RODE Microphones M1 Manuale utente

(EMC, LVD)

Instruction Manual

www.rodemic.com

- 2 -

Speciﬁcations

Acoustic Principle: Dynamic

Polar Pattern: Cardioid (see graph below)

Frequency Range: 75Hz ~ 18,000Hz (see graph below)

Output Impedence: 320Ω

Sensitivity: -56dB ± 2 dB re 1V/Pa

(1.6mV @ 94 dB SPL) @ 1 kHz

Output Connection: 3-pin XLR balanced output between

pin 2(+), pin 3(-) and pin 1 (ground)

Net Weight: 360g (0.79lb)

Packed Weight: 700g (1.54lb)

Dimensions: Length: 171mm (6.73”)

Width: 51.5mm (2.03”)

RM1

stand mount

ZP1

zip pouch

Polar ResponseFrequency Response

Accessories

- 3 -

Using the M1

• The M1’s primary function is a live vocal

microphone. When setting it up on stage,

make sure the foldback monitors are

positioned as pictured. This will direct the

sound to the vocalist and towards the least

responsive section of the M1’s pick up

pattern.

• To ensure the lowest noise/distortion your mixer input gain

control should be set so that the Peak Program indicator (PPI) LED

ﬂashes ON during peaks of the source (voice/instrument).

If there is no PPI, adjust the input gain while listening for

distortion of the sound. If distortion is heard, gradually reduce

the gain until it is no longer present.

• Microphone technique, or how to get the sound you want,

requires experimentation.

We suggest that you start with the channel EQ set to ‘OFF’ or

‘FLAT’ (no boost or cut).

• To avoid feedback and make full use of the M1’s

pick up pattern, it is best not to cup your

hands over the head of the microphone.

- 4 -

Warranty

All microphones are warranted for one year from date of purchase.

The M1 can be extended to a lifetime warranty if you register online at

www.rodemic.com.

The warranty covers parts and labour that may be required to repair the

microphone during the warranty period. The warranty excludes defects

caused by normal wear and tear, modiﬁcation, shipping damage, or failure to

use the microphone as per the instruction guide.

If you experience any problem, or have any questions regarding your

microphone, ﬁrst contact the dealer who sold it to you. If the microphone

requires a factory authorised service, return will be organised by that dealer.

We have an extensive distributor/dealer network, but if you have difﬁculty

getting the advice or assistance you require, do not hesitate to contact us

directly.

Microphones

International

PO Box 6685

Silverwater NSW 2128 Australia

Ph: +61 2 9648 5855

Fax: +61 2 9648 2455

USA

P.O. Box 4189

Santa Barbara, CA 93140-4189

Ph: 805 566 7777

Fax: 805 566 0071

Technical Support

For information and technical support questions contact:

support@rodemic.com

In the Unites States and Puerto Rico, contact

usasupport@rodemic.com or call 805 566 7777

Anywhere except the United States and Puerto Rico,

contact support@rodemic.com or call +61 2 9648 5855
