Ricoh Ri 100 Guida rapida

Notes for Users

This supplement includes corrections and additional information for the manuals

provided with this machine.

Operating Instructions

Safety Information > Safety Precautions to Be Followed > Handling the main

machine

Correction

Error Corrections

Do not put fabrics on the front cover

while it is open. Doing so may damage

the machine, cause injury or burns.

Do not put objects on the front cover

while it is open. Doing so may damage

the machine, cause injury or burns.

Do not open the front cover if the fabric

smokes or ignites. Doing so may cause

a fire.

Disconnect the power plug immediately

from the outlet if the fabric smokes or

ignites. Do not open the front cover.

Doing so may cause a fire.

Do not touch the terminals with your

hand or a metal object. Doing so may

cause a short circuit, resulting in smoke

or fire.

This caution does not apply to this ma-

chine.

Safety Labels of This Machine > Positions of WARNING and CAUTION labels

Correction

Error Corrections

1 2

DSA131

1, 2.

Do not touch the surroundings de-

scribed by the safety symbol labels.

1 2

DSA131

Do not touch the inside of the finisher

because it may become very hot. Do-

ing so may cause burns.

The weight of the finisher is about 16.5

kg (36.4 lb.). When moving the finisher,

hold the handle at the center bottom of

both sides and lift it slowly so that you

do not strain your body.

Do not touch the inside of the finisher

because it may become very hot. Do-

ing so may cause burns.

Smoothing Wrinkles/Flattening Fibers (Press ) > Standard mode

Smoothing Wrinkles/Flattening Fibers (Press ) > Professional mode

Fixing Ink (Fix ) > Standard mode

Fixing Ink (Fix ) > Professional mode

Correction

Error Corrections

Take out the cassette.

Remove the cassette, and then close

the front cover. An alarm sounds if you

leave it open more than 10 seconds.

Take out the cassette.

Remove the cassette, and then close the

front cover. If you leave it open more

than 10 seconds, an alarm sounds to

warn you of risks such as injury or burns.

Troubleshooting

Correction

Error Corrections

After the high temperature caution

indicator goes out, wait until the heater

cools down sufficiently, and then wipe

off the dirt.

After the high temperature caution in-

dicator goes out and the heater cools

down sufficiently, wipe off the dirt with

a soft, dry or damp cloth.

Specifications

Correction

Error Corrections

■Power consumption

1,000W

■Power consumption

980-1,160W

980-1,300W

Operating Instructions

Additional information

• This appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or

lack of experience and knowledge if they have been given supervi-

sion or instruction concerning use of the appliance in a safe way and

understand the hazards involved.

• Children shall not play with the appliance.

• Cleaning and user maintenance shall not be made by children.

Safety Information

Additional information

• This product can be safely used in areas whose height above sea level is 2,500

meters (8,202.1 feet) or below.

Safety Information > Safety Precautions to Be Followed > Handling the main

machine

Additional information

• When loading or removing a cassette, hold the part (a). If you hold another

part, you might be burned.

(a)

DXD001

• The high-temperature state inside the machine may continue. As it may cause

injury or burns, be sure to close the front cover (b) after removing the cas-

sette.

DSB061

(b)

Precautions when using the machine

Additional information

• Take out the cassette from the finisher soon after pressing (smoothing wrinkles/

flattening fibers) or fixing ink is completed. Leaving the cassette in the hot finisher

for a long time may cause the cassette to malfunction.













 











































 

1 2

DSA131





1 2

DSA131























 

 

 

 



 























 

















 

■

W

■

W

W







 








