QUICK GUIDE

CLIO

ENG_UD16894_2

Edito (X85 - B85 - C85 - S85 - K85 - Renault)ENG_RP_871-4_BCSK85_Renault_0

Detailed information regarding your vehicle’s use, maintenance and warranty, as well as videos and simulators,

are all only a click away in the e-Guide, accessible from the website www.e-guide.renault.com.

Translated from French. Copying or translating, in part or in full, is forbidden unless prior written permission has been obtained from RENAULT, 92100 Billancourt

2009.

WELCOME ABOARD YOUR VEHICLE

Note

Congratulations on your choice - your new vehicle has been created by RENAULT’s design teams to offer you exceptional comfort and an outstanding driving experi-

ence.

In order to make your experience as pleasant as possible, we suggest you discover the main features of your new vehicle by reading this document.

This document does not replace the driver’s handbook.

Please read the complete driver’s handbook for more detailed information on your vehicle’s equipment.

The reference guide covers all existing equipment (both standard and optional) for all models of this vehicle. Whether the equipment is fitted to the vehicle depends

on the version, the options selected and the country where the vehicle is sold.

A.S.R. (antipatinage) ................................................................................... (page courante)

ENG_UD16918_4

Sommaire (X85 - B85 - C85 - S85 - K85 - Renault)ENG_RP_871-4_BCSK85_Renault_0

Front and engine compartment

Passenger side

Rear seats

Rear of vehicle

Accessing the vehicle

Starting/Stopping the engine

Dashboard

Lighting/Wipers

Driving position

Audio system

Heating and air conditioning system

Cruise control/Speed limiter

Fuel

Gadgets

eco2

ENG_UD16895_2

Avant et compartiment moteur (niveaux) (X85 - B85 - C85 - S85 - K85 - Renault)ENG_RP_871-4_BCSK85_Renault_0

Front and engine compartment

FRONT AND ENGINE COMPARTMENT

Screen washer fluid level

Add some fluid in the reservoir 1if necessary.

Coolant level

The level indicated on reservoir 2should be be-

tween the MIN and MAX marks.

If it is necessary to top up this level, it is essential

to do so when the engine is cold.

Engine oil level

To check the oil level, use dipstick 3. The level

shown on dipstick 3should be between the MIN A

and MAX Bmarks.

Depending on the vehicle, when the oil is at the

minimum level, the message “oil” or “top up oil” is

displayed on the instrument panel.

You must observe the service intervals and the

standards governing the oils tested for your

engine. Refer to the Maintenance Service docu-

ment for your vehicle, and to Section 4 of the ve-

hicle handbook for the precautions to take when

filling with oil.

ENG_UD16897_3

Côté passager (X85 - B85 - C85 - S85 - K85 - Renault)ENG_RP_871-4_BCSK85_Renault_0

OFF

Passenger side

FRONT PASSENGER SIDE

Deactivating the front

passenger air bag

Depending on the vehicle, you may have a function

to deactivate the passenger air bag. If you wish to

fit a child seat to the front passenger seat, it is es-

sential to deactivate the air bag: with the vehicle

stationary, press and turn lock 1to OFF (refer to

Section 1 of your driver’s handbook).

With the ignition on, the indicator light on the cen-

tral display comes on.

Activation of the front

passenger air bag

You should reactivate the air bag as soon as you

remove the child seat from the front passenger seat

to ensure the protection of the front passenger in

the event of an impact.

To reactivate the air bag: when the vehicle is sta-

tionary, press and turn lock 1to the ON position.

With the ignition on, you must check that the warn-

ing light is off on the central display.

Immediately reposition the lock to ON as soon

as you stop using the child seat.

ENG_UD11374_1

Places arrière (blanc) (X85 - B85 - C85 - S85 - K85 - Renault)ENG_RP_871-4_BCSK85_Renault_0

Rear seats

Folding away the bench seat

TO FOLD AWAY THE SEAT BASE

– Lift the front of cushion A.

– lift the back of cushion Athen tilt it against the front seats.

TO FOLD DOWN THE SEATBACK

– Press button 2;

– lower seatback B.

TO RAISE THE BENCH SEAT

– Check that the seat belts are correctly positioned, then lift the seatback and lock it back in place.

– lift cushion A, place rear section 1under the seatback and press on the front of the cushion to lock the seat

base.

ISOFIX system

Each rear side seat is fitted with the ISOFIX child

seat mounting system 3.

Depending on the type of child seat used, installa-

tion requires specific precautions.

