Ritetemp 6010 Manuale utente

PG 1

PG 2

Statement of use: The 6010 can be used with most 24

volt gas, oil or electric heating systems, zoned heating

systems, heat pumps with or without auxiliary heat, or

gas millivolt heating systems. It cannot be used with

120 volt heating systems.

Configure

•

Set HEAT/COOL mode switch to

HEAT or COOL. Set the Fan

switch to AUTO (automatic).

Once you have installed the

thermostat, follow the instructions

below to operate your new

thermostat.

Your thermostat is now in operation.

•

In the winter, set the mode switch to

HEAT to control your heating system.

•

In the summer, set the mode switch to

COOL to control your air conditioner.

•

In spring and fall or when windows are

open, you can set the mode switch OFF.

•

Setting the FAN switch to AUTO

automatically runs your system's fan

during heating and cooling.

•

Setting the FAN switch to ON runs your

system's fan continuously even without

heating or cooling.

NOTE: LED blinks when batteries are low.

Caution: System will stop when batteries die.

Set Temp

Operate

Turn the Temperature control to

select the desired temperature.

•

Warmer - to the right

•

Cooler - to the left.

COOLER WARMER

Temperature

Control

Thermometer HEAT/COOL

Mode Switch

Low Battery

indicator

Fan

Switch

ENGLISH

Operation 6010

50 - 60 - - 80 - 90

Heat Pump EMER Switch

Gas/ Electric

jumper

EMER

latch

Circuit

Board

NOTE: If you have a HEAT PUMP with

auxiliary heat this section applies to

your system.

If your Heat Pump malfunctions or

cannot maintain your desired

temperature you may occasionally need

to access the EMER position on the

mode switch. This enables your auxiliary

heat source and will continue until you

turn it off.

• This is done by lifting the EMER latch and moving

the mode switch to the EMER position.

• Return the mode switch to HEAT position as

soon as the heat pump is again available. Auxiliary heat is more

expensive to use.

RC ORH B

GAS ELECT

1611-016

Customer Support: 877-505-2353

or Visit our website www.ritetemp-thermostats.com

Printed in China

50 - 60 - - 80 - 90

50 - 60 - 70 - 80 - 90
