Revo REVDM600-1 Manuale utente
1/3” 410K Sony Super HAD ll Color CCD
600 TV Lines of resolution
Advanced DNR (Digital Noise Reduction)
D-WDR for clear vivid pictures where strong back-lighting occurs
3.6mm fixed lens
Flush vandal dome with surface base
Gimbal bracket
Compact design
Weatherproof IP-66 compliant
Dimensions
CAUTION
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
Installation
’
Features
S
82.4
66.4
28.4
60
82.4
60.9
60
TV System NTSC PAL
Dimensions (mm) Flush : 61mm(D) x 82.4mm(L)
Surface : 66.4mm(D) x 82.4mm(L)
Weight(g) 400g
Operating Temp. -10 ~ +50
Number of Pixels H768 752
V494 582
Scanning Frequency H15.734KHz 15.625KHz
59.94Hz 50Hz
V
Scanning System 2:1 Interlace
Gamma Correction 0.45 Approx.
Gain Control Automatic
Video Output Composite Video 1.0Vp-p/75Ω
Lens
Fixed 3.6mm Lens
Horizontal Resolution Color : 600TV Lines
S/N Ratio More than 50dB
Min. Sensitivity 0.1 Lux at F : 1.4
IR LED 11 pcs of IR LEDs
Power Source
1.7 Watt
Power Consumption
Image pick-up Device
L o c k S c re w
by L - wrench
Fix the surface mount bracket to a wall
or ceiling using suitable screws
Fix the camera base onto the mount
surface bracket using screws and adjust desired
focus and scene by turning the camera bracket
Fix the dome cover onto the base using
the L-wrench
IR Smart for better night vision performance
Digital Zoom
Model No. : REVDM600-1
(DC 12V 140mA /NTSC)
REVO AMERICA
700 FREEPORT PARKWAY SUITE 100 COPPELL,
TX 75019 U.S.A TEL: 1-866-625-REVO(7386)
12VDC, 140mA minimum
All specification and pictures are subject to change without notice to improve quality.
