Rocket Fish RF-MRBTAD Manuale utente

User Guide Guide de l’utilisateur Guía del Usuario

Micro BT 2.1 EDR USB Adapter

Micro-adaptateur USB Bluetooth 2.1 + EDR

Micro adaptador USB para Bluetooth 2.1 + EDR

RF-MRBTAD

08-1322_RF-MRBTAD_COMBINED.fm Page 1 Tuesday, May 13, 2008 2:09 PM

08-1322_RF-MRBTAD_COMBINED.fm Page 2 Tuesday, May 13, 2008 2:09 PM

RF-MRBTAD

Rocketfish RF-MRBTAD RF Micro

BT 2.1 EDR USB Adapter

Contents

Introduction ................................................................................................... 3

Features ........................................................................................................... 4

Installing the software................................................................................ 5

Connecting to a Bluetooth device.......................................................15

Uninstalling the software........................................................................20

Troubleshooting .........................................................................................20

Legal notices................................................................................................21

One-year limited Warranty .....................................................................25

Français .............................................................. 29

Español............................................................... 55

Introduction

Congratulations on your purchase of a high-quality Rocketfish

product. Your RF-MRBTAD represents the state of the art in

Bluetooth adapter design and is designed for reliable and

trouble-free performance.

08-1322_RF-MRBTAD_COMBINED.fm Page 3 Tuesday, May 13, 2008 2:09 PM

Features

• Bluetooth specification compliant

• The adapter is compatible with the following profiles:

Package contents

• Bluetooth 2.1 EDR USB adapter

• Installation CD

• User Guide

Advanced Audio Distribution Profile

(A2DP)

Generic Access Profile (GAP)

Audio Video Remote Control Profile

(AVRCP)

Hardcopy Cable Replacement Profile

(HCRP)

Basic Imaging Profile (BIP) Headset/Audio Gateway Profile

(HSP)

Basic Printing Profile (BPP) Human Interface Device Profile

(HID)

BNEP Object Push Profile (OPP)

Dial-Up Networking Profile (DUN) Personal Area Networking Profile

(PAN)

Fax Profile (FAX) Serial Port Profile (SPP)

File Transfer Profile (FTP) Synchronize Action Profile (SYNC)

Generic Audio Video Distribution

Profile (GAVDP)

Generic Object Exchange Profile

(GOEP)

08-1322_RF-MRBTAD_COMBINED.fm Page 4 Tuesday, May 13, 2008 2:09 PM

RF-MRBTAD

System requirements

• One available USB port (USB 2.0 or 1.1)

•CDdrive

• Operating system: Microsoft® Windows 2000, Microsoft

Windows XP, or Microsoft Windows Vista®

Installing the software

Windows 2000 or Windows XP software

To install the Bluetooth software:

1Insert the installation CD into your computer’s CD drive. The

Welcome screen opens.

Note: If the program does not start automatically, open Windows

Explorer, browse to the BTW5 folder on the CD, then double-click

Setup.exe.

08-1322_RF-MRBTAD_COMBINED.fm Page 5 Tuesday, May 13, 2008 2:09 PM

2Click the language you want to use. The CD option screen

opens.

3Click Windows 2000/XP. The Welcome to the Installshield Wizard

screen opens.

4Click Next. The License Agreement screen opens.

08-1322_RF-MRBTAD_COMBINED.fm Page 6 Tuesday, May 13, 2008 2:09 PM

RF-MRBTAD

5Read the agreement, click I accept the terms in the license

agreement, then click Next. The Destination Folder screen opens.

6To install the software in the default location, click Next. The

Ready to Install the Program screen opens.

Or, to install the program in a different location, click Change,

type the new location, then click Next. The Ready to Install the

Program screen opens.

7Click Install. When the installation is complete, the Driver

Signature Notice box opens.

8Click OK. The Found New Hardware Wizard opens.

Note: If the Bluetooth device not found box opens, plug the Bluetooth

adapter into an available USB port on the your computer, then

click OK.

08-1322_RF-MRBTAD_COMBINED.fm Page 7 Tuesday, May 13, 2008 2:09 PM

The wizard installs the software. The installation may take

several minutes. When the installation is complete, the

InstallShield Wizard Completed screen opens.

9Click Finish. You are prompted to restart your computer.

10 After you restart your computer, click the Bluetooth icon on

the destop or on the toolbar.

08-1322_RF-MRBTAD_COMBINED.fm Page 8 Tuesday, May 13, 2008 2:09 PM

RF-MRBTAD

11 Click the locations where you want the icon to appear, then

click Next. The Bluetooth Service Selection screen opens.

Note: You can access the Bluetooth features through the Bluetooth

icon on the desktop or on the toolbar.

08-1322_RF-MRBTAD_COMBINED.fm Page 9 Tuesday, May 13, 2008 2:09 PM

12 Make sure that each Bluetooth service that you want to use

has a check mark, then click Next. The connection setup screen

opens.

13 If you want to set up a Bluetooth connection, make sure that

the Bluetooth device is in pairing mode, then click Next.

Or, if you do not want to set up Bluetooth connections, click

Skip.

08-1322_RF-MRBTAD_COMBINED.fm Page 10 Tuesday, May 13, 2008 2:09 PM
