Page 4Rize Engineering Manual 2022 Ver. 6
SECURITY KWIK-LOCS:
Security Kwik Locs, like standard Kwik Locs, are to be used on
static load applications only. However, Security Kwik-Locs offer
more reliability in instances where your static load may become
dynamic by flying objects, unexpected movement or striking. The
locking bolts on the Security Kwik-Loc hold the inside locking
wedge in place and disable the release pin feature until the locking
bolt is manually loosened.
CABLE:
Galvanized steel cable supplied by Rize Enterprises is
manufactured to exact standards and statistically tested
to verify the breaking strength. Using cable supplied by
Rize Enterprises ensures the safety and integrity of the
hanging system. Wire is available in WC1, WC2, WC3,
WC4, WC6, and WC8.
CABLE COUNTER LID:
An easy solution for the contractor to measure the cable
to length. The lid fits on a standard five-gallon bucket,
which can be used to easily transport cable, tools and
Kwik-Locs on the job site.
SAFETY CABLES:
Safety Cables are commonly used for lighting in the oil,
gas, and mining industries.
KV BRACKET
The KV bracket assembly enhances the Rize suspension system by
the addition of an integral bracket, which fastens the cable lock to
rectangular ductwork or signage with sheet metal screws. Once the
KV assembly bracket is attached to the duct, the wire rope “drop” is
passed into the entry hole at the top of the bracket, through the cable
lock, and out the exit hole at the bottom. The locking teeth inside the
cable lock engage the wire rope and secure the system in place. An
accessible release pin allows for adjustments without the use of any
special tools.
PATENT #7,770,849
