RogeRs Rocket™Hub

NETCOMM LIBERTY SERIES

ROGERS ROCKET HUB™ User Guide YML10WVR2

2 www.netcommlimited.com

Preface

The purpose of this manual is to provide you with detailed information on the installation, operation and application of your HSPA WiFi

Router with Voice.

Important Notice and Safety Precaution

• Before servicing or disassembling this equipment, always disconnect all power or telephone lines from the device.

• Use an appropriate power supply, preferably the supplied power adapter, with an output of DC 12V 1.5A

• Do not operate the device near ammable gas or fumes. Turn o the device when you are near a petrol station, fuel depot or chemical

plant/depot. Operation of such equipment in potentially explosive atmospheres can represent a safety hazard.

• The device and antenna shall be used only with a minimum of 20cm from human body.

• The operation of this device may aect medical electronic devices, such as hearing aids and pacemakers

• The antennas must be connected to this product prior to connecting the telephone cord.

• The telephone cord must be disconnected prior to disconnecting the antennas.

YML10WVR2 ROGERS ROCKET HUB™ User Guide

www.netcommlimited.com 3

ROGERS ROCKET™ HUB

NETCOMM LIBERTY SERIES

table of contents

Introduction �� 5

1.1 Features.................................................................................................................................................................................................................5

1.2 Package Contents..................................................................................................................................................................................................5

1.3 LED Indicators........................................................................................................................................................................................................6

1.4 Rear Panel .............................................................................................................................................................................................................7

Quick Setup �� 9

2.1 Setup Procedure ....................................................................................................................................................................................................9

Web User Interface�� 11

3.1 Default Settings ...................................................................................................................................................................................................11

3.2 TCP/IP Settings....................................................................................................................................................................................................11

3.3 Login Procedure ..................................................................................................................................................................................................14

3.4 Web User Interface Homepage ............................................................................................................................................................................14

3G Settings �� 16

4.1 3G Service Setup .................................................................................................................................................................................................16

4.2PINConguration.................................................................................................................................................................................................17

Wireless �� 20

5.1 Setup ...................................................................................................................................................................................................................20

5.2 Security ...............................................................................................................................................................................................................21

5.3Conguration........................................................................................................................................................................................................22

5.4 MAC Filter ............................................................................................................................................................................................................24

5.5 Wireless Bridge ....................................................................................................................................................................................................25

5.6 Station Info...........................................................................................................................................................................................................25

Management�� 27

6.1 Device Settings ....................................................................................................................................................................................................27

6.2CongureSNMPagenton3G10WVR2 ...............................................................................................................................................................29

6.3 Simple Network Time Protocol (SNTP) .................................................................................................................................................................30

6.4 Access Control.....................................................................................................................................................................................................31

Advanced Setup �� 34

7.1 Local Area Network (LAN) ....................................................................................................................................................................................34

7.2 Network Address Translation (NAT).......................................................................................................................................................................36

7.3 Security................................................................................................................................................................................................................38

7.4 Routing................................................................................................................................................................................................................40

Voice�� 43

Status�� 45

8.1 Diagnostics ..........................................................................................................................................................................................................45

8.2 System Log..........................................................................................................................................................................................................46

8.3 3G Network .........................................................................................................................................................................................................48

8.4 Statistics ..............................................................................................................................................................................................................50

8.5 Route...................................................................................................................................................................................................................51

8.6 ARP .....................................................................................................................................................................................................................51

8.7DynamicHostCongurationProtocol(DHCP)......................................................................................................................................................52

8.8 PING....................................................................................................................................................................................................................52

Appendix A: Print Server�� 54

ForWindowsVista/7 ..................................................................................................................................................................................................54

For MAC OSX ............................................................................................................................................................................................................56

Appendix B: USB Storage�� 58

ForWindowsVista/7 ..................................................................................................................................................................................................58

For MAC OSX ............................................................................................................................................................................................................58

Legal & Regulatory Information �� 59

IntRoductIon

YML10WVR2 ROGERS ROCKET HUB™ User Guide

www.netcommlimited.com 5

Introduction

With the increasing popularity of the 3G standard worldwide, this HSPA WiFi Router with Voice provides you with triple-band coverage

through expanding cellular networks throughout the world.

By following these simple step-by-step instructions, you can share your connection with multiple wireless and wired devices using the

3G network.

Integrating a Sierra Wireless HSPA module, this Router downloads at turbo speeds of up to 7.2Mbps.

This Router also provides state-of-the-art security features such as WiFi Protected Access (WPA) data encryption, Firewall and Virtual Private

Networks (VPN) pass through.

1.1 Features

• This HSPA WiFi Router with Voice allows you to share your 3G connection with multiple wireless or wired devices

• Provides you with worldwide coverage through triple-band HSUPA/HSDPA/UMTS (850 / 1900 / 2100MHz), quad-band EDGE/GSM (850

/ 900 / 1800 / 1900 MHz)

• Embedded multi-mode HSUPA/HSDPA/UMTS/EDGE/GPRS/GSM module

• 1 x RJ11 port for voice calling over the 3G network via a connected standard Analogue Telephone (not included).

