Ricoh BR-C1a Basic Manuale

BR-C1 Training

Slide 1 Version 1.0

D179/D180/D181

Service Training

BR-C1

This course explains the new series of high-end black-and-white copiers BR-C1.

These new models are successors to the Katana series.

BR-C1 Training

Slide 2

D179/D180/D181

Service Training

Product Overview

This section provides an overview of the machine, and the options that can be

installed.

BR-C1 Training

Slide 3

Three Models

BR-C1a SP (D179), BR-C1a Basic (D179, N. America only)

95 ppm (A4/LT LEF)

The BR-C1a Basic for N. America does not have scanner

and printer units built in. It can be upgraded with a

printer/scanner kit.

BR-C1b SP (D180)

110 ppm (A4/LT LEF)

BR-C1c SP (D181)

135 ppm (A4/LT LEF)

The machine is very similar to the Taurus (except that the

Taurus is a color engine).

Differences from the Taurus will be explained during this

course, and new points that are unique to the BR-C1.

Model Names

BR-C1a Basic: Pro 8100EX

BR-C1a SP: Pro 8100S

BR-C1b SP: Pro 8110S

BR-C1c SP: Pro 8120S

BR-C1 Training

Slide 4

Basic System

The ADF (single-pass duplex) is built in.

Finisher SR5050 A4/LT LCIT

RT5070

This shows minimal optional peripherals attached.

BR-C1 Training

Slide 5

Full System - 1

1. Main Machine

2. LCIT RT5080 (A3)

3. Multi Bypass Tray BY5010

4. Cover Interposer Tray

CI5030

5. Multi-Folding Unit FD5020

6. Ring Binder RB5020

7. Booklet Finisher SR5060

8. Trimmer Unit TR5040

There will be more details on the peripherals later.

BR-C1 Training

Slide 6

Full System - 2

If the Trimmer Unit is not installed, the booklet tray for the

Booklet Finisher must be installed to hold stapled booklets.

The booklet tray must be removed from the finisher in order to

install the Trimmer Unit.

1. Main Machine

2. LCIT RT5080 (A3)

3. Multi Bypass Tray BY5010

4. Transit Pass Unit for Perfect

Binder Type S1

5. Perfect Binder GB5010

6. Cover Interposer Tray for

Perfect Binder Type S1

7. Booklet Finisher SR5060

No additional notes

BR-C1 Training

Slide 7

Full System - 3

1. Main Machine

2. LCIT RT5080 (A3)

3. Multi Bypass Tray BY5010

4. Multi-Folding Unit FD5020

5. Booklet Finisher SR5060

6. Trimmer Unit TR5040

No additional notes

BR-C1 Training

Slide 8

Full System - 4

1. Main Machine

2. LCIT RT5080 (A3)

3. Multi Bypass Tray BY5010

4. Cover Interposer Tray CI5030

5. Booklet Finisher SR5060

No additional notes

BR-C1 Training

Slide 9

Rules About Installing Peripherals

Either of the two LCITs can be installed on the right side of

the main machine.

The Multi Bypass Tray can be installed on top of either

LCIT.

The Decurl Unit is installed inside the main machine.

Either the Perfect Binder or the Ring Binder can be

installed, but these units cannot be installed together at the

same time.

If the Multi Folding Unit is installed, the Booklet Finisher or

Finisher must be installed as the last unit downstream.

The Trimmer Unit can be attached only to the Booklet

Finisher, not the Finisher.

The booklet tray of the Booklet Finisher must be removed

in order to install the Trimmer unit.

If the Trimmer Unit is not installed, the booklet tray of the

Booklet Finisher must be installed.

No additional notes

BR-C1 Training

Slide 10

Options: Paper Feed

Taurus-C1NewD738: Cover Interposer Tray

CI5030

Katana-C2NewD733: LCIT RT5070

Taurus-C1D517: Multi Bypass Tray

BY5010

Also used with these

models:

Taurus-C1NewD732: LCIT RT5080

NoteSimilar to:

No additional notes
