F3-56 Dry Horizontal Sidewall 5.6 (80) cULus, FM, LPCB, CE 175 (12.0)

cULus 250 (17.2) R5334

F3-56 Dry Upright 5.6 (80) cULus 175 (12.0) R5324

Table A

Sprinkler Summary

*Note: Approvals may not apply to all trim, inlet thread, temperature, and/or nish combinations. See pages 2-11 for additional technical

information.

Features

• Various trim options available

• Sprinklers and trim available in a wide variety of standard and

special application nishes

• Listed corrosion resistant combinations of sprinkler and trim

available

Product Description

Model F3-56 dry sprinklers are standard-response, standard

coverage sprinklers with a nominal K-factor of 5.6 (80

metric). Available in pendent, horizontal sidewall, and upright

congurations, Model F3-56 dry sprinklers utilize a 5mm glass

bulb ordinary, intermediate, or high temperature classication

operating element.

Model F3-56 dry sprinklers are intended for installation on wet

pipe, dry pipe, or preaction systems in accordance with NFPA 13,

FM Property Loss Prevention Data Sheets, or other applicable

installation standards.

Model F3-56 dry sprinklers are available in a variety of trim

options and nish combinations as shown on the following pages.

The Reliable escutcheons and cover plates shown are the only

escutcheons and cover plates listed for use with the sprinkler.

The use of any other escutcheon or cover plate will void all

guarantees, warranty, listing, and approvals.

Standard inlet tting threads are 1” NPT or ISO7-R1 threads.

An inlet tting with 3/4” NPT or ISO7-R3/4 threads (cULus listed

only) is also available for select sprinklers for replacement of

existing sprinklers.

Table A provides a basic summary of Model F3-56 dry sprinklers.

Additional technical information is provided on the following

individual sprinkler pages.

www.reliablesprinkler.com

K-factor 5.6 (80 metric)

Model F3-56 Series

Standard-Response Dry Sprinkler

Bulletin 153 July 2023

“A” Dimension

in (mm)

Temperature

Classication

Temperature Rating

°F (°C) Glass Bulb Color Approvals Sprinkler Guard

2” to 48” (51mm to

1219mm) in 1/4” (6mm)

increments for 1”

connections or

2” to 36” (51mm to

914mm) in 1/4” (6mm)

increments for 3/4”

connections

Ordinary 155°F (68°C) Red

cULus

LPCB

CE (2381-CPR-S2006)

UKCA (0832-UKCA-CPR-S5043)

C-2

Intermediate

175°F (79°C) Yellow

200°F (93°C) Green

Table B

Model F3-56 Dry Pendent: Standard Escutcheon - SIN R5314

Note: Standard inlet tting threads are 1” NPT or ISO7-R1. Inlet tting is also available with 3/4” NPT and ISO-R3/4 threads for replacement of

existing sprinklers (cULus Listed only).

Model F3-56 Dry Pendent Sprinkler: Standard Escutcheon Figure 1

System Fitting

Inlet Fitting

1-5/8"

[41mm]

3" [76mm]

DIA.

2-1/8"

[54mm] Dia.

Hole in Ceiling

1/2" [12mm]

Nominal Protrusion

"A" Dimension Sprinkler Can

Escutcheon

Ceiling

1" [25mm]

Escutcheon

Adjustment

1/2" [12mm]

Escutcheon Adjustment

Nominal

Escutcheon

Position

1/2" [12mm]

COMDRYDET1

Note: The sprinkler can protrudes 1/2” (12mm) when escutcheon is in nominal position. Escutcheon ad-

justment provides -1/2” (12mm) to +1” (25mm) “A” dimension adjustment range.

Finish Combinations: Standard Escutcheon

Sprinkler Escutcheon(3)(4)

Bronze Polished Stainless

Bronze Laquered Brass

Chrome Polished Stainless

White Polyester(1) White Polyester

Black Polyester(1) Black Polyester

Custom Color Polyester(1) Custom Color Polyester

Electroless Nickel PTFE(1)(5) Polished Stainless

Wax(1)(2) Polished Stainless

Lead(1) Polished Stainless

Wax over Lead(1)(2) Polished Stainless

Notes:

1. UL Listed as Corrosion Resistant.

2. Clear wax used on ordinary temperature rated sprinklers; brown

wax used on intermediate temperature rated sprinklers. Brown

wax may be used on high temperature rated sprinklers where the

ambient temperature does not exceed 150°F (66°C).

