RGF PTAC Manuale utente
Cleaner, Fresher Air in 24 Hours
New Advanced Environmental Air Treatment System
For PTAC & ETAC Units
NOTE: lease take time to read the attached assembly instructions.
All instructions and precautions should be adhered to while
operating this system.
Manufactured in the USA by RGF Environmental Group, Inc.
RGF Environmental Group, Inc.
Copyright 2012
TAC 9-2012
The TAC HI Unit by RGF
The HI line of products are designed to help eliminate sick building syndrome
risks by reducing odors, air pollutants, bacteria and cold and virus causing
germs through the patented hotohydroionization®( HI) process. The HI
Cell easily mounts into existing TAC air conditioning, heating and heat pump
units. When the TAC system is in operation, the HI Cell uses an Advanced
Oxidation rocess to reduce airborne contaminants.
Quad-metallic coating
roprietary UVX Long
life lamp
HI Cell Features
Figure 1
Figure 2
Incoming air containing bacteria,
mold, smoke, virus and VOCs
Typical Installation
urified air distributed to
conditioned space Air Knight TAC unit
TAC HI Unit
INSTALLATION INSTRUCTIONS
Your kit contains the following:
• TAC unit with high voltage 208-265V ballast and 3’ leads
• Four (4) mounting screws
• Four (4) wire nuts
• Two (2) wire tap splice connectors
• Instruction manual
NOTE: BE SURE TAC UNIT IS UN LUGGED AND OWER IS
DISCONNECTED BEFORE ROCEEDING WITH INSTALLATION.
INSTALLATION INSTRUCTIONS:
1. Remove plastic housing from TAC unit by carefully lifting tabs off metal
frame.
CAUTION: NEVER LOOK DIRECTLY AT AN ILLUMINATED HI CELL.
THIS DEVICE RODUCES GERMICIDAL UV LIGHT AND WILL CAUSE
DAMAGE TO EYES
Figure 3
Guardian Air REME HVAC Cell REME or Re-
flective Electro Magnetic Energy utilizes an
electromagnetic energy cell to create ionized
hydro peroxides™, a friendly oxidizer plasma
made from oxygen and humidity. This air purify-
ing plasma is propelled into the HVAC duct or
plenum by a silent plasma propulsion module
that has no moving parts, yet propels the
plasma at 2 cfm. This provides for fan or blower-
less operation on a 24-hour basis. The purifying plasma will be propelled
through the ducts whether the fan or blower is on or not. 24 volt installation
lets the REME run 24/7 without wiring to the fan/blower circuit. The oxidizer
plasma transfers the electrical charge (positively and negatively charged ions)
from the hydro peroxides to suspended (airborne) particles in the occupied
space causing them to bond together. This makes them too heavy to float en-
abling them to be drawn back to the filter. This is an excellent solution for in-
divuals that suffer from dust and dander allergies.
RGF’s Guardian Air HI is designed to elimi-
nate sick building syndrome risks by reducing
odors, air pollutants, VOCs (chemical odors),
smoke, mold, bacteria and viruses*. The HVAC-
HI Cells are easily mounted into air condition-
ing and heating systems air ducts where most
sick building problems start. When the HVAC
system is in operation the HVAC- HI Cell cre-
ates an Advanced Oxidation rocess consisting of: Hydro-peroxides, super
oxide ions and hydroxide ions. All are friendly oxidizers that revert back to
oxygen and hydrogen after the oxidation of the pollutant.
Additional RGF roducts
In Duct Microbe, VOC and Allergen Solutions
Figure 5
Figure 4
2. Remove metal screen by removing the 6 screws. (Refer to figure 4)
3. Attach unit to screen using the 4 screws. (Refer to figure 5)
LIMITED WARRANTY
This warranty supersedes and replaces any warranty statements made orally
by the Sales erson, Distributor, or Dealer, or contained in the written instruc-
tions or other brochures or informational documents related to this product.
Manufacturer warrants the new TAC HI equipment to be free from defects in
material and workmanship under normal use and service when operated and
maintained in strict accordance with manufacturer’s instructions for a period of
twelve (12) months parts only. Shipping not included.)
Manufacturer’s obligation under this warranty is limited to repairing or replacing
any part found to its satisfaction to be so defective. The manufacturer at its dis-
cretion may replace / exchange the defective unit up to 90 days from the date
of purchase. Hereafter it will need to be returned under a Returned Materials
Authorization (RMA) for review and or repair (if found defective). This warranty
does not cover parts damaged by decomposition from chemical action or wear
caused by abrasive materials, nor does it cover damage resulting from misuse,
abuse, or any other than its intended use, accident, neglect, or from improper
operation, maintenance, installation, modification or adjustments.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE
DESCRI TION ON THE FACE HEREOF.
To obtain warranty service and return authorization number, contact your
contractor or supplier.
Model number: UNV- TAC
Replacement cell part number: HIC-5GA
Hg- LAM CONTAINS MERCURY Manage in accord with disposal laws.
See: www.lamprecycle.org
Electrical Connection:
8. Mount ballast to inside of electrical enclosure cover by first
removing cover
Figure 10
9. Using double stick tape mount ballast to inside of electrical
enclosure cover.
Figure 11
LIMITED WARRANTY COMMON QUESTIONS
How long is the warranty?
•For one (1) year from initial start up.
Are there any parts not covered by this warranty (that the manufaturer
will not repair or replace)?
•Yes. arts damaged by decomposition from chemical action, hu-
midity, moisture, or wear caused by abrasive materials. It does not
cover damage resulting from misuse, abuse, or any other use
other than its intended use. This warranty does not cover acci-
dent, neglect, or from improper operation, maintenance, installa-
tion, modification or adjustments.
• arts not made by Manufacturer. However, your supplier will
process the claim with the other manufacturer.
Steps to take when you have determined that your equipment is mal-
functioning within the warranty period.
•Call your contractor or distributor and notify them of the problem or
malfunction. (It may be a simple problem or oversight with a
simple solution.)
•If it is determined that a part is malfunctioning due to a defect, ship
unit to your supplier or call supplier for other means of
return. An Equipment Warranty Form should be completed and
included.
•Your supplier will repair or exchange the defective unit with a work-
ing replacement.
Things I should do to avoid problems or injuries when running my
TAC HI Equipment.
•Thoroughly read and understand all Operating Instructions,
Warnings and recautions before commencing application.
• lace unit in a dry area when possible.
• Using wire strippers remove 1/2” of insulation from ends of ballast wires
and cell wires.
• Using supplied wire nuts attach wires from cell to wires from ballast.
Blue to blue and red to red.
Figure 12
Figure 13
• Replace screen.
• Replace cover.
• Reconnect power and turn on unit to verify HI unit operation.
(Should notice faint blue glow from outlet vent area.)
• Replace enclosure cover
• Ensure HI power cord is routed as shown (see figure 18)
• Ensure wire does not interfere with squirrel cage operation.
Figure 18
• Locate input power cord terminal (directly below capacitor) and connect
black wire (line) using supplied wire tap splice connector.
• To use the wire tap splice terminal first place around wire and press firmly.
• Now remove 1/2” of insulation from ballast power wire and press into holes
on wire tap splice. White to white (neutral) black to black (line).
• Locate terminal N1 and connect white wire (neutral) using supplied wire
tap splice connector.
Figure 14
Figure 15
Capacitor
Figure 16
Figure 17
