Roland TB-30 Manuale utente
R1-201223 FA02295
Thank you very much for purchasing this product.
• To ensure correct and safe usage with a full understanding of this product's performance, please be sure to
read through this manual completely and store it in a safe locaon.
• Unauthorized copying or transferal, in whole or in part, of this manual is prohibited.
• The contents of this document and the specicaons of this product are subject to change without noce.
• This document and the product have been prepared and tested as much as possible. If you nd any misprints
or errors, please inform us.
• Roland DG Corporaon assumes no responsibility for any direct or indirect loss or damage that may occur
through use of this product, regardless of any failure to perform on the part of this product.
• Roland DG Corporaon assumes no responsibility for any direct or indirect loss or damage that may occur
with respect to any arcle made using this product.
Company names and product names are trademarks or registered trademarks of their respecve holders.
Copyright © 2020 Roland DG Corporaon
hp://www.rolanddg.com/
1
Contents
Contents ...........................................................................................................1
Introducon......................................................................................................2
Notes to Follow .............................................................................................. 2
How to Load Media...........................................................................................3
1. Load the paper tube. .................................................................................. 3
2. Pass the media through the printer. ........................................................... 5
3. Secure the media on the paper tube (core). .............................................. 7
4. Take up the media. ................................................................................... 10
5. Congure the prinng sengs. ................................................................ 12
2
Introduction
Notes to Follow
The TB-30 is a device used to print on thin lm material or other such roll media consisng of material
that lacks rmness. It is not designed for prinng on sheet media.
Before prinng on sheet media, remove the TB-30.
Media that lacks rmness wrinkles easily, so do not pull back this media.
To prevent media from being pulled back, adhere to the following guidelines.
• Do not use the Print & Cut funcon.
• Do not use the sheet cung funcon.
• Do not pull back the media manually.
• Set the take-up method to "TU3" on the printer.
• Use the "Page Space" seng in VersaWorks to set the page space to "120 mm" (4.72 in.).
3
CAUTION Load the roll media correctly.
Otherwise the media may fall and cause injury.
CAUTION The roll media weighs about 25 kg (55 lb.). To avoid injury, handle the roll
media with care.
CAUTION Never load media that weighs more than 25 kg (55 lb.).
The machine may fail to withstand the weight and p over or cause the
media to fall.
CAUTION Do not touch the dancer roller needlessly.
The media take-up unit and feeder may move suddenly, which may result
in injury.
IMPORTANT
• Media with a width of 688 to 762 mm (27.1 to 30 in.) can be used.
• When prinng on thin lm material or similar media, use only the le and right pinch rollers.
1. Load the paper tube.
A Lower the dancer roller toward the rear.
Dancer roller
B Loosen the arm retaining screw.
Loosen the screw to a point where the arm can be moved to the le and right.
Arm retaining screw
How to Load Media
4
How to Load Media
C Install the paper tube to the end cap and x the arm.
1
Fit the paper tube securely onto the (right) stand leg side end cap.
2
Push the arm side end cap against the paper tube and t it securely.
3
Fix the arm in place with the arm retaining screw.
Fit on securely
Arm
Fit on securely
End cap
Paper
tube
Paper tube
IMPORTANT
• Do not overghten the arm retaining screw.
Overghtening may make it dicult to remove the arm.
• Use the paper tube that is included with the roll.
If a dierent tube is used, the media may not be taken up because the roll may fail to engage.
Tighten the screw while pulling this
part forward and pushing it from
above.
5
How to Load Media
2. Pass the media through the printer.
A Check that the printer's loading lever is in the up posion.
B Switch on the printer's sub power.
C Check that the following menu items on the printer have been set to "DISABLE."
• [PREFEED]
"For details on how to check and change the sengs, refer to the instrucon manual for your printer.
D Press [MENU] to return to the setup screen.
SETUP SHEET
ROLL
E Press [◄] or [►] to select "TU3."
"For details on selecng the take-up method, see the TUC-4 user's manual.
F Open the front cover.
G Remove the screws (in two locaons), and then remove the front UV shield.
Front UV shield
6
How to Load Media
H Raise the oang roller (weight roller) toward you.
I Pass the media between the oang roller and the tension roller.
J Lower the oang roller toward the back of the machine.
K Lower the (front) loading lever.
Loading lever (front)
L Close the front cover.
Media
Tension
roller
Floang roller
7
How to Load Media
M Check the loading status of the media.
• The media is loaded straight.
• All areas of the media are taut.
If the media has slack or is bent, raise the loading lever and load once again.
IMPORTANT
Avoid pulling back the media as much as possible because doing so may wrinkle the media.
N Press [ENTER].
3. Secure the media on the paper tube (core).
A Make sure the screen in the gure is displayed.
LOAD SHEET
TO TAKE-UP
B Press [▼] to feed out the media unl the p of the media reaches the paper tube.
Check that the media is fed out straight.
If the media is not feeding straight, perform the loading operaon once again.
Media is fed out 10 mm (0.4 in.) each me you press [▼]. Holding down the key lets you feed
out paper connuously.
8
How to Load Media
C Aach the center and both ends of the media to the paper tube (core) using adhesive
tape (three locaons in total).
1
While pulling the media so that it does not sag, secure the center of the media.
2
While pulling the media from the center toward the outer edges, and x the le
and right edges.
Take-up with outward curl
Adhesive tapePaper tube
Take-up with inward curl
Adhesive tape
Paper tube