3. Escutcheons do not carry corrosion resistant listings.

4. Base material is 316 stainless steel unless noted.

5. FM Approved as Corrosion Resistant.

Bulletin 153

July 2023

Page 2 of 19

www.reliablesprinkler.com

“A” Dimension

in (mm)

Temperature

Classication

Temperature Rating

F (C) Glass Bulb Color Approvals Sprinkler Guard

3½” to 48” (89mm

to 1219mm) in 1/4”

(6mm) increments for 1”

connections or

3½” to 36” (89mm to

914mm) in 1/4” (6mm)

increments for 3/4”

connections

Ordinary 155°F (68°C) Red

cULus

LPCB

CE (2381-CPR-S2006)

UKCA (0832-UKCA-CPR-S5043)

C-2

Intermediate

175°F (79°C) Yellow

200°F (93°C) Green

Table C

Model F3-56 Dry Pendent: HB Escutcheon - SIN R5314

Note: Standard inlet tting threads are 1” NPT or ISO7-R1. Inlet tting is also available with 3/4” NPT and ISO-R3/4 threads for replacement of

existing sprinklers (cULus Listed only).

Model F3-56 Dry Pendent Sprinkler: HB Escutcheon Figure 2

Note: The sprinkler can protrudes 1¼” when escutcheon is in nominal position. Escutcheon adjustment

provides -½” (-12.7mm) to +½” (+12.7mm) “A” dimension adjustment range.

COMDRYDET2

System tee

2-1/2" [64 mm] Dia. Hole

in Ceiling

3-1/2" [89 mm]

Escutcheon Dia.

Ceiling

Sprinkler Can

Escutcheon

"A" Dimension

Inlet fitting

1-1/4" [32mm]

1/2" [13mm] Escutcheon

Adjustment

1/2" [13mm] Escutcheon

Adjustment

Nominal Position of

Escutcheon

Deflector distance below ceiling

is 3-1/2" (89mm) minimum,

4-1/2" (114mm) maximum.

Finish Combinations: HB Escutcheon

Sprinkler Escutcheon(3)(4)

Bronze Chrome

Chrome Chrome

White Polyester(1) White Polyester

Black Polyester(1) Black Polyester

Custom Color Polyester(1) Custom Color Polyester

Electroless Nickel PTFE(1)(5) Stainless Steel

Wax(1)(2) Chrome

Lead(1) Stainless Steel

Wax over Lead(1)(2) Stainless Steel

Notes:

1. UL Listed as Corrosion Resistant.

2. Clear wax used on ordinary temperature rated sprinklers; brown

wax used on intermediate temperature rated sprinklers. Brown

wax may be used on high temperature rated sprinklers where the

ambient temperature does not exceed 150°F (66°C).

3. Escutcheons do not carry corrosion resistant listings.

4. Base material is cold rolled steel unless noted.

5. FM Approved as Corrosion Resistant.

Bulletin 153

July 2023

Page 3 of 19

www.reliablesprinkler.com

“A” Dimension

in (mm)

Temperature

Classication

Temperature Rating

°F (°C) Glass Bulb Color Approvals Sprinkler Guard

31/2” to 48” (89mm

to 1219mm) in 1/4”

(6mm) increments for 1”

connections or

3½” to 36” (89mm to

914mm) in 1/4” (6mm)

increments for 3/4”

connections

Ordinary 155°F (68°C) Red

cULus

LPCB

CE (2381-CPR-S2006)

UKCA (0832-UKCA-CPR-S5043)

N/A

Intermediate

175°F (79°C) Yellow

200°F (93°C) Green

Table D

Model F3-56 Dry Pendent: FP Escutcheon - SIN R5314

Note: Standard inlet tting threads are 1” NPT or ISO7-R1. Inlet tting is also available with 3/4” NPT and ISO-R3/4 threads for replacement of

existing sprinklers (cULus Listed only).

Model F3-56 Dry Pendent Sprinkler: FP Escutcheon Figure 3

Note: Do not install the Model F3-56 Dry Pendent sprinkler with the Model FP escutcheon in ceilings which

have positive pressure in the space above.

COMDRYDET3

Inlet Fitting

3-7/32"

[82 mm] Dia.

2-5/8" [67 mm] Dia.

