Rointe D SERIES Istruzioni operative
D Series
quick programming
guide
Program your D Series products
the quickest way.
2
D SERIES
Learn how to optimise your consumption
without aecting comfort
Set correct temperature
The average comfortable temperature is 21ºC. So, we
recommend a temperature between 18 - 21ºC to keep your home
warm, whilst helping reduce energy consumption.
Reducing the temperature by just 1ºC, can save you up to £75 per
year.*
Program correctly
We recommend 3-4 hour heating periods under 21ºC, three times
a day. In between, the product should be set to off or eco mode.
Your radiators will be on for 9-12 hours a day at a constant,
comfortable heat.
Program your product to switch on 1 hour before using the room, for
a warm space without excessive consumption.
* Sourced from http://www.energysavingtrust.org.uk
Do not cover product
Our products transfer heat through natural air convection. If the
product is covered, this will interrupt air flow and could cause an
overheating or fire risk.
Please do not cover the products or place any object
(including furniture) directly in front of them.
3
Infrared sensor
On / Off button
Decrease temperature /
move left button
Increase temperature
/ move right button
Main menu button
Programming button
TFT screen
1 Current programming set
2 Days of the week
3 Current time
4 Current temperature set
5 Control panel locked / unlocked
6 Manual / automatic mode active
7 Comfort / eco / anti-frost mode active
8 Product Wi-Fi status
9Fuzzy Logic technology /
heating element active
10 Consumption indicator
11 Open Windows indicator
10
11
9
1
2
3
4
5
6 7 8
QUICK PROGRAMMING GUIDE
D SERIES CONTROL PANEL
4
D SERIES
D SERIES BASIC OPERATION
Turn product on / off
• Press once.
Lock / unlock control panel
• Press and hold and together for 3 seconds.
Adjust day and time
• Press once.
• Use and to highlight for settings and press .
• Highlight for day/time and press .
• Use and to set hour and press .
• Use and to set minutes and press .
• Use and to set day (1 for Mon, 2 for Tue etc.) and press .
5
QUICK PROGRAMMING GUIDE
Turn Open Windows function on / off
• Press once.
• Use and to highlight for energy saving functions and
then press .
• Highlight for Open Windows and press .
• Use and to select ON or OFF, press to
confirm and exit to main screen.
Adjust screen brightness
• Press once. Use and to highlight for settings and
press .
• Highlight for brightness and press .
• Use and to choose backlight or standby screen.
• Use and to adjust the level of brightness.
• Press to confirm and exit to main screen.
View Wi-Fi settings
• Press once.
• Use and to highlight for settings and press .
• Highlight for Wi-Fi settings and press .
• The network name and password PIN will appear on the screen.
• Press to exit and return to main screen.
Switch between manual & automatic mode
• An (manual) or (automatic) will
appear on the main screen to show which
mode is active.
• Press once. Use and to select
the top left setting which will say MAN or
AUTO.
• Press to toggle between MAN (manual) or AUTO (automatic).
• Don’t touch keypad for 60 seconds to confirm & exit to main screen.
6
1. Select Manual mode
• Press once. Use and to select the top left setting which will say MAN or AUTO.
• Use to toggle between MAN (manual) or AUTO (automatic).
• Do not touch the keypad for 60 seconds to confirm and exit to main screen.
• An will appear on the main screen.
2. Select temperature
• Press to decrease temperature.
• Press to increase temperature.
3. Switch radiator off when heating not required
• Press once.
• Press again to switch radiator back on when heating required. The previous temperature
and programming set will activate.
D SERIES MANUAL MODE
D SERIES Manually adjust
temperature
between 15 and 30oC.
Switch radiator on/
off when required.
No automatic
programming.
7
1. Select Automatic mode
• Press once. Use and to select the top left setting which
will say MAN or AUTO.
• Use to toggle between MAN (manual) or AUTO (automatic).
• Do not touch the keypad for 60 seconds to confirm and exit to main
screen.
• An will appear on the main screen.
2. Go to programming menu
• Press once.
• Use and to highlight for programming and press .
3. Select comfort mode temperature
• Use and to set comfort mode temperature between 19 - 30ºC.
• Press .
4. Select eco mode temperature
• Use and to set eco mode temperature between 7.5 - 18.5ºC.
• Press .
5. Select days
• Start on day 1 (Monday). Press to include this day in
programming. The day will stop flashing. If you press again the
day will be excluded and start flashing.
• Use to move forwards a day.
• Repeat for all days of the week.
• Press to move to next part of programming.
6. Select hours
• Start on 0h (midnight). Press to choose eco, press again for
comfort or press again for off mode for this hour.
• Use to move onto the next hour 1h (1 am) and repeat the eco /
comfort / off mode selection using .
• Repeat until all hours of the day are programmed.
• Press to confirm and exit.
D SERIES AUTOMATIC MODE
NOTE
• If you need different programming on individual days then repeat steps 2 to 6 above for each day.
Schedule automatic
programming for
each day and hour
of the week using
comfort and eco
modes.
If you have any questions or need help, please contact us:
0203 321 5929 · support@rointe.co.uk
Mon to Fri from 7.30 am to 5.30 pm Professional team, always happy to help
Rointe United Kingdom
Catalyst House, 720 Centennial Court, Centennial Park, Elstree, Herts, WD6 3SY | T. 0203 321 5928 | F. 0208 953 5861
Rointe Ireland
Blackrock, County Louth | T. 01 553 0523 | F. 01 553 0524
Rointe España
P.I. Vicente Antolinos - C/ E, p. 43, 30140 Murcia | T. 902 158 049 | F. 968 277 125
Rointe France
6 Rue Duret, 75116 Paris | T. 01 73 05 70 01
Rointe Россия
121069, Поварская 10/1, 4 этаж, Москва | T. 917 541 70 69
DSERIES-QPG-2019
