Ritetemp 6020 Manuale utente

PG 1

PG 2

Statement of use: The 6020 can be used with millivolt,

24VAC, 1 and 2 stage conventional gas/oil/elec heat, 1 and 2

stage heat pumps, 2 or 3 wire zoned hot water, zoned forced

air, 1 and 2 stage cooling and hybrid systems. 

It cannot be used with 120 volt heating systems.

HEAT

COOL

OFF

FAN

AUTO

TEMP

UP button

TEMP DOWN button

Temperature

Display HEAT/COOL

Mode Switch

Fan

Switch

Configure

Set HEAT/COOL mode switch to HEAT or COOL. The unit will display the

Room temperature. Set the Fan switch to AUTO.

Press the TEMP UP and TEMP DOWN buttons to select the desired

temperature. The TARGET icon will be displayed with your desired

temperature. (Display will return to room temp in 5 sec).

In the winter, set the system switch to HEAT to control your heating system.

In the summer, set the system switch to COOL to control your AC.

In spring and fall or when windows are open, 

you can set the system switch OFF.

Setting the FAN switch to AUTO automatically runs your system's fan during

heating and cooling.

Setting the FAN switch to ON runs your system's fan continuously even

without heating or cooling.

Operate

Farenheit/Celcius

indicator

Current Temperature

Display SET Temperature

Display

ROOM TEMP TARGET TEMP

Operation 6020

PG 4

Celsius

jumper

Reset

button

Aux Only

Heat Pump

Customer Support: 877-505-2353 Visit our webiste

www.ritetemp-thermostats.com 1611-010

/ C

Select

The F/C jumper is under the top cover Jumper #5. It determines which

temperature system is displayed on the LCD display. With the jumper off, the

display is Fahrenheit (default setting), with the jumper on both pins, the

display is Centigrade. When the jumper is changed, the unit must be reset

(under the top cover on the left).

Low Battery

When the batteries are low, the battery icon will flash. The two AAA

batteries in the unit need to be replaced. The HVAC system will stop

functioning when the thermostat loses power; replace batteries as soon

as you see this warning. Press RESET after replacing batteries

If you have a heat pump with auxiliary heat, and the heat pump is not

working, you can use the auxiliary heat only by moving jumper 1 [heat pump]

to jumper position 2 [ Aux only].

1234567

To set a Heat Pump's Aux only mode