Hole in Ceiling

"A" Dimension

Sprinkler

Cup

System Tee

Escutcheon

1/4" [6 mm]

Escutcheon Adjustment

1/4" [6 mm]

Escutcheon Adjustment

Nominal

Escutcheon Position

3/4" [19 mm] Nom.

Finish Combinations: FP Recessed

Sprinkler(1) Escutcheon(3)(4)

Bronze Brass

Chrome Chrome

White Polyester(2) White Polyester

Black Polyester(2) Black Polyester

Custom Color Polyester(2) Custom Color Polyester

Electroless Nickel PTFE(2)(5) Stainless Steel

Notes:

1. Cup for FP Recessed is unnished galvanized steel except electro-

less nickel PTFE sprinklers which are provided with a stainless steel

cup

2. UL Listed as Corrosion Resistant.

3. Escutcheons do not carry corrosion resistant listings.

4. Base material is cold rolled steel unless noted.

5. FM Approved as Corrosion Resistant.

Bulletin 153

July 2023

Page 4 of 19

www.reliablesprinkler.com

“A” Dimension

in (mm)

Temperature

Classication

Temperature Rating

F (C) Glass Bulb Color Approvals Sprinkler Guard

31/2” to 48” (89mm

to 1219mm) in 1/4”

(6mm) increments for 1”

connections or

3½” to 36” (89mm to

914mm) in 1/4” (6mm)

increments for 3/4”

connections

Ordinary 155°F (68°C) Red

cULus

LPCB

CE (2381-CPR-S2006)

UKCA (0832-UKCA-CPR-S5043)

N/A

Intermediate

175°F (79°C) Yellow

200°F (93°C) Green

Table E

Model F3-56 Dry Pendent: CCP Cover Plate - SIN R5314

Note: Standard inlet tting threads are 1” NPT or ISO7-R1. Inlet tting is also available with 3/4” NPT and ISO-R3/4 threads for replacement of

existing sprinklers (cULus Listed only).

Model F3-56 Dry Pendent Sprinkler: CCP Cover Plate Figure 4

Note: Do not install the Model F3-56 Dry Pendent sprinkler with the Model CCP cover plate in ceilings

which have positive pressure in the space above.

COMDRYDET4

Ceiling

Inlet Fitting

3-5/16"

[84 mm] Dia.

2-1/2" [64 mm] Dia.

Hole in Ceiling

3/16" [5 mm]

Cover Plate Adjustment

"A" Dimension

3/16" [5 mm]

Cover Plate Adjustment

Sprinkler Cup

System Tee

Model CCP 1/2

Cover Plate Assembly

Nominal Cover

Plate Position

7/8"

[22 mm]

Finish Combinations: CCP Concealed

Sprinkler(1) Cover Plate(2)

Bronze

White Polyester

Chrome Bright

Chrome Dull

Bright Brass

Unnished Bronze

Black Plate

Custom Color

Notes:

1. Cup for CCP Concealed is unnished galvanized steel.

2. Cover plates do not carry corrosion resistant listings.

Bulletin 153

July 2023

Page 5 of 19

www.reliablesprinkler.com

“A” Dimension

in (mm)

Temperature

Classication

Temperature Rating

°F (°C) Glass Bulb Color Approvals Sprinkler Guard

31/2” to 48” (89mm

to 1219mm) in 1/4”

(6mm) increments for 1”

connections or

3½” to 36” (89mm to

914mm) in 1/4” (6mm)

increments for 3/4”

connections.

Ordinary 155°F (68°C) Red

cULus

LPCB

CE (2381-CPR-S2006)

UKCA (0832-UKCA-CPR-S5043)

N/A

Intermediate

175°F (79°C) Yellow

200°F (93°C) Green

Table F

Model F3-56 Dry Pendent: F1 Escutcheon - SIN R5314

Note: Standard inlet tting threads are 1” NPT or ISO7-R1. Inlet tting is also available with 3/4” NPT and ISO-R3/4 threads for replacement of

existing sprinklers (cULus Listed only).

Model F3-56 Dry Pendent Sprinkler: F1 Escutcheon Figure 5

COMDRYDET5

Ceiling

Inlet Fitting

2-1/4" [57 mm] Dia.

Hole in Ceiling

System Tee

Escutcheon

"A" Dimension

1/8"

[3 mm]

2-27/32"

[72 mm] Dia.