• Integrated 802.11g/54Mbps AP (backward compatible with 802.11b)

• WiFi Protected Access (WPA)/ WiFi Protected Access 2 (WPA2) and 802.1x wireless encryption

• Static route/ Routing Information Protocol (RIP)/RIP v2 routing functions

• Media Access Control (MAC) address and IP ltering

• Network Address Translation (NAT)/ Port Address Translation (PAT)

• Supports Universal Plug and Play (UPnP) and Internet Group Management Protocol (IGMP) snooping

• Supports Virtual Private Network (VPN) Pass-Through

• Dynamic Host Conguration Protocol (DHCP) Server/Relay/Client

• Domain Name System (DNS) Proxy and Dynamic Domain Name System (DDNS)

• Web-based Management

• Command Line Interface (CLI) command interface via Telnet

• Conguration backup and restoration

• Remote conguration

• Router and 3G module rmware upgrade

• Supports half-bridging mode

• Supports Simple Network Management Protocol (SNMP)

1.2 Package Contents

Your package contains the following:

• 3G10WVR2 – HSPA WiFi Router with Voice

• Printed Quick Start Guide

• Ethernet Cable

• Wireless Security Card

• 1 x 3G Antenna

• Power Supply

• Support CD

NETCOMM LIBERTY SERIES

ROGERS ROCKET HUB

ROGERS ROCKET HUB™ User Guide YML10WVR2

6 www.netcommlimited.com

1.3 LED Indicators

The front panel LED indicators are shown in this illustration and followed by detailed explanations in the table below.

LED COLOR MODE DESCRIPTION

POWER Red On Power on

Off Power off

Phone Red On Phone line active

Off Phone line inactive or not connected

Flashing New Voice mail

LAN 1~2 Red On Powered device connected to the associated port (includes

devices with wake-on- LAN capability where a slight voltage is

supplied to an Ethernet connection)

Off No activit y, m o d e m p o wered off, no cable or no powere d

device connected to the associated port

Blink LAN activity present (traffic in either direction)

Wi Fi Red On Th e w i r e l e s s m o d u l e i s r e a d y.

Off The wireless module is not installed.

Blink Data being transmitted or received over WiFi.

Internet Red Blink Data is transmitted through Internet connection

Off No co n n e c ti o n t o t h e i n t e r n e t o r r o u ter powe r e d o f f

On Internet connection established

3G Red On Internet connection established.

Blink Connecting with UMTS cellular station

Off No connection with UMTS cellular station, no activity or

ro u t e r p o wered off.

2G Red On Internet connection established.

Blink Connecting to an EDGE, GPRS or GSM cellular station

Off No connection with EDGE, GPRS or GSM cellular station, no

activit y o r router powe r e d o f f.

Lo w Red On Lo w s i g n a l s t rength

Off No activit y, r o u ter powe r e d o f f o r o n o t h e r s i g n a l s t rength

Med Red On Medium signal strength

Off No activit y, r o u ter powe r e d o f f o r o n o t h e r s i g n a l s t rength

High Red On High signal strength

Off No activit y, r o u ter powe r e d o f f o r o n o t h e r s i g n a l s t rength

NOTE: The six LEDs on the right side of the front panel display (Internet, 3G, 2G, Low, Med, High) will cycle on and

o if PIN code protection is activated. In this case, you should consult section 4.2.1 PIN Code Protection for

further instructions.

YML10WVR2 ROGERS ROCKET HUB™ User Guide

www.netcommlimited.com 7

ROGERS ROCKET™ HUB

NETCOMM LIBERTY SERIES

1.4 Rear Panel

The rear panel contains the ports for data and power connections.

2 RJ-45 Ethernet Ports

Main 3G Antenna (removable, SMA connection)

Power jack for DC power input (12VDC / 1.5A)

Power button

USIM card slot

Aux 3G Antenna (internal)

USB Port (For connecting a USB Printer or USB Storage Device)

Reset button

Phone Port (for Circuit-Switched Voice Call)

QuIck setup

YML10WVR2 ROGERS ROCKET HUB™ User Guide

www.netcommlimited.com 9

ROGERS ROCKET™ HUB

NETCOMM LIBERTY SERIES

Quick Setup

2.1 Setup Procedure

These steps explain how to quickly setup your 3G Router:

1. Attach the 3G antenna provided to the port marked Main on the back of the router. The antenna should be screwed

in a clockwise direction.

2. Insert your SIM card (until you hear a click) into the USIM slot at the back of the Router.

3. Connect the yellow networking cable to one of the yellow ports found at the back of the Router.

4. Connect the other end of the yellow networking cable to the port on your computer.

5. If required, connect a standard Analogue Telephone to the port labeled “Phone”using an RJ-11 Cable (not included)

6. Connect the power adapter to the Power socket on the back of the Router.

7. Plug the power adapter into the wall socket and press the power button into the ON position (in).

8. Congure the router through the Web User Interface (WUI).

NOTE: Chapters 3 through 8 explain how to setup and use the WUI

9. Save the router conguration and reboot (see section 6.4).

Telephone

Laptop

Computer

3G Tower

Smart Phone

Printer USB Storage

OR

Web useR

InteRface
