Robomow RS Manuale utente

Follow

me!

Quick start guide

Watch

the

Video

For RS Models

1 2 3

Left turns Right turns

20cm

90°

45°

5 6

4

1

2

3

4

45

5

6

Wire Setup

Carefully read and review all safety instructions,

warnings and cautions contained in the

Operating & Safety Manual.

Main Zone

Main Zone

Sub-Zone

1

Separated Zone

A

Base Station Location

Chap. 1.1.4

Corners

Chap. 1.6.1, 2.2.1

Wire Direction & Distance

Chap. 2.1.2

min 3m

Leave 30cm

at starting

point

32cm from edge

40cm from wall

Min 3m after corner

Avoid

slopes

Max 20m

Anti

Clockwise Obstacles Inside Lawn

Chap. 1.6.1, 2.2.1

Hard obstacle

Soft obstacle

Both wires under

same peg

w

w

Main Zone Main Zone Main Zone Main Zone

Sub-Zone

Sub-Zone

Main Zone

Seperated

Zone

Chap. 1.3, 2.3 Chap. 1.2.2, 2.2.2 Chap. 1.2.2 Chap. 1.2.1

Multiple Zones & Narrow Pass Finish

Connect the wire

W 1.2m 1.2m W 2m 2m W 5m W 5m

7 8

10

9

11 12

13

14 15

1716

Base Station Installation

Remove charging adaptor

Chap. 2.6.3 A - Pull

B - Push

Assemble adaptor

Chap. 2.6.3

Insert 2 stakes

Chap. 2.7

Connect the wires

Chap. 2.6.3

Power Box Installation

Chap. 2.8 Mount Bracket

Connect 20m extension cable

12

11

13

Add pegs

Insert fuse

Chap. 3.1

Follow instructions on Robomow LCD

Chap. 3.3.1- 3.3.3

Setup complete

One-Time Setup

Mowing Schedule is On

Mowing Schedule is Off

Mower is in winter charging

Battery is in charging

Battery is fully charged

Next operation time

Mowing Height

Indicator

Mowing Adjustment Knob

(Push & Turn)

Safety Switch

Chap. 3.1

Docking

Indicator

On/Off

Button

Wire

Indicator

Operating

Indicator

Chap. 2.9

button is used to

cancel selection and to

move one step back in

the menu

Reference

Rain Sensor

GO button is used to

select menu option or

to confirm displayed

message.

Current Day and Time Anti-theft is activated Scroll arrows for menu selection

DOC6013E