1/4" [6 mm]

Escutcheon Adjustment

Nominal Escutcheon

Position

Collar

Finish Combinations: F1 Recessed

Sprinkler Escutcheon(2)(3)

Bronze Brass

Chrome Chrome

White Polyester(1) White Polyester

Black Polyester(1) Black Polyester

Custom Color Polyester(1) Custom Color Polyester

Electroless Nickel PTFE(1)(4) Stainless Steel

Notes:

1. UL Listed as Corrosion Resistant.

2. Escutcheons do not carry corrosion resistant listings.

3. Base material is cold rolled steel unless noted.

4. FM Approved as Corrosion Resistant.

Bulletin 153

July 2023

Page 6 of 19

www.reliablesprinkler.com

Order Dimension

in (mm)

Temperature

Classication

Temperature Rating

°F (°C) Glass Bulb Color Approvals Sprinkler Guard

5” to 48” (127mm

to 1219mm) in 1/4”

(6mm) increments for 1”

connections or

5” to 36” (127mm to

914mm) in 1/4” (6mm)

increments for 3/4”

connections.

Ordinary 155°F (68°C) Red

cULus

LPCB

CE (2381-CPR-S2006)

UKCA (0832-UKCA-CPR-S5043)

N/A

Intermediate

175°F (79°C) Yellow

200°F (93°C) Green

Table G

Model F3-56 Dry Pendent: No Escutcheon - SIN R5314

Note: Standard inlet tting threads are 1” NPT or ISO7-R1. Inlet tting is also available with 3/4” NPT and ISO-R3/4 threads for replacement of

existing sprinklers (cULus Listed only).

Model F3-56 Dry Pendent Sprinkler: No Escutcheon Figure 6

System Fitting

Inlet Fitting

1-5/8" [41mm]

Ordering

Dimension COMDRYDET_NOCAN_PEND

Note: Customer is responsible for

determining the correct deflector distance

from the ceiling or structure above.

Ref.

Available Finishes: No Escutcheon

Sprinkler

Bronze

Chrome

COMING SOON!

Bulletin 153

July 2023

Page 7 of 19

www.reliablesprinkler.com

“A” Dimension

in (mm)

Temperature

Classication

Temperature Rating

°F (°C) Glass Bulb Color Approvals Sprinkler Guard

2” to 48” (51mm to

1219mm) in 1/4” (6mm)

increments for 1”

connections or 2”

to 36” (51mm to 914mm)

in 1/4” (6mm) increments

for 3/4” connections

Ordinary 155°F (68°C) Red

cULus (Light Hazard Only)

FM (HC-1 Only)

LPCB

CE (2381-CPR-S2006)

UKCA (0832-UKCA-CPR-S5043)

C-2

(FM Only)

Intermediate

175°F (79°C) Yellow

200°F (93°C) Green

Table H

Model F3-56 Dry Horizontal Sidewall: Standard Escutcheon - SIN R5334

Note: Standard inlet tting threads are 1” NPT or ISO7-R1. Inlet tting is also available with 3/4” NPT and ISO-R3/4 threads for replacement of

existing sprinklers (cULus Listed only).

Model F3-56 Dry Horizontal Sidewall: Standard Escutcheon Figure 7

System Fitting

[76mm]

Wall

1" [25mm]

Escutcheon

Adjustment

2-3/32"

[53mm]

Ceiling

1/2" [12mm]

Escutcheon Adjustment

2-1/8"

[54mm] Dia.

Hole in Wall

4" [100mm] Min.

12" [300mm] Max.

COMDRYDET6-A

Inlet Fitting

"A" Dimension

5/8" [16mm]

Nominal Escutcheon Position

Sprinkler Can 1/2" [12mm]

1/2" [12mm] Nominal Protrusion

Escutcheon

Note: The sprinkler can protrude 1/2” when escutcheon is in nominal position. Escutcheon adjustment

provides -1/2” (-12mm) to +1” (25mm) “A” dimension adjustment range.

Finish Combinations: Standard Escutcheon

Sprinkler Escutcheon(3)(4)

Bronze Polished Stainless

Bronze Laquered Brass

Chrome Polished Stainless

White Polyester(1) White Polyester

Black Polyester(1) Black Polyester

Custom Color Polyester(1) Custom Color Polyester

Electroless Nickel PTFE(1)(5) Polished Stainless

Wax(1)(2) Polished Stainless

Lead(1) Polished Stainless

Wax over Lead(1)(2) Polished Stainless

Notes:

1. UL Listed as Corrosion Resistant.

2. Clear wax used on ordinary temperature rated sprinklers; brown

wax used on intermediate temperature rated sprinklers. Brown

wax may be used on high temperature rated sprinklers where the

ambient temperature does not exceed 150°F (66°C).