Refer to the information on “Child safety” in

Section 1 of your driver’s handbook for the spe-

cial features.

Consult your RENAULT Dealer to find out about the

equipment available for your vehicle.

REAR SEATS

ENG_UD11375_1

Arrière (blanc) (X85 - B85 - C85 - S85 - K85 - Renault)ENG_RP_871-4_BCSK85_Renault_0

Rear of the vehicle

REAR OF VEHICLE

Parking distance control

On equipped vehicles, the parking distance control

“measures” the distance between the rear of the

vehicle and any obstacles nearby.

When approaching an obstacle during manoeuvres,

the beeps become faster and then sound continu-

ously when 25 cm from the obstacle.

You can temporarily or permanently deactivate the

system using the switch located on the dashboard:

refer to your Driver’s Handbook.

Luggage compartment

STORAGE CAPACITY

Depending on the vehicle, the storage capacity of

the luggage compartment on your Clio may be ad-

justable.

MOBILE FLOOR

Depending on the vehicle, a mobile floor can be

used to make loading easier.

Refer to Section 3: “Rear parcel shelf/luggage

compartment features” in your driver’s handbook

to store the mobile floor.

Tyre inflation kit/

Emergency spare wheel

Depending on the vehicle, in the event of a punc-

ture, there is either a tyre inflation kit or emergency

spare wheel available. To access it, lift the luggage

compartment carpet.

Refer to Section 5 of your driver’s handbook.

ENG_UD11317_1

Accès au véhicule (X85 - B85 - C85 - S85 - K85 - Renault)ENG_RP_871-4_BCSK85_Renault_0

Accessing the vehicle

ACCESSING THE VEHICLE

RENAULT “HANDS-FREE” CARD VERSION

The RENAULT card system replaces the tradi-

tional key. Locking/unlocking the vehicle is simple:

whether from a distance or nearby, a single press

is required.

Special features

The detection zone of the card, necessary for lock-

ing and unlocking the vehicle, depends on the sur-

rounding environment or the location of the card.

With the card on your person (you can leave it in

your pocket, bag etc.), in addition to the remote

control card functions, the following are possible:

– automatic unlocking by pulling a door handle;

– automatic locking by pressing the button on the

driver’s door handle.

Note: if required, you can use the manual mode or

the key 2. Pull to release it.

Remote control key/

RENAULT card

Press:

‡

to unlock;

…

to lock;

†

to lock/unlock the luggage compartment

only.

In all situations:

– two flashes of the direction indicator lights con-

firm locking,

– one flash of the direction indicator lights con-

firms unlocking.

Special note

…

For vehicles equipped with deadlocking,

pressing this button twice in succession prevents

the doors from being unlocked, even from the

inside.

Special note on switchblade key

To release the key, press button 1. It is released

from the unit. To return it, push it into its housing.

Never leave a key or RENAULT card inside the

vehicle.

ENG_UD14448_2

Démarrage/arrêt du moteur (X85 - B85 - C85 - S85 - K85 - Renault)ENG_RP_871-4_BCSK85_Renault_0

Starting/Stopping the engine

STARTING/STOPPING THE ENGINE

Automatic transmission

With the lever in position P, press button 2.

Note: for vehicles fitted with the hands-free

RENAULT card, the brake pedal must be depressed

to allow the engine to be started.

Stopping the engine

REMOTE CONTROL KEY

With the vehicle stopped, turn the key towards

you.

RENAULT CARD

With the vehicle stationary, press button 2.

Accessing functions

Turn the key through two positions in order to

access certain functions (radio, navigation, wipers

etc.).

Hands-free card version

Depending on the case, these functions will switch

off at the latest when the vehicle is locked.

AUTO

Starting the engine

REMOTE CONTROL KEY

With key 1in the ignition switch, turn it fully on.

Once the engine has started, release it.

Note: on diesel versions, several seconds may

pass between turning the key and the engine start-

ing to allow for engine preheating.

Vehicle fitted with automatic transmission

Before starting, position the lever at Nor P.

RENAULT CARD

With the remote control RENAULT card in reader 3

or the hands-free RENAULT card in the interior de-

tection zone (excluding certain high locations such

as the sun visor, etc.) apply the following starting

conditions:

Manual gearbox

With the gear lever in neutral, press button 2.

ENG_UD11376_1

Planche de bord 1/2 (blanc) (X85 - B85 - C85 - S85 - K85 - Renault)ENG_RP_871-4_BCSK85_Renault_0

Dashboard

DASHBOARD (1/2)

12 3
