RODE Microphones NTG-1 Manuale utente

(EMC, LVD)

NTG-1

Instruction Manual

www.rodemic.com

- 2 -

Introduction

I want to thank you for your purchase of the

NTG-1 shotgun microphone.

The design brief for this microphone was to build a

shotgun that could be used in professional video,

ﬁlm and live stage applications where low noise, a

wide frequency response and tightly controlled polar

patterns are vital.

I am sure t hat once you have used your new mic ro pho n e,

you will agree we achieved our aim.

Likeall microphones, theNTG-1ismanufactured

using the ﬁnest surface mount electronic components

available, and has a body machined of high grade

aluminium which is ﬁnished in hard wearing epoxy

paint.

The heart of any microphone is the capsule, and with

the NTG-1, we have designed and incorporated what

we believe to be one of the best transducers in its

class.

The NTG-1 has many uses; It can be mounted on video

cameras using either the on-board camera mic mounts

or the optional shock mount. The NTG-1 is also suitable

as a boom mounted mic for ﬁlm and video use where it

is desirable to get closer to the sound source yet still be

out of the shot. Another area where the NTG-1 excels is

in a live sound situation, used to great effect as a ‘crowd

mic’ when doing a live band recording.

The NTG-1 comes complete with a heavy duty

microphone holder and a wind cover for ‘moderate’

outdoor applications. has also designed a

series of products which include the Dead Cat wind

sock (for high wind applications) and boom pole as well

as various cables and adaptors. Details of these units

are available on the website www.rodemic.com

Also while on our website please take the time to

Peter Freedman

Microphones

Sydney, Australia

- 3 -

Speciﬁcations

Acoustic

Principle:

Line plus gradient

Directional

Pattern:

Super-Cardioid

(see graph)

Frequency

Range:

20Hz ~ 20,000Hz

selectable HPF@80Hz/12dB

octave (see graph)

Output

Impedence:

50Ω

Sensitivity: -36dB re 1V/Pa @ 1kHz

(15mV/Pa @ 94dB SPL)

±2dB @ 1kHz

Equivalent Noise: 18dBA SPL

(per IEC651)

Maximum

Output:

+6.9dBu

(@ 1kHz, 1% THD into 1kΩ)

Dynamic Range: 121dB (per IEC651)

Maximum SPL: 139dB

(@ 1kHz, 1% THD into 1kΩ)

Signal/Noise: 76dB SPL

(@ 1kHz, rel 1Pa per IEC651)

Power

Requirement:

Phantom P48, P24

Output

Connection:

3-pin XLR

Net Weight: 105g

- 4 -

Speciﬁcations

Frequency Response

Polar Response

Accessories

`ÊÀiÊ£Ê6É*>

Ê£ä

Êä

Ê £ä

Ê Óä

Ê Îä

Ê {ä

ÊÓäâÊ £ääÊ £äääÊ £äÊäääÊ ÓäÊäää

äÂ

äÂ ÓÇ

£näÂ

Ó°ä

Óä°ä

Ê£ä°äÊÊ

ä°ä

Ó°ä

{°ä

È°ä

n°ä

£ä°ä

£Ó°ä

£{°ä

£È°ä

£n°ä

Óä°ä

ÓÓ°ä

Ó{°ä Óx°ä

`ÊÀi°Ê£6É*>

³x°ä

ÀiµÕiVÞ\

Ê xääÊâ\

£äääÊâ\

{äääÊâ\

–

Stand mount

Wind shield

Zip pouch

- 5 -

Features

• Broadcast sound quality

• Low noise circuitry

• Condenser transducer

• Rugged metal construction

• Low handling noise

• Includes stand mount, zip pouch and windshield

• Designed & manufactured in Australia

• Full 10 year guarantee*

Supplying Power

• The NTG-1 requires power to operate. This needs

to be supplied via P48V phantom power supply

which is available from most professional video

cameras or mixing consoles.

• If the mixer or preamp does not contain this

phantom power requirement, then an external

phantom power supply is needed.

• Some phantom power supplies do not supply the

voltage at which they are rated. If the required

voltage is not supplied, the dynamic range and

general performance of the microphone will be

reduced.

• We strongly suggest the use of a reputable high

quality power supply. Damage caused by a faulty

power supply is not covered by the warranty.

*Online product registration required.

- 6 -

• The NTG-1 comes complete with a heavy duty

stand mic holder for mounting the microphone on

any compatible stand with a 3/8” or 5/8” thread.

• Install as shown by pushing the mic in on an angle

coming from the back. You will notice the holder

is quite ﬁrm, and this is intentional so that the

the NTG-1 will not come out easily, which could

damage the mic.

• Make sure you do not block the slots on the side

of the mic (Fig 3) as blocking these will affect the

sound quality and the polar pattern (directional

qualities).

Mounting the NTG-1

- 7 -

• The NTG-1 incorporates a switchable high pass

ﬁlter set at 80 Hz. This can be used when you wish

to remove low frequency noise that is not part of

your intended sound source. Remember however

the tonal characteristics will be affected by this, so

it is important that you listen to the sound with and

without the HPF in circuit before deciding if it is

appropriate for the source.

• The HPF activated by the recessed

switch shown to the right. A small

screwdriver or pen will be required

as the switch is designed to prevent

accidental toggling.

• While it may sound like a contradiction, Shotgun

microphones have a narrow pick-up angle or polar

response, and so can be used to great effect with

cameras for news gathering, weddings, sporting

events or any situation where you want to focus on

a particular area of sound source without having

your audio overpowered by ambient noise.

• The NTG-1 is supplied with a foam windshield.

This windshield should be used even in the

slightest breeze, as this can cause sound

interference.

• When using the mic outside in heavy winds you

may need to purchase a more specialised wind

shield, such as the Dead Cat, which will

provide additional protection from adverse wind

conditions.

Using the NTG-1

High Pass Filter ON

High Pass Filter OFF/Flat

- 8 -

Warranty

All microphones are warranted for one year

from date of purchase. You can extend that to a full

ten years if you register online at www.rodemic.com.

The warranty covers parts and labour that may be

required to repair the microphone during the warranty

period. The warranty excludes defects caused by

normal wear and tear, modiﬁcation, shipping damage,

or failure to use the microphone as per the instruction

guide.

If you experience any problem, or have any questions

regarding your microphone, ﬁrst contact the

dealer who sold it to you. If the microphone requires a

factory authorised service, return will be organised by

that dealer.

We have an extensive distributor/dealer network, but

if you have difﬁculty getting the advice or assistance

you require, do not hesitate to contact us directly.

Microphones

International

107 Carnarvon Street

Silverwater NSW 2128 Australia

Ph: +61 2 9648 5855

Fax: +61 2 9648 2455

USA

P.O. Box 4189

Santa Barbara, CA 93140-4189

Ph: 805 566 7777

Fax: 805 566 0071

Technical Support

For information and technical support questions contact:

support@rodemic.com

In the Unites States and Puerto Rico, contact

usasupport@rodemic.com or call 805 566 7777

In Australia, contact ozsupport@rodemic.com or call (02) 9648 5855

Anywhere except Australia, the United States and Puerto Rico,

contact support@rodemic.com or call +61 2 9648 5855