3. Escutcheons do not carry corrosion resistant listings.

4. Base material is 316 stainless steel unless noted.

5. FM Approved as Corrosion Resistant.

Bulletin 153

July 2023

Page 8 of 19

www.reliablesprinkler.com

“A” Dimension

in (mm)

Temperature

Classication

Temperature Rating

°F (°C) Glass Bulb Color Approvals Sprinkler Guard

31/2” to 48” (89mm

to 1219mm) in 1/4”

(6mm) increments for 1”

connections or

3½” to 36” (89mm to

914mm) in 1/4” (6mm)

increments for 3/4”

connections

Ordinary 155°F (68°C) Red

cULus (Light Hazard Only)

FM (HC-1 Only)

LPCB

CE (2381-CPR-S2006)

UKCA (0832-UKCA-CPR-S5043)

C-2

(FM Only)

Intermediate

175°F (79°C) Yellow

200°F (93°C) Green

Table I

Model F3-56 Dry Horizontal Sidewall: HB Escutcheon - SIN R5334

Note: Standard inlet tting threads are 1” NPT or ISO7-R1. Inlet tting is also available with 3/4” NPT and ISO-R3/4 threads for replacement of

existing sprinklers (cULus Listed only).

Model F3-56 Dry Horizontal Sidewall: HB Escutcheon Figure 8

Note: The sprinkler can protrudes 1¼” when escutcheon is in nominal position. Escutcheon adjustment

provides -½” (-12.7mm) to +½” (+12.7mm) “A” dimension adjustment range.

COMDRYDET7

System Tee

3-1/2"

[89mm]

Escutcheon Dia.

Nominal Position

of Escutcheon

Inlet Fitting

1/2" [13mm]

Escutcheon Adjustment

2 3/32"

[53mm]

Ceiling

"A" Dimension

Sprinkler Can

2 1/2" Dia.

[64mm]

Hole in Wall

4" [100 mm] Min.

12" [300 mm] Max.

Wall

1/2" [13mm]

Escutcheon

Adjustment

Escutcheon

1-1/4" [32mm] Nominal Protrusion

1-1/4"

[32mm]

5/8" [16mm]

Finish Combinations: HB Escutcheon

Sprinkler Escutcheon(3)(4)

Bronze Chrome

Chrome Chrome

White Polyester(1) White Polyester

Black Polyester(1) Black Polyester

Custom Color Polyester(1) Custom Color Polyester

Electroless Nickel PTFE(1)(5) Stainless Steel

Wax(1)(2) Chrome

Lead(1) Stainless Steel

Wax over Lead(1)(2) Stainless Steel

Notes:

1. UL Listed as Corrosion Resistant.

2. Clear wax used on ordinary temperature rated sprinklers; brown

wax used on intermediate temperature rated sprinklers. Brown

wax may be used on high temperature rated sprinklers where the

ambient temperature does not exceed 150°F (66°C).

3. Escutcheons do not carry corrosion resistant listings.

4. Base material is cold rolled steel unless noted.

5. FM Approved as Corrosion Resistant.

Bulletin 153

July 2023

Page 9 of 19

www.reliablesprinkler.com

“A” Dimension

in (mm)

Temperature

Classication

Temperature Rating

°F (°C) Glass Bulb Color Approvals Sprinkler Guard

31/2” to 48” (89mm

to 1219mm) in 1/4”

(6mm) increments for 1”

connections or

3½” to 36” (89mm to

914mm) in 1/4” (6mm)

increments for 3/4”

connections

Ordinary 155°F (68°C) Red cULus (Light Hazard Only)

FM (HC-1 Only)

LPCB

CE (2381-CPR-S2006)

UKCA (0832-UKCA-CPR-S5043)

N/A

Intermediate

175°F (79°C) Yellow

200°F (93°C) Green

Table J

Model F3-56 Dry Horizontal Sidewall: FP Escutcheon - SIN R5334

Note: Standard inlet tting threads are 1” NPT or ISO7-R1. Inlet tting is also available with 3/4” NPT and ISO-R3/4 threads for replacement of

existing sprinklers (cULus Listed only).

Model F3-56 Dry Horizontal Sidewall: FP Escutcheon Figure 9

Note: Do not install the Model F3-56 Dry Horizontal Sidewall sprinkler with the Model FP escutcheon in

walls which are positively pressurized with respect to the protected space.

COMDRYDET8

Hole in Wall

3-7/32"

[82 mm] Dia.

2-1/2"

[64 mm] Dia.

"A" Dimension

Face of Fitting

to Face of Wall

1-1/4"

[32 mm]

System Tee

Wall

4" [100 mm] Min.

6" [150 mm] Max. for UL

12" (300 mm) Max. for FM

Ceiling

Sprinkler Cup

Escutcheon

1/4" [6 mm]

Escutcheon Adjustment

Nominal Escutcheon Position

5/8" [16 mm]

Inlet Fitting

Nom.

Finish Combinations: FP Recessed

Sprinkler(1) Escutcheon(3)(4)

Bronze Brass

Chrome Chrome

White Polyester(2) White Polyester

Black Polyester(2) Black Polyester

Custom Color Polyester(2) Custom Color Polyester

Electroless Nickel PTFE(2)(5) Stainless Steel

Notes:

1. Cup for FP Recessed is unnished galvanized steel except electro-

less nickel PTFE sprinklers which are provided with a stainless steel

cup

2. UL Listed as Corrosion Resistant.

3. Escutcheons do not carry corrosion resistant listings.

4. Base material is cold rolled steel unless noted.

5. FM Approved as Corrosion Resistant.

Bulletin 153

July 2023

Page 10 of 19

www.reliablesprinkler.com

Indice

Altri manuali Reliable Sistema di irrigazione

Reliable

Reliable F156 Series Manuale

Reliable

Reliable N252 EC Manuale utente

Reliable

Reliable F1FR80VdS Series Manuale

Reliable

Reliable DH56 HSW Manuale utente

Reliable

Reliable F1FR-SS Series Manuale

Reliable

Reliable G4 Manuale utente

Reliable

Reliable F1FR-300 Manuale utente

Reliable

Reliable F1FR QREC Manuale

Reliable

Reliable F1FR-FS LO Manuale

Reliable

Reliable G5 Series Manuale utente

Reliable

Reliable F1FR LO Series Manuale

Reliable

Reliable F3QR Manuale utente

Reliable

Reliable GXLO Series Manuale

Reliable

Reliable SWC Manuale

Reliable

Reliable G5-56 Dry Manuale utente

Reliable

Reliable F1FR Manuale utente

Reliable

Reliable F1FR Manuale utente

Reliable

Reliable F1FR42 Series Manuale utente

Reliable

Reliable F3-80 Dry Pendent Manuale utente

Reliable

Reliable Reliable Manuale utente

Reliable

Reliable LT56 Series Manuale utente

Reliable

Reliable XL Manuale

Reliable

Reliable F1FR-SS Series Manuale utente

Reliable

Reliable The Non-Ferrous Concealer F4FR-NF Manuale utente

Manuali Sistema di irrigazione popolari di altre marche

Hunter

Hunter Institutional Series Manuale utente

Cellfast

Cellfast 52-305 Manuale utente

Tyco Fire Product

Tyco Fire Product Star Galaxy SGQR Manuale utente

Tyco Fire Product

Tyco Fire Product CENTRAL A Manuale utente

Oral Care Technologies

Oral Care Technologies Hydro Floss Manuale utente

Tyco Fire Product

Tyco Fire Product Gem F892 Manuale utente

Netafim

Netafim NETBEAT Manuale utente

Irrigation-Mart

Irrigation-Mart KIT-GK100-RV-B Manuale utente

Tyco

Tyco CC3 Manuale utente

OpenSprinkler

OpenSprinkler OSPi Manuale utente

EINHELL

EINHELL GE-WW 5537 E Manuale utente

Valley

Valley Bender160 Manuale utente

Toro

Toro 730 Series Guida rapida

Eden

Eden 97063-EDAMZ Manuale utente

Tyco

Tyco TY-L Series Manuale utente

Tyco Fire Product

Tyco Fire Product CENTRAL ELO-231 Manuale utente

Johnson Controls

Johnson Controls tyco ESFR-17 Manuale utente

Victaulic

Victaulic VicFlex I-VICFLEX.AQC-U Manuale utente
